Model # YJAF-819C-CAFE
Model # YJAF-819C-CHILI
USE AND CARE GUIDE
10 FT X 10 FT SQUARE OFFSET UMBRELLA
Questions, problems, missing parts? Before returning to the store
call Royal Garden Customer Service.
6 a.m. - 9 p.m., EST, 9 a.m. - 5 p.m., PST, Monday - Friday
(866) 988-3300
WWW.ROYALGARDEN.COM
THANK YOU
We appreciate the trust and con dence you have placed in Royal Garden through the purchase of this umbrella. We strive to continually create quality products
designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Royal Garden!
Advertisement
Related Manuals for Royal garden YJAF-819C-CAFE
Summary of Contents for Royal garden YJAF-819C-CAFE
- Page 1 THANK YOU We appreciate the trust and con dence you have placed in Royal Garden through the purchase of this umbrella. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Pre-Assembly................3 Safety Information ..............2 Planning Assembly..............3 Product Caution ..............2 Hardware Included..............3 Safety Warnings ..............2 Package Contents..............4 Warranty ..............Assembly.................5 What is Covered..............2 Operation................ -
Page 3: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED : Hardware not shown to actual size. NOTE Part Description... -
Page 4: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Lower bracket Upper bracket Lower umbrella pole Middle umbrella pole Crank Umbrella shade Pedal Turnplate Side base Middle base Upper base cover Lower base cover... -
Page 5: Assembly
Assembly Attaching the brackets Attach the upper bracket (B) onto the lower bracket (A). WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance. - Page 6 Assembly (continued) Attaching the pedal to the turn plate Attach the pedal (G) to the turn plate (H) using M6x10 bolt (AA) and the M6 hex wrench (FF).
- Page 7 Assembly (continued) Attaching the middle umbrella pole to the lower umbrella pole Insert the middle umbrella pole (C) into the lower umbrella pole (D). WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance.
- Page 8 Assembly (continued) Attaching the turn plate to the brackets Attach the lower umbrella pole (D) to the turn plate (H) using M10x22 combination bolts (CC) and the M10 hex wrench (EE). Attach the turn plate (H) to the brackets (A & B) using M10x25 combination bolts (DD) and the M10 hex wrench (EE).
- Page 9 Assembly (continued) Pouring sand and water into the bases Open the side bases (I) and the middle bases (J) in the counterclockwise direction. Pour sand and water into the side bases (I) and the middle bases (J). Close the side bases (I) and the middle bases (J) in the clockwise direction. OPEN WATER SAND...
- Page 10 Assembly (continued) Attaching the middle bases to the brackets Attach the middle bases (J) onto the brackets (A & B).
- Page 11 Assembly (continued) Attaching the side bases to the brackets Attach the side bases (I) to the bracket (A & B). WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance.
- Page 12 Assembly (continued) Inserting the middle umbrella pole into the lower umbrella pole Insert the lower base cover (L) into the lower umbrella pole (D). Insert the upper base cover (K) into the lower umbrella pole (D). Insert the middle umbrella pole (C) into the lower umbrella pole (D).
- Page 13 Assembly (continued) Inserting the umbrella shade into the middle umbrella pole Insert the umbrella shade (F) into the middle umbrella pole (C) using one M6x15 bolt (BB). WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance.
- Page 14 Assembly (continued) Attaching the crank to the umbrella shade Attach the crank (E) to the umbrella shade (F). BUTTON...
-
Page 15: Operation
Operation Opening the umbrella Shake the umbrella fabric before opening the umbrella. Press the button on the umbrella shade (F) and slowly turn the crank (E) clockwise to open the umbrella. BUTTON WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance. - Page 16 Operation (continued) Rotating the umbrella Hold the pedal (G) with one foot and rotate the umbrella pole (The umbrella can rotate up to 360 degrees). 360°...
- Page 17 Operation (continued) Tilting the umbrella To tilt the umbrella, push the button located on the top of the umbrella shade (F). Button WWW.ROYALGARDEN.COM Please contact (866) 988-3300 for further assistance.
-
Page 18: Care And Cleaning
Operation (continued) Closing the umbrella Slowly turn the crank in a counterclockwise direction to close the umbrella. Tie the umbrella to the umbrella pole with the Velcro belt when not in use. Velvro Care and Cleaning For best results, clean the umbrella with damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate. - Page 19 Questions, problems, missing parts? Before returning to the store call Royal Garden Customer Service. 6 a.m. - 9 p.m., EST, 9 a.m. - 5 p.m., PST, Monday - Friday (866) 988-3300 WWW.ROYALGARDEN.COM Retain this manual for future use.
