- Page 1 QUICK START GUIDE INSTALLATION AND SETUP MD-2 CLOUD-INTELLIGENT INDOOR DUAL MOTION & LIGHT SENSOR POWERED BY PoE+ poewit.com poewit.com...
-
Page 2: Package Content
App-controlled Lux, Time, and Duration-adjusting functions allow the user to conveniently control conditions of motion detection. 2.2 Dimensions (See Fig 1-A and Fig 1-B) poewit.com... -
Page 3: Installation And Wiring
(26.24ft) in diameter with a 360-degree detection angle. 3.2 Installation Procedure a. Drill a hole with a diameter of 65mm (2.55”) on the ceiling sheet . rock. (See Fig 2) b. Connect a Cat Cable to the MD-2 PoE Driver poewit.com... - Page 4 INSTALLATION AND SETUP c. Insert the MD-2 PoE Driver into the drilled hole cavity d. Close two spring clips of detector and insert detector into the ..drilled hole 65mm - 2.55” Fig 2 Ø Ceiling board Drill a hole with a Ø...
- Page 5 Walk towards 9.84ft 13.12ft Walk across 26.24ft Height Walk Across Walk Towards Seated 2.0m 6.56ft 22.96ft 9.84ft 9.84ft 2.5m 8.20ft 26.24ft 13.12ft 9.84ft 3.0m 9.84ft 29.52ft 13.12ft 19.84ft 3.5m 11.48ft 32.80ft 13.12ft 6.56ft N/ a 4.0 m 13.12ft 13.12ft 13.12ft poewit.com...
- Page 6 - Avoid mounting the detector near heat sources (such as heating vents, air conditioners, lights, etc.) - Avoid aiming the detector towards objects which may sway in the wind (such as curtains, tall plants, etc.) (See Fig 5-A & 5-B) poewit.com...
- Page 7 INSTALLATION AND SETUP Fig 5-A Fig 5-B 4) SHIELD 4.1 Usage of Lens Shield The MD-2 has two (2) lens shields for masking the undesired detection area. (See Fig 6) Used Lens Shield Covered Detection Range None 26.24ft Small Segment 30º...
- Page 8 Part of the lens shield is used. Φ1m Φ3m Φ5m Φ8m 1m = 3.28ft | 3m = 9.84ft | 5m = 16.40ft | 8m = 26.24ft The shadow of the lens shield in Fig 6 represents the area excluded from detection. poewit.com...
-
Page 9: Configuration Instructions
5) CONFIGURATION INSTRUCTIONS Power on the device. You should automatically be connected to the Internet. You are now ready to download and install the PoEWit app. Seach “PoEWit” in the Apple App Store or Google Play. NOTE: Your device and mobile phone must both have an Internet connection through the same external IP address and must be on the same local subnet. -
Page 10: Troubleshooting
After initial configuration, a PoEWit wall switch and/or PoEWit motion detector PIR can control the lights should the Internet connection go down. 6) TROUBLESHOOTING When the MD-2 works abnormally, check the “problems and suggested solutions” table below. Problem Possible Cause...
