DFA 1163 Quick Reference Guide
LED13 LED12 LED9 LED6 LED5 LED4 LED1 LED2 LED3
C4 A4
146 220
145
2
1 77
146 220
145
2
1 77
L1 L2 L3 L4
P12 P7
P6 P1
U5
U9
U1 U4
CN1 SW1 J1 J2 J3
CN11
C4 A4
288
287
144
143
288
287
144
143
TP29 18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
L 4 L 4 L 3 L 3 L 2 L 2 L 1 L 1
CON2 CON1 CN4
CON2: LAN Connector
CN7 SW2
1 6
J4
J5
CN9
JP6
JP7
JP8
JP9
JP10
CPLD_JP1
CN6
CON1: LAN Connector
1
CN10
CN8
Pin Signal
A1 Port3_TX0N
A2 Port3_TX0P
A3 Port3_TX1N
A4 Port3_TX1P
A5 Port3_TX2N
4 A6 Port3_TX2P
A7 Port3_TX3N
A8 Port3_TX3P
A9 GND
A10 GND
AL4 P3V3
AL3 P1_LED2
AL1 P1_LED1
5
AL2 P1_LED0
L5 P10G_Scl2
L6 ModABS2_L
L7 2_RS0
L8 RxLOS2
L9 2_RS1
L10 GND
Pin Signal
A1 LAN1_MDIN0
A2 LAN1_MDIP0
A3 LAN1_MDIN1
A4 LAN1_MDIP1
A5 LAN1_MDIN2
4 A6 LAN1_MDIP2
A7 LAN1_MDIN3
A8 LAN1_MDIP3
A9 GND
A10 GND
AL4 P3V3
AL3 LAN1_LED_ACT_N
AL1 LAN1_LED_LINK1000_N
5
AL2 LAN1_LED_LINK2500_N
L5 P10G_Scl2
L6 ModABS2_L
L7 2_RS0
L8 RxLOS2
L9 2_RS1
L10 GND
Pin Signal
B1 LAN2_MDIN0
B2 LAN2_MDIP0
B3 LAN2_MDIN1
B4 LAN2_MDIP1
B5 LAN2_MDIN2
B6 LAN2_MDIP2
B7 LAN2_MDIN3
B8 LAN2_MDIP3
B9 GND
B10 GND
BL4 P3V3
BL3 P3_LED2
BL1 P3_LED1
BL2 P3_LED0
L16 3P3V_SFP2_T
L15 3P3V_SFP2_R
L14 GND
L13 2_SFP+_RD+
L12 2_SFP+_RD-
L11 GND
Pin Signal
B1 LAN2_MDIN0
B2 LAN2_MDIP0
B3 LAN2_MDIN1
B4 LAN2_MDIP1
B5 LAN2_MDIN2
B6 LAN2_MDIP2
B7 LAN2_MDIN3
B8 LAN2_MDIP3
B9 GND
B10 GND
BL4 P3V3
BL3 LAN2_LED_ACT_N
BL1 LAN1_LED_LINK1000_N
BL2 LAN2_LED_LINK2500_N
L16 3P3V_SFP2_T
L15 3P3V_SFP2_R
L14 GND
L13 2_SFP+_RD+
L12 2_SFP+_RD-
L11 GND
