- Page 1 Regatta Race Timer_W014 Instruction Manual...
- Page 2 This Regatta Race Timer comes with a 2 year warranty. For warranty issues please contact your nearest stockist. Proof of purchase required.
- Page 3 1.0 Introduction Thank you for purchasing this timer. The timer includes real time, daily alarm and a regatta timer which times the starting of a race. The timer is carefully designed and produced for sailing use. In order to utilise the features on your timer, it is advisable to read the following notes before using for the first time: - Avoid exposing the timer to extreme conditions...
- Page 4 2.0 Buttons Operation Summary Mode Button [M] Set Button [S] - In function modes: Press to enter the - In Real Time Mode, press and hold for about next mode 2 seconds to enter the time setting display. - In any setting display: Press to choose - In Function Mode, press and hold for about 2 among different settings seconds to enter the function setting display.
- Page 5 3.0 Major Function Modes Real Time Mode Timer Mode Daily Alarm Mode Chronograph Mode...
- Page 6 4.0 Real Time Mode How to set the Real Time - To set the Real time, date, and other settings Real Time press and hold the [S] button for about 2 seconds to enter the setting display (The [S/R] minutes digits will start flashing). The Setting Sequence - When the minute digit starts flashing, press the [M] button to move the flashing digits...
- Page 7 4.1 Real Time Mode - Setting Sequence HOLD [S] Minute Keytone Format ON / OFF Hours LCD Level Year Month...
- Page 8 5.0 Timer Mode How to set the Timer - In Timer Mode, press and hold [S] button for 2s, the hour will be flashing, press the [S/L/S] or [S/R] buttons to adjust the time you want. Press the [M] button to change the setting items.
- Page 9 5.1 Timer Mode - Countdown Timer 5.1 Timer Mode - Countdown Timer Countdown Timer Countdown Timer (Four Pre-set Values & One User-defined Value) (Four Pre-set Values & One User-defined Value) - This race timer has four pre-set values: 5.4.1.0, 5-Min, 3-Min and 1-Min and one user - This race timer has four pre-set values: 5.4.1.0, 5-Min, 3-Min and 1-Min and one user defined value, Press the [S/R] button to change the display among them.
- Page 10 5.2 Timer Mode - Countdown Timer Multiples of Present Value - After you have chosen one of the pre-set values, you also can mutliply those values by pressing the [S] button. For example: If pre-set timer is 3 Min, press [S] button once to double it to 6 Min, press [S] button twice to triple it to 9 Min...
- Page 11 5.3 Timer Mode - Countdown Timer Synchronisation Function Alert Indications - When the Countdown Timer is running, press - The watch will beep once at each minute. the [S/L/R] button to round off the counting - The watch will beep once at 50, 40, 30 & 20 time.
- Page 12 5.4 Timer Mode - Count-up Timer & Timer Recall Count-up Timer Timer Recall - When the Countdown Timer reaches zero, - In Timer Mode, press the [S] button once to icon will change to a icon and enter enter timer recall display. to the Count-up Timer.
- Page 13 6.0 Chronograph Mode Chronograph Mode [S/R] - In Chronograph Mode, the Hour, Minute, and second digits appear on the middle row of the display. Hour, Minute, Second - The Chronograph (CHR) icon appears on the upper row of the display 1/100 sec - The Lap number and 1/100s appears on the lower row of the display.
- Page 14 7.0 Daily Alarm Mode The Alarm Time Mode To select the Alarm ON/OFF - In the Chronograph Mode, press the [M] - Press the [S/R] button to toggle between button to enter the Alarm Mode. alarm ON/OFF - The alarm time (hour, minute) is shown on - When the alarm indicator appears, the the middle row of the display.
- Page 15 7.1 Daily Alarm Mode Daily Alarm Mode - Setting - In the Alarm Mode, press and hold the [S] button for about 2 seconds, the minute digit will flash on the display. - Press the [M] button to change between the desired setting item.
- Page 16 8.0 Power Saving Mode Power Saving Mode - This timer includes a power saving function. (this function allows the battery to last longer) - While in the Power Saving Mode, the general functions are still working normally. (i.e.the time keeping function is still running during Power Saving Mode) How to enter/exit Power Saving Mode - Hold down the [S/R] button in Real Time Mode...
- Page 17 9.0 Battery Changing The Regatta Race Timer has an easy battery change feature. To change the battery follow the instructions below. 1- Turn the cover counter- clockwise with a coin gently until it opens. 2- Replace the battery (CR2032) ensuring CR2032 the negative side (-) is placed against the CR2032...
- Page 18 9.0 Battery Changing 3- Replace the cover. 4- Turn the cover clockwise with a coin until the arrow points to the dot as shown below. Locked NOTE: Keep batteries away from children. If swallowed, contact a doctor immediately. CAUTION: Risk of malfunction if battery is replaced by an incorrect type.
- Page 19 10.0 Setting up To unlock and remove the timer from the holder: Turn the timer clockwise until the two arrow points align. MODE STP. ST./LAP/SYNC Unlocked...
- Page 20 10.0 Setting up Fitting and adjustment:...
- Page 21 10.0 Setting up Use the screws to mount the timer holder to a bulkhead.
-
Page 22: Specifications
11.0 Specifications Real Time Mode Daily Alarm Mode - Hour, minute, second, am, pm, month, - 1 Daily alarm date, and day of week - Time System Chronograph Mode 12-hour or 24-hour format - Resolution - Calendar System 1/100 second Auto-Calendar pre-programmed from the - Measuring Range year 2000 to 2099... - Page 24 gillmarine.com...
