Owner’s Manual pages referenced in this guide. We strongly recommend that you read the Owner’s Manual for complete details on how to install, configure and operate the DPR 1001, as well as for the important safety information it contains.
Page 2
LINE IN/SUB/LFE SURROUND BACK SUBWOOFER RIGHT SPEAKER Step 2. Connect the speakers to the receiver: red (+) on speaker to colored (+) on receiver and black (–) to black (–). (See page 14.) Step 3. Connect the Subwoofer Pre-Out jack to the Line-In jack on your subwoofer (see page 14).
Page 3
Step 6. Plug all components into AC power outlets. The outlets on the back of the DPR 1001 should be used only for low-current products, such as CD or DVD players, and the total should not exceed 100 watts.
Page 4
Coax Device Connection Options : Recommended connections are shown in red, but connections may be made to best fit your system requirements. The Video 4, Coax 3 and Optical 3 inputs are on the front panel of the receiver. Device...
