  • Page 2 Outdoor Furniture 1-Year Limited Warranty Program For a period of one (1) year after purchase, the Manufacturer will either repair or replace defective components in accordance with this Limited Warranty. This warranty is between Manufacturer and the original purchaser and is valid only when accompanied by the original purchaser’s sales receipt showing original date of purchase and location of purchase.
  • Page 7 PARTS IDENTIFICATION LIST * NOTE: PARTS SHOWN ON PARTS LIST ARE NOT TO SCALE PARTS LIST DESCRIPTION ORDER PART # AT8575 TABLE TOP LEG CONNECTOR AT8576 BRACKET AT8577 TABLE LEG 1/4" X 20 MM BOLT HW0036 1/4" X 30 MM BOLT HW0038 Ø6.5 X 1.0 MM HW0004...
  • Page 8 ASSEMBLY INSTRUCTIONS Place the table top upside down on a flat, non-abrasive surface. Attach a table leg to the table top by igure using four 1/4"x20 mm bolts and washers as shown in the . Guide the bolts through the holes in the table leg, into the pre-drilled holes in the table top.
