- Page 1 High Performance Subwoofer DB12 Instruction Manual Thank you for your purchase of this Fluance product. Please read this manual carefully before using the product to ensure proper use. Keep this manual in a safe place for future reference. fluance.com...
- Page 2 Fluance believes everyone should experience audio in its truest form, recreating the performance the way the artist intended. Utilizing only superior components and expert audio engineering, their products are a testament to the performance that can be achieved when a passion for music takes center stage.
-
Page 3: Table Of Contents
Additional Settings ............................6 Volume Setting............................6 Crossover Setting ............................7 Auto Setting ..............................7 Phase Setting ............................... 7 FAQ ................................... 8 Troubleshooting ..............................9 Specifications ..............................10 Fluance Warranty ..............................11 Important Safety Instructions ........................12 FCC & IC Information ............................13... -
Page 4: What's Included
What’s Included • High Performance Subwoofer • Power Cable • Quick Start Guide • 2 Year Warranty • Lifetime Customer Support Back Panel Layout DB12 110Hz 80Hz 120Hz Speaker Inputs - Connect speaker wire to receive signal from home theater receiver. Speaker Outputs –... -
Page 5: First Time Setup
First Time Setup Step One Place the subwoofer in the most optimal position. Important! Fluance recommends having the woofer face the listener while being positioned near the front channel speakers in a corner if possible. Step Two Step Three Attach the subwoofer cable to either... -
Page 6: Step Four
Step Four Optional Steps Connect the power cable to the wall Attach speaker wire to the speaker outlet. Set the power switch to either inputs of the subwoofer. Attach same ON or AUTO. speaker wire to the channel outputs of your choice on the home theater receiver. -
Page 7: Crossover Setting
Crossover Setting The crossover setting can be adjusted with the Crossover knob located on the back panel of the subwoofer. The crossover setting changes the cut off frequency for the subwoofer. DB12 110Hz 80Hz 120Hz Auto Setting By selecting the AUTO setting, the subwoofer will automatically turn on when it detects a signal from the home theater receiver. -
Page 8: Faq
What is the purpose of the speaker wire inputs and outputs? The speaker wire inputs can be used as an alternative to connect your DB12 to your home theater receiver, however, Fluance recommends using the Low Level input connected via subwoofer cable. -
Page 9: Troubleshooting
Troubleshooting Issue Troubleshooting Steps • Ensure the subwoofer is plugged into a known good power source • Confirm that the subwoofer power switch is set to ON or AUTO No Power • Ensure the Power LED is lit • With the power cord removed ensure the fuse located next to the power input is intact and connected securely •... -
Page 10: Specifications
Specifications Specifications DB12 Front Firing Powered Subwoofer with Integrated Speaker Configuration Amplifier 12 Inch Long Throw Polypropylene with Rubber Low Frequency Driver Surround Amplifier Power Peak 400W / RMS 240W Low-Pass Crossover Range 40Hz – 180Hz 36Hz – 180Hz (+/- 3dB) Full Range Anechoic Measurement Frequency Response 34Hz –... -
Page 11: Fluance Warranty
Warranty Period The Fluance products listed below are warranted for parts and labor for the stated period from the date of original purchase and are subject to the terms and conditions of the warranty. -
Page 12: Important Safety Instructions
Important Safety Instructions WARNING: WA R N I N G TO REDUCE THE RISK OF FIRE OR ELECTRIC RISK OF ELECTRIC SHOCK DO NOT OPEN SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the CAUTION:... -
Page 13: Fcc & Ic Information
20. Do not attempt to clean this unit 22. When moving the apparatus, be sure with chemical solvents as this might to first disconnect the power cord. damage the finish. Use a clean 23. Use caution when wearing loose dry cloth. clothing or articles near the spinning 21. - Page 14 fluance.com...
