- Page 1 QUICK START GUIDE WP-4 CLOUD-INTELLIGENT CCT | DIMMABLE OUTDOOR COMMERCIAL WALL PACK Powered by PoE + PoE Pass-Through poewit.com...
- Page 2 WALL PACK CONSUMES 40 WATTS OF POWER. IN ADDITION, IF USING THE TWO POE PASS-THROUGH PORTS, THE TOTAL POE BUDGET MUST BE SUFFICIENT TO POWER THE WP-4 AND THE TWO DEVICES USING THE POE PASS-THROUGH PORTS. NOTE, EACH POE PASS-THROUGH PORT CAN HANDLE UP TO 30 WATTS.
- Page 3 INSTALLATION AND SETUP e) Wire Connector poewit.com...
- Page 4 INSTALLATION AND SETUP 2) Installation and Setup a) Select the color temperature of the WP-4 LED (use table below for reference). Switch Position Color Temperature BRIDGE COOL WARM 3000k 4000k 5000k poewit.com...
- Page 5 INSTALLATION AND SETUP b) Separate the front and back housings by unscrewing the LED connector wire and lifting the front housing off the hinges. poewit.com...
- Page 6 The back housing can be mounted to a wall or standard electrical pancake box. Note, drill out only the necessary holes to mount the back housing. It is highly recommend to use silicon sealant on the drilled holes to prevent water ingress over time. poewit.com...
- Page 7 INSTALLATION AND SETUP d) Terminate and connect the CAT cables to the LED driver. e) Before installing the front housing, ensure the rubber water tight gasket is firmly seated. poewit.com...
- Page 8 INSTALLATION AND SETUP f) Connect the LED driver connector and hang the front to the back housing with the two screws (A hex tool is supplied / taped to the housing). poewit.com...
- Page 9 Power up device; you should be automatically connected to the internet. You are now ready to download and install your app. You can search PoEWit in the apple app store or Google Play to get the app Note: Your device and mobile phone both must have an internet connection through the same external IP address and must be on the same local subnet.
