- Page 1 Sanitizing Sink Heater 3CS Series 3CS-3 3CS-4 REPLACEMENT PARTS LIST 3CS-6 3CS-9...
- Page 2 HATCO 3CS SERIES SANITIZING SINK HEATERS CAUTION - Use of replacement parts other than those supplied by Hatco Corporation may result in damage to the unit or injury to personnel. Form No. 3CSRP - 0401 9, 10 Model Designation 3CS-X...
- Page 3 ITEM DESCRIPTION On/Off Power Switch Control,Thermostat, 192°F (89°C) Thermostat, Overtemp, 205°F (96°C) Thermostat, At-Temp, 175°F (79°C), (optional) Mounting Bolts Gasket, Element Drain Cap, Heating Compartment Handle, Sump Drain Ball Valve, Sweat Fitting (old style) Ball Valve, Thread Fitting (new style) Temperature Monitor (optional) Shaded area in parts lists on the following pages reflects export models only.
- Page 4 PARTS SPECIFIC TO MODEL 3CS-3 ITEM DESCRIPTION Heating Element (Qty. 1) Power Relay Mounting Bracket, Terminal Block Transformer Mounting Bracket, Transformer Fuse (AGC-1) (2 Pack) Fuse Holder Water Tank Water Tank Terminal Block Contactor (Qty. 1-2) Indicator Light, Blue Rubber Cover, Toggle Switch...
- Page 5 PARTS SPECIFIC TO MODEL 3CS-4 ITEM DESCRIPTION Heating Element (Qty. 1) Power Relay Mounting Bracket, Terminal Block Transformer Mounting Bracket, Transformer Fuse (AGC-1) (2 Pack) Fuse Holder Water Tank Water Tank Terminal Block Contactor (Qty. 1-2) Indicator Light, Blue Rubber Cover, Toggle Switch (Not Shown) Jacket, Painted Jacket, S.S.
- Page 6 PARTS SPECIFIC TO MODEL 3CS-6 ITEM DESCRIPTION Heating Element (Qty. 2) Power Relay Mounting Bracket, Terminal Block Transformer Mounting Bracket, Transformer Fuse (AGC-1) (2 Pack) Fuse Holder Water Tank Water Tank Terminal Block Contactor (Qty. 1-2) Indicator Light, Blue Rubber Cover, Toggle Switch (Not Shown) Jacket, Painted Jacket, S.S.
- Page 7 PARTS SPECIFIC TO MODEL 3CS-9 ITEM DESCRIPTION Heating Element (Qty. 2) Power Relay Mounting Bracket, Terminal Block Transformer Mounting Bracket, Transformer Fuse (AGC-1) (2 Pack) Fuse Holder Water Tank Water Tank Terminal Block Contactor (Qty. 1-2) Indicator Light, Blue Rubber Cover, Toggle Switch (Not Shown) Jacket, Painted Jacket, S.S.
- Page 8 Comm. Parts & Service, Inc. Louisville 502-367-1788 LOUISIANA Chandlers Parts & Service Baton Rouge 225-272-6620 Parts & Service Fax (800) 690-2966 Form No. 3CSRP-0401 HATCO AUTHORIZED PARTS DISTRIBUTORS LOUISIANA (Continued) Bana Comm. Parts, Inc. Shreveport 318-631-6550 MARYLAND Electric Motor Service Baltimore 410-467-8080 GCS Service, Inc.
