9. BT: Bluetooth mode.
Press "BT" button on the remote to convert to Bluetooth input mode, LED
flash fast to search the Bluetooth device. Turn on your mobile Bluetooth
device and search the device name " UL-SB10-2.1 ", paired them well.
When you have successfully paired your mobile to the speaker system,
LED flashes slowly. When starting to play your mobile music, LED stopped
flash. The functions as "PREVIOUS/NEXT", "PLAY/PAUSE", can operate
via the front panel. On BT mode, when connecting with mobile, press " "
for 3 seconds, bluetooth function can be force-disconnected.
10. ARC: ARC mode.
11. OPT: Optical mode.
12. AUX: Audio input mode.
13. USB: USB mode.
14. TONE: Press it, LED flashes, it enter into treble adjustment status,
can press Vol+/Vol- adjust treble level -6(min)~+6(max). Press it again,
LED flashed 2 times, it enter into bass adjustment status, can press
Vol+/Vol- adjust bass level -6(min)~+6(max).
System Connection Diagram:
Soundbar
Place it near the TV or DVD player.
Please Note:
05
SB-soundbar
6
Rear panel:
Soundbar
(1)
1. Input Connect to sound sources such as computer, CD player, Mp3, etc.
2. Optical Input.
3. ARC Input.
4. AC Power cord.
Subwoofer
(5)
5. AC IN: AC Power cord
6. RESET: Press and hold the button at the back plate of subwoofer,
and connect to power at the same time, wait for 5 seconds, then stop
pressing, Subwoofer will be reset.
7. LED:Turn on the red light long, connected successfully long blue light
8. Power ON/OFF: Switch for turning on/off the unit.
* If the remote control cannot function, it is because the battery of
remote control has been used up. thank you.
(2) (3) (4)
(6) (7) (8)
