CARE AND MAINTENANCE
Spot clean using a mild water-free solvent. Only a professional cleaner should undertake
a complete overall cleaning.
The use of steam or water-based cleaners may cause excessive shrinking or staining.
NOTICE
NOTICE
* Please make sure that you have all parts indicated before you begin assembly of this
item
* This item should be assembled on a soft surface to prevent scratching the finish during
assembly
y
* This item may require periodic tightening
Part List and Hardware List
PIECE
DESCRIPTIO N
1
Left corner sofa side
Left corner sofa seat
2
2
3
Left corner sofa back
Right corner sofa side
4
5
Right corner sofa seat
Right corner sofa back
6
7
Storage Base
8
Storage Short Side
Storage Long Side
9
10
Storage Top
Table Top
11
12
Table Side
13
Table Back Side
Table Base
14
15
Table Apron
A
Allen bolt(M6x30 mm)
Flat washer
B
C
Tapping screw(
￠
3x16 mm)
D
Gas spring
Allen key
E
Open end wrench
F
QUANTITY
1X
1X
1X
1X
1X
1X
1X
2X
2X
1X
1X
2X
1X
1X
1X
42X
42X
12X
2X
1X
1X
Model# PAT2513
Product Dimensions:
57.5" x 31.5" x 26" H (Sofa)
29" x 29" x 24.8" H (Storage)
22.8" x 22.8" x 16.1" H (Table)
WARNING
Weight Capacity: 550lbs(twoperson seat)
WARNING:DO NOT STAND ON CHAIR
1/5
