- Page 1 USER’S MANUAL 802.11b/g/n 2T2R Wireless LAN USB Module WN4646L ICM S.B.U. LITE-ON Technology Corporation 11F, 392, Ruey Kuang Road, Neihu, Taipei 11492, Taiwan, R.O.C. Page 1/9...
-
Page 2: Product Features
RODUCT EATURES Operate at ISM frequency Band (2.4GHz) IEEE Standards Support, 802.11b, 802.11g and 802.11n CMOS MAC, Baseband PHY, and RF in a single chip for IEEE 802.11b/g/n compatible WLAN Complete 802.11n MIMO solution for 2.4GHz band ... -
Page 3: Specifications
RODUCT PECIFICATIONS HIPSET Realtek RTL8192FC UNCTIONAL PECIFICATIONS Wi-Fi Function Standard IEEE802.11b; IEEE 802.11g; IEEE 802.11n Bus Interface USB 2.0 802.11b: 11, 5.5, 2, 1 Mbps 802.11g: Data Rate 54, 48, 36, 24, 18, 12, 9, 6 Mbps 802.11n: MCS 0 to 7 for HT20MHz MCS 0 to 7 for HT40MHz Media Access Control CSMA/CA with ACK... - Page 4 802.11n MCS0 MCS1 MCS2 MCS3 MCS4 HT40 Tgtpwr (dBm) MCS5 MCS6 MCS7 Receiver Sensitivity Frequency Rate Condition 1x1(1SS) Band (dBm) 11b-1M PER < 8% 11b-11M PER < 8% 11g-6M PER < 10% 11g-54M PER < 10% 2.4G 11n-HT20 MCS0 PER < 10% 11n-HT20 MCS7 PER <...
- Page 5 ECOMMENDED PERATION ONDITIONS Symbol Rating Units 5V Supply Voltage VDD33 3.3V I/O Supply Voltage VDD10 1.05V Core Supply Voltage 0.95 1.05 1.15 DC C HARACTERISTICS Symbol Parameter Units Input Low Voltage Input High Voltage Output Low Voltage 0.33 Output High Voltage 2.97 SPEC ESET...
-
Page 6: Pin Assignment
SSIGNMENT Pin. Pin Define Description Status +5VCC 5V source +5VCC 5V source USB_D- USB Data- USB_D+ USB Data+ Ground RESET# System reset RTL8192FC, low active WoWLAN# Wake up system via wi-fi, low active Ground Page 6/9... - Page 7 EEPROM I NFORMATION Worldwide Channels 1-13 with active scan Reg Domain 0x20 Vendor ID 0x0BDA 0xF192 Device ID NVIRONMENTAL PERATING Operating Temperature: 0 to 70 °C (32 to 158 °F) Relative Humidity: 5-90% (non-condensing) TORAGE Temperature: -25 to 75 °C (-13 to 167 °F) Relative Humidity: 5-95% (non-condensing) Page 7/9...
- Page 8 WARNINGS Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 9 Label of the end product: The host product must be labeled in a visible area with the following " Contains FCC ID: PPQ-WN4646L". The end product shall bear the following 15.19 statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
