- Page 1 QUICK START GUIDE OD-1 MODEL CLOUD INTELLIGENT OUTDOOR ARCHITECTURAL LED LIGHTS POWERED BY PoE poewit.com...
- Page 2 INSTALLATION AND SETUP WARNING - BEFORE INSTALLATION POEWIT POE POWERED ARCHITECTURAL LIGHTS CAN BE MOUNTED OUTDOORS, ON A WALL OR CEILING. THE LIGHT HOUSING IS WATER-RESISTANT; HOWEVER, THE ACCOMPANYING POE LED DRIVER IS NOT WATER-RESISTANT. THIS POE LED DRIVER IS DESIGNED TO BE SECURELY MOUNTED IN A LOCATION FREE OF MOISTURE, SUCH AS INSIDE THE CAVITY OF THE WALL.
- Page 3 BEFORE YOU START 1) PACKAGE CONTENTS Confirm that you have the package contents as follows: 1. OD-1 PoE Powered LED Flood Light 2. OD-1-PT PoE powered LED flood light with PoE pass-through 3. Hardware screw bag 4. Quick start guide PACKAGE...
- Page 4 See figure 1 Fig 1. 4. Insert category cable into PoE light driver and pull the light driver cable through the back mounting plate opening. Mount the back mounting plate to the wall with the three screws. See figure 2 poewit.com...
- Page 5 INSTALLATION AND SETUP Fig 2 5. Connect the light housing to the PoE driver wire. See figure 3 Fig 3 poewit.com...
- Page 6 INSTALLATION AND SETUP 6. Push the cable assembly into the wall cavity and secure the water tight grommet onto the back mounting plate. See figure 4 Fig 4 poewit.com...
- Page 7 INSTALLATION AND SETUP 7. Attach the Light Housing to the Back Mounting Plate and tighten the three screws. See figure 5 Fig 5 poewit.com...
- Page 8 Power up device; you should be automatically connected to the internet. You are now ready to download and install your app. You can search PoEWit in the apple app store or Google Play to get the app. Note: Your device and mobile phone both must have an internet connection through the same external IP address and must be on the same local subnet.
