PRODUCT SPECIFICATION
802.11n, 2.4G 2T2R Wireless LAN USB Module
WN4627R
RT5372
Version 1.0
User Manual
* This document contains confidential proprietary information and is property of LTC. The contents of
this document should not be disclosed to unauthorized persons without the written consent of LTC
Page 1/13
