Congratulations on your latest furniture purchase! Dorel Living furniture has been developed with
quality, convenience and style in mind. We trust it will provide you with many years of exceptional
comfort and service.
Before beginning assembly, we encourage you to familiarize yourself with your new furniture piece by
taking a few minutes to go through this booklet. It contains important information on our warranty and
care tips to keep your furniture looking as good as new.
Customer satisfaction is important to us at Dorel Asia. Our agents are available Monday to Friday
8am to 5pm (EST) to answer any question you may have. For faster service, always have the model
number ready when calling our toll free number 1-800-295-1980 or emailing us at das@dorel.com .
For more great furniture ideas, check out our website at
You can also keep up to date on all the latest trends by liking our
Date of Purchase: _____ / _____ / _____
DO NOT RETURN PRODUCT TO THE STORE. If a part is missing or damaged, contact
our customer service department. We will replace the part FREE of charge.
NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
TWIN/FULL BUNK BED
Model Number:
DA6940BK
DA6940BL
DA6940E
DA6940W
www.dorelliving.com
UPC Code:
0-65857-17264-5
0-65857-17026-9
0-65857-16788-7
0-65857-16789-4
Facebook page.
Lot Number:
(taken from carton)
Color:
Black
Blue
Espresso
White

Advertisement

loading
Need help?

Need help?

Do you have a question about the DA6940BK and is the answer not in the manual?

Questions and answers

Related Manuals for Dorel Living DA6940BK

Summary of Contents for Dorel Living DA6940BK

  • Page 1 DA6940W 0-65857-16789-4 White Congratulations on your latest furniture purchase! Dorel Living furniture has been developed with quality, convenience and style in mind. We trust it will provide you with many years of exceptional comfort and service. Before beginning assembly, we encourage you to familiarize yourself with your new furniture piece by taking a few minutes to go through this booklet.
  • Page 2 CUSTOMER SERVICE If you are missing parts or have any questions about this product, contact our customer service representative first! CALL 1-800-295-1980 You can also order parts by writing to the address listed below. Please include the product model number, color and a detailed description of the part. Customer Service Department No.

