Royal garden YJAF-038G-CAFE Use And Care Manual

10 ft x 12 ft square offset umbrella
Hide thumbs

Advertisement

Quick Links

Download this manual
Model # YJAF-038G-CAFE
Model # YJAF-038G-CHILI
USE AND CARE GUIDE
10 FT X 12 FT SQUARE OFFSET UMBRELLA
Questions, problems, missing parts? Before returning to the store
call Royal Garden Customer Service.
6 a.m. - 9 p.m., EST, 9 a.m. - 5 p.m., PST, Monday - Friday
(866) 988-3300
WWW.ROYALGARDEN.COM
THANK YOU
We appreciate the trust and con dence you have placed in Royal Garden through the purchase of this umbrella. We strive to continually create-
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Royal Garden!

Advertisement

loading
Need help?

Need help?

Do you have a question about the YJAF-038G-CAFE and is the answer not in the manual?

Questions and answers

Related Manuals for Royal garden YJAF-038G-CAFE

Summary of Contents for Royal garden YJAF-038G-CAFE

  • Page 1 THANK YOU We appreciate the trust and con dence you have placed in Royal Garden through the purchase of this umbrella. We strive to continually create- quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.

  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............2 Pre-Assembly................3 Safety Information ..............2 Planning Assembly..............3 Product Caution ..............2 Hardware Included..............3 Safety Warnings ..............2 Package Contents..............4 Warranty ..............Assembly.................5 What is Covered..............2 Operation................

  • Page 3: Pre-Assembly

    Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED : Hardware not shown to actual size. NOTE Part Description...

  • Page 4: Package Contents

    Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Lower bracket Upper bracket Lower umbrella pole Upper base cover Lower base cover Pedal Turn plate Side base Middle base Crank Umbrella shade...

  • Page 5: Assembly

    Assembly Pouring sand and water into the bases Open the side bases (H) and the middle bases (I) in the counterclockwise direction. Pour sand and water into the side bases (H) and the middle bases (I). Close the side bases (H) and the middle bases (I) in the clockwise direction. OPEN WATER SAND...
  • Page 6 Assembly (continued) Separating the lower umbrella pole from the umbrella shade Separate the lower umbrella pole (C) from the umbrella shade (K). WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance.
  • Page 7 Assembly (continued) Attaching the brackets Attach the upper bracket (B) onto the lower bracket (A). NOTE: This umbrella should be set up in its desired location to avoid moving it after assembly...
  • Page 8 Assembly (continued) Attaching the lower umbrella pole to the turn plate Attach the pedal (F) to the turn plate (H). Attach the turn plate (H) to the brackets (A & B) using M10x25 combination bolts (AA). Attach the lower umbrella pole (C) to the turn plate (H) using M10x22 combination bolts (BB) and the M10 hex wrench (FF). WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance.
  • Page 9 Assembly (continued) Attaching the middle bases to the brackets Attach the middle bases (I) onto the brackets (A & B).
  • Page 10 Assembly (continued) Attaching the side bases to the brackets Attach the side bases (H) to the bracket (A & B). WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance.
  • Page 11 Assembly (continued) Inserting the lower base cover and the upper base cover into the lower umbrella pole Insert the lower base cover (E) and the upper base cover (D) into the lower umbrella pole (C).
  • Page 12 Assembly (continued) Connecting the umbrella shade to the ower umbrella pole Connect the umbrella shade (K) to the lower umbrella pole (C) using M6x15 bolts (CC) and M6 hex wrench (EE). WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance.
  • Page 13 Assembly (continued) Attaching the crank to the umbrella shade Attach the crank (J) to the umbrella shade (K).

  • Page 14: Operation

    Operation (continued) Opening the umbrella Shake the umbrella fabric before opening the umbrella. Press the button on the umbrella shade (K) and slowly turn the crank (J) clockwise to open the umbrella. WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance.
  • Page 15 Operation (continued) Rotating the umbrella Hold the pedal (F) with one foot and rotate the umbrella pole (The umbrella can rotate up to 360 degrees).
  • Page 16 Operation (continued) Tilting the umbrella To tilt the umbrella, push the button located on the top of the umbrella shade (K). WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance.

  • Page 17: Care And Cleaning

    Operation (continued) Closing the umbrella Slowly turn the crank (J) in a counterclockwise direction to close the umbrella. Tie the umbrella to the umbrella pole with the Velcro belt when not in use, as shown below. Velcro Care and Cleaning For best results, clean the umbrella with damp cloth and dry thoroughly.
  • Page 18 Questions, problems, missing parts? Before returning to the store call Royal Garden Customer Service. 6 a.m. - 9 p.m., EST, 9 a.m. - 5 p.m., PST, Monday - Friday (866) 988-3300 WWW.ROYALGARDEN.COM Retain this manual for future use.

This manual is also suitable for:

Yjaf-038g-chili
