Multi-application - LiFePO4 Power
NA-12Li100BL
Issued Date
Issued Version
1. General Information
This specification defines the performance of rechargeable LiFePO4 battery pack
UPOWER, S.L., describes the type, performance, technical characteristics, warning and caution of the battery
pack. The battery pack support Bluetooth communication function. Through Android and IOS APP, can read the
battery status and information. Especially due to the Android system's openness, different smart phone manufactu-
rer will have their own different Bluetooth hardware version and customized feature Android systems.
So the APP may not work well on some smart phones (with Android system) due to compatible issue.
It is necessary for the customer to confirm whether the phone is compatible for the APP.
2. Specification (@Battery initial Temp25±5°C)
NO.
Items
Rated Capacity
1
Minimum Capacity
Energy
2
3
Nominal Voltage
4
Outgoing Voltage
Internal resistance
5
6
Series parallel application
7
Limited charge voltage
8
Floating charge voltage
9
Standard charge current
10
Maximum charge current
11
Standard discharge current
** Siguiendo la normativa estricta de la industria naval en materias de interconexión eléctrica y salud
>
2017-05-31
>
V00
LITHIUM IRON PHOSPHATE BATTERY
NA-12Li100BL
Description
100Ah
95Ah
1.28KWh
12.8V
≥12.8V
≤30mΩ
Up to 4 series-connected applications
14.6±0.2V
13.8±0.2V
60A
80A
80A
www.upowerbatteries.com
manufactured by
01
Advertisement
Table of Contents
Related Manuals for UPOWER Ecoline NauticBattery NA-12Li100BL
Summary of Contents for UPOWER Ecoline NauticBattery NA-12Li100BL
- Page 1 www.upowerbatteries.com LITHIUM IRON PHOSPHATE BATTERY Multi-application - LiFePO4 Power NA-12Li100BL Issued Date > 2017-05-31 Issued Version > 1. General Information This specification defines the performance of rechargeable LiFePO4 battery pack manufactured by NA-12Li100BL UPOWER, S.L., describes the type, performance, technical characteristics, warning and caution of the battery pack.
- Page 2 NA-12Li100BL www.upowerbatteries.com Items Description Maximum discharge current 100A Pulse discharge current Withstand the 350A/3s Discharge cut-off voltage 8.0V Length: 327±2mm Dimension Width: 171±2mm Height: 234±2mm Weight Approx: 12.8±0.5Kg Charging: 0~45°C Operating Temperature Discharging: -20~60°C Recommended operating temperature: 15°C~35°C Residual capacity: ≤3%/month; ≤15%/years Self-discharge rate Reversible capacity: ≤1.5%/month;...
- Page 3 NA-12Li100BL www.upowerbatteries.com 3.5 Quick Discharge Mode "Quick Discharge" means discharge to the cut-off voltage with 0.5C current. 4. Product Performance Items Criteria Testing Method Rated Capacity 100Ah Rest for 1 hour after fully charged, then discharge with 0.33C current until the battery reaches the discharge cutoff voltage.
- Page 4 NA-12Li100BL www.upowerbatteries.com Items Content Specification Over-charge protection for each cell 3.75±0.025V Over charge Over-charge release for each cell 3.60±0.04V Over-charge release method Under the release voltage Over-discharge protection for each cell 2.0±0.04V Over discharge Over-discharge release for each cell 2.5±0.04V Over-discharge release method Charge to recovery Discharge over current protection...
- Page 5 NA-12Li100BL www.upowerbatteries.com 7. Transportation • Based on the character of cell, proper environment for transportation of LiFePO4 battery pack need to be created to protect the battery. • Battery should be stayed in the warehouse 15ºC 〜 35ºC where it’s dry, clean, shade and well-ventilated. •...
- Page 6 NA-12Li100BL www.upowerbatteries.com 9. Battery Operation Instruction 9.1 Charge and discharge 9.1.1 Charging current: Do not surpass the largest charging current that specification stipulated. 9.1.2 Charging voltage: Do not surpass the highest limited voltage that specification stipulated. 9.1.3 Charging temperature: within temperature scope that specification stipulated. 9.1.4 Charge with constant current, then with the constant voltage, no reverse charge, which is dangerous.