  • Page 3: Care And Cleaning

    NOTES READ EACH STEP CAREFULLY BEFORE STARTING. IT IS VERY IMPORTANT THAT EACH STEP OF INSTRUCTION IS PERFORMED IN THE CORRECT ORDER. IF THESE STEPS ARE NOT FOLLOWED IN SEQUENCE, ASSEMBLY DIFFICULTIES WILL OCCUR AND CAN RESULT IN INJURY. CAUTION: ADULT ASSEMBLY REQUIRED. MAKE SURE ALL PARTS ARE INCLUDED.
  • Page 4 TWIN/FULL BUNK BED DA6940E (ESPRESSO) / DA6940W (WHITE) / DA6940BL(BLUE) / DA6940BK (BLACK)
  • Page 5 TWIN/FULL BUNK BED DA6940E (ESPRESSO) / DA6940W (WHITE) / DA6940BL(BLUE) / DA6940BK (BLACK)
  • Page 6 TWIN/FULL BUNK BED DA6940E (ESPRESSO) / DA6940W (WHITE) / DA6940BL(BLUE) / DA6940BK (BLACK)
  • Page 7 TWIN/FULL BUNK BED DA6940E (ESPRESSO) / DA6940W (WHITE) / DA6940BL(BLUE) / DA6940BK (BLACK)
  • Page 8 TWIN/FULL BUNK BED DA6940E (ESPRESSO) / DA6940W (WHITE) / DA6940BL(BLUE) / DA6940BK (BLACK) STEP 1 One of the headboard top crosses (F) has a label on it, do not use it in this step. Insert wood dowels (9) into the ends of headboard top cross (F), headboard bottom cross (G) and headboard center cross (R).
  • Page 9 TWIN/FULL BUNK BED DA6940E (ESPRESSO) / DA6940W (WHITE) / DA6940BL(BLUE) / DA6940BK (BLACK) STEP 2 Repeat the previous step to assemble the remaining three sets of headboards. Be sure to pair the bottom posts (D) and (E) for one pair; (E) and (D) for another; and the top posts (C) and (A) for the last pair.
  • Page 10 TWIN/FULL BUNK BED DA6940E (ESPRESSO) / DA6940W (WHITE) / DA6940BL(BLUE) / DA6940BK (BLACK) STEP 3 Insert barrel nuts (10 ) into bottom side rais (J) as shown. Attach the two headboards with bottom posts (D and E) to bottom side rails (J) using joint connectors (1) and Allen key (12).
  • Page 11 TWIN/FULL BUNK BED DA6940E (ESPRESSO) / DA6940W (WHITE) / DA6940BL(BLUE) / DA6940BK (BLACK) 14 PCS 3 PCS STEP 4 Attach the support posts (W) to bottom slats (Y) of the bottom bunk with hex socket head bolts (8) as shown.
  • Page 12 TWIN/FULL BUNK BED DA6940E (ESPRESSO) / DA6940W (WHITE) / DA6940BL(BLUE) / DA6940BK (BLACK) STEP 5 Insert wood dowels (9) into each end of the long guardrails (L). Insert barrel nuts (10) into top side rails (H & I). Attach two long guardrails (L) and two top side rails (H and I) to top posts (A and B) & (A and C) as shown using joint connectors (1) &...
  • Page 13 TWIN/FULL BUNK BED DA6940E (ESPRESSO) / DA6940W (WHITE) / DA6940BL(BLUE) / DA6940BK (BLACK) STEP 6 Insert the dowels (9) into each end of short guardrails (M). Attach the short guardrail post (S) and one guardrail leg (Q) to short guardrails (M) with wood joint connectors (3) and flat head...
  • Page 14 TWIN/FULL BUNK BED DA6940E (ESPRESSO) / DA6940W (WHITE) / DA6940BL(BLUE) / DA6940BK (BLACK) STEP 7 Attach the assembled short guardrail to top post (A) with wood joint connectors (3), and to top side rail (H) using hex socket head bolts (8) and hex caps (7) as shown. And use Allen key (12) to tighten the hex cap (7).
  • Page 15 TWIN/FULL BUNK BED DA6940E (ESPRESSO) / DA6940W (WHITE) / DA6940BL(BLUE) / DA6940BK (BLACK) STEP 8 Attach the other guardrail leg (Q) to long guardrails (L) and top side rail (I) with flat head wood screws (6). Secure the guardrail leg (Q) (done in step 6) to top side rail (H) with flat head wood screw (6) as shown.
  • Page 16 TWIN/FULL BUNK BED DA6940E (ESPRESSO) / DA6940W (WHITE) / DA6940BL(BLUE) / DA6940BK (BLACK) STEP 9 Insert wood dowels (9) into the ends of the ladder steps (P). Attach left ladder end (N) and right ladder end (O) to ladder steps (P) with wood joint...
  • Page 17 TWIN/FULL BUNK BED DA6940E (ESPRESSO) / DA6940W (WHITE) / DA6940BL(BLUE) / DA6940BK (BLACK) STEP 10 Attach the ladder to the top side rail (H) with flat head screw (11) as shown.
  • Page 18 TWIN/FULL BUNK BED DA6940E (ESPRESSO) / DA6940W (WHITE) / DA6940BL(BLUE) / DA6940BK (BLACK) Instructions for converting the bunk bed into two beds Full bed Single bed CONVERTING THE BUNK BED INTO A FULL BED AND A TWIN BED Remove the ladder and all the guardrails.
  • Page 19 TWIN/FULL BUNK BED DA6940E (ESPRESSO) / DA6940W (WHITE) / DA6940BL(BLUE) / DA6940BK (BLACK) CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury.

  • Page 20: Customer Service

    MODEL #: DA6940E (ESPRESSO) / DA6940W (WHITE) / DA6940BL(BLUE) / DA6940BK(BLACK) Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com...

This manual is also suitable for:

Da6940blDa6940eDa6940w0-65857-17264-50-65857-17026-90-65857-16788-7 ... Show all
