Stealth Timer
_W016
Instruction Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W016 and is the answer not in the manual?

Questions and answers

Related Manuals for Gill W016

Summary of Contents for Gill W016

  • Page 1 Stealth Timer _W016 Instruction Manual...
  • Page 2 This watch comes with a 2 year warranty. For warranty issues please contact your nearest stockist. Proof of purchase required.
  • Page 3 1.0 Introduction Thank you for purchasing the Stealth Timer. This watch features real time, race countdown timer, stopwatch and compass modes in addition to many other functions. Your watch will be supplied in Power Down Mode in order to preserve battery life. To exit, press and hold any button for 5 seconds.
  • Page 4 2.0 Buttons Operation Summary Mode Button [M] STP. Button [STP] - In function modes: Press to enter the next - In Timer Mode: Press to stop or hold to mode. reset the timer. - In Clock Mode, press and hold for about - In Chronograph Mode: Press to stop or 2 seconds to enter the time setting display.
  • Page 5 3.0 Major Function Modes MODE STP. Countdown Timer Mode Compass Mode Section 5 Section 6 ST./LAP/SYNC Clock Mode Section 4 Alarm Mode Chronograph Mode Section 8 Section 7...

  • Page 6: Clock Mode

    4.0 Clock Mode [STP] AM/PM Indicator 12hr format only Date Day of Week Real Time [S/L/S] Clock Display Clock Mode. Any button Idle 10mins * Standby Mode - To set the time, date, and other settings press and hold the [M] button for about 2 seconds to enter the setting display.
  • Page 7 3.0 Regatta Mode 4.1 Clock Mode _ Settings [STP] 2 Seconds Minutes Hours [S/L/S] Month Year 12/24 Hr format Keytone ON/OFF LCD Level...
  • Page 8 5.0 Timer Mode _ Countdown Timer Countdown Timer Mode - The Stealth Timer has four pre-set values: 5.4.1.0, 5-Minutes, 3-minutes and 1-minutes and one user defined value. [STP] [STP]* 2 Seconds 5-Minutes 3-Minutes [S/L/S] Countdown Timer Mode User 1-Minutes * Press and hold [STP] button for two second to switch between each value. Alternatively press and hold [STP] button continuously to scroll through values.
  • Page 9 7.0 Chronograph Mode 5.1 Timer Mode _ Countdown Timer Settings [STP] 2 Seconds Hours Minutes [S/L/S] Vibrate ON/OFF Seconds Alert ON/OFF Sync Mode Timer Repeat ON/OFF...
  • Page 10 5.2 Timer Mode _ Countdown Timer Multiples of Pre-set Value - After the pre-set values have been chosen, the countdown can be increased by a multiple of that value by pressing [STP] button. For example: if pre-set is 3 minutes, press [STP] button once to double it to 6 minutes, press [STP] button twice to triple it to 9 minutes and so on*.
  • Page 11 5.3 Timer Mode _ Countdown Timer - Press [S/L/S] button to start countdown, the countdown icon will start flashing. [S/LS] - The countdown display from 59 seconds to 1 second will be displayed as large digits . Alert Indications - The timer will beep\vibrate once at each minute. - The timer will beep\vibrate once at 50, 40, 30 &...
  • Page 12 5.4 Timer Mode _ Countdown Timer Key Lock Function (suspend buttons operation during counting) - Whilst in Timer mode, press and hold [M]+[SLS] buttons at the same time to toggle the key lock function ON/OFF. When key lock function is ON the symbol will be shown.
  • Page 13 5.5 Timer Mode _ Count-up Timer Count-up Timer Mode - When the Countdown Timer reaches zero, the icon will change to a icon and enter the Count-up Timer. Auto return after 10 sec [S/L/S] Countdown Mode - zero Count-up Mode - Running Set Lap Time (Up to 10 Laps) [STP]...
  • Page 14 5.6 Timer Mode _ Timer Recall Timer Recall Mode - In Timer Mode, the Stealth Timer can recall the total elapsed time and saved lap times - Timer recall mode can be entered whilst the count-up timer is running or stopped by pressing [M] button for about 2 seconds.

  • Page 15: Compass Mode

    6.0 Compass Mode [STP] Wait 3 Seconds Compass Display [S/L/S] [S/L/S] [STP] Compass Mode Course Shift Mode Shift Right Shift Left - To lock heading press [ button, the Stealth Timer will then enter Course Shift Mode S/L/S] - A new heading can be set in Course Shift Mode by pressing button.
  • Page 16 6.1 Compass Mode _ Settings [STP] 2 Seconds Calibration Declination* [S/L/S] [S/L/S] Auto Return Calibration: To Calibrate Compass rotate watch through 360 degrees until boarder is complete. Declination: To adjust declination press [S/L/S] to increase value and [STP] to decrease value. Declination accounts for the difference between True North and Magnetic North and should be set according to your current location...

  • Page 17: Chronograph Mode

    7.0 Chronograph Mode Auto return after 10 seconds [STP] [S/L/S] [S/L/S] [STP] 1/100 2 Seconds Chronograph - Running Set Lap Time [S/L/S] (Up to 50 Laps) Chronograph Mode [M] 2 Seconds [S/L/S] [STP] Recall - Total Time Recall - Lap Time Chronograph Recall Mode - In Chronograph Mode, the Stealth Timer can recall the total elapsed time and saved lap times...

  • Page 18: Daily Alarm Mode

    8.0 Daily Alarm Mode [STP] ON/OFF 2 Seconds Minutes Hours [S/L/S] Alarm Test Auto return after 60 seconds Alarm Settings - Press [STP] button to toggle between alarm ON/OFF, when the alarm indicator Icon appears the alarm is on. - The alarm will sound at the alarm time every day when the alarm is ON. - The watch will beep for about 60 seconds at alarm time.

  • Page 19: Power Modes

    9.0 Power Modes. This watch includes three power saving Functions designed to help the battery last longer: Standby Mode. - In Clock Mode, when no key is pressed for 10 Minutes, the timer will enter Standby Mode. - When in Standby Mode only the current time will be shown. - To exit Standby Mode: press any key.

  • Page 20: Battery Changing

    10.0 Battery Changing The Stealth Timer has an easy battery change feature. To change the battery follow the instructions below . 1- Turn the cover counter- clockwise with a coin gently until it opens 2- Replace the battery (CR2032) ensuring the negative side (-) is placed against the silver metal connector.
  • Page 21 10.0 Battery Changing 3. Replace the cover, ensuring the two arrows are aligned. 4- Turn the cover clockwise with a coin until the arrow points to the dot as shown. Locked NOTE: Keep batteries away from children. If swallowed, contact a doctor immediately. CAUTION: Risk of malfunction if battery is replaced by an incorrect type.
  • Page 22 10.1 Setting up Unlock and remove timer from the holder - Locate the Lock Button on reverse of the holder. - Rotate Timer until the large arrow is aligned with lock button, press lock button and pull timer from holder. Lock button - To replace timer, ensure the arrow is aligned with lock button, then firmly push timer into place until you hear lock button click.
  • Page 23 10.2 Setting up _ Wrist Strap Fitting and adjustment:...
  • Page 24 10.3 Setting up _ Surface Mounting Screws can be used to mount the timer holder to a suitable surface.

  • Page 25: Specifications

    11.0 Specifications Clock Mode: Daily Alarm - Hour, minute, second, am, pm, month, - 1 Daily Alarm date, and day of week - Sounds for 60 seconds at alarm time - Time System 12-hour or 24-hour format - Calendar System Battery: Auto-Calendar pre-programmed from - Single 3V lithium battery (CR2032)
