- Page 1 QUICK START GUIDE MD-1 MODEL CLOUD INTELLIGENT OUTDOOR DUAL MOTION AND LIGHT SENSOR POWERED BY POE+ poewit.com...
-
Page 2: Package Contents
OUTDOOR POE DUAL MOTION AND LIGHT SENSOR MD-1 | QUICK START BEFORE YOU START 1) PACKAGE CONTENTS Confirm that you have the package contents as follows: 1. PoE powered motion detector and light sensor 2. Lens shield label Outdoor Motion Detector... - Page 3 OUTDOOR POE DUAL MOTION AND LIGHT SENSOR MD-1 | QUICK START The MD-1 can be configured to trigger as many PoEWit lighting hardware as desired. The MD-1 is IOS and andriod app controlled; the user can adjust lux, time and sensitivity through the app.
-
Page 4: Installation And Wiring
OUTDOOR POE DUAL MOTION AND LIGHT SENSOR MD-1 | QUICK START FIG.1-A - Ceiling mount: 108 x 139.4 x 115.3mm (4.25 x 5.48 x 4.53 inch) Ceiling mount: 108 x 139.4 x 115.3mm 115.3 Fig 1b 3) INSTALLATION AND WIRING FIG.1-B... -
Page 5: Top View
OUTDOOR POE DUAL MOTION AND LIGHT SENSOR MD-1 | QUICK START Top view Side view 1. 5 12 m Fig 2 • Helpful tips for installation - The optimal installation location can be both indoor or outdoor; garden, corridor, staircase, entrance, garage, public lavatory, outdoor parking area, household and office, etc. - Page 6 OUTDOOR POE DUAL MOTION AND LIGHT SENSOR MD-1 | QUICK START - Since the detector responds to temperature change, please avoid the following conditions: 1) Avoid pointing the detector towards the objects whose surfaces are highly reflective, such as mirror, swimming pool, etc.
- Page 7 OUTDOOR POE DUAL MOTION AND LIGHT SENSOR MD-1 | QUICK START - Pay attention to the walking direction on the test proceeding (see fig 4) More sensitive to movement Less sensitive to movement across the detector directly towards the detector Fig 4 poewit.com...
-
Page 8: Installation Procedure
OUTDOOR POE DUAL MOTION AND LIGHT SENSOR MD-1 | QUICK START 4) INSTALLATION PROCEDURE • MD-1 can be mounted either on the wall or ceiling. • Feed the ethernet cable through the rubber gasket (Will need to terminate the RJ45 jack AFTER feeding the Cat5 cable... - Page 9 OUTDOOR POE DUAL MOTION AND LIGHT SENSOR MD-1 | QUICK START • Fix the detector head to the bottom cover and adjust the detector head to be in the right position (see fig 7a & 7b) Ceiling Mount Wall Mount Fig 7a Fig 7b • Detector head can be adjusted downward to max. 40° and upward to max. 90° vertically (see fig 8a) to shorten the detection...
- Page 10 OUTDOOR POE DUAL MOTION AND LIGHT SENSOR MD-1 | QUICK START Fig 8a Fig 8b 5) USAGE OF LENS SHIELD LABEL The attached lens shield label can be used to change the detection coverage. With the different layers of labels used, the different...
-
Page 11: Configuration Instructions
Power up the device and you should be automatically connected to the Internet. You are now ready to download and install our App. You can search PoEWit in the Apple App Store or Google Play to get the App. NOTE: Your device and mobile phone both must have an internet connection through the same external IP address and must be on the same local subnet. - Page 12 OUTDOOR POE DUAL MOTION AND LIGHT SENSOR MD-1 | QUICK START 7) WALK TEST NOTE: It takes approx. 60 sec for detector to warm up after power is supplied, then detector enters into normal operation mode to conduct a walk test.
- Page 13 OUTDOOR POE DUAL MOTION AND LIGHT SENSOR MD-1 | QUICK START The following conditions may cause lower sensitivity: • In very foggy days, the sensitivity may be less due to moisture collecting on the lens. • In very hot days, the sensitivity may be less since high ambient temperature is close to body temperature.
