M-Audio Code 49 Service Manual page 7

M-AUDIO MK43 (CODE 49) BOM LIST
Item Part No.
1 020495000
2 020558000
3 041184100
4 041196000
5 041237100
6 041471000
7 042558100
8 042559000
9 043459000
10 043495000
11 043558100
12 044559000
13 051559000
14 051559100
15 053219000
16 053498000
17 054496200
18 054496300
19 054498100
20 061219100
21 105-MK43-70
22 005003058
23 020252100
24 020317200
25 021232900
26 021252200
27 021497900
28 021498100
29 021558000
30 021558200
31 021558300
32 021558400
33 021558500
34 021558600
35 021558700
36 021558800
37 021559000
38 022558100
39 030558200
40 054497000
41 054558100
42 054558200
43 054559000
44 058498000
45 061252004
46 061359002
47 061496002
48 080252000
49 021252700
50 030252201
51 150004502
52 ALT 150004502A
WHITE KEY PROTECTION FILM 508# FOR LQV7 "ROHS"
LCD PROTECTION FILM REV:0.2 FOR MK42 "ROHS"
SERIAL NUMBER LABEL BLANK 63.5*12.5mm CHROME PAPER "ROHS"
BLANK LABEL 50x10mm "ROHS"
CARTON LABEL BLANK 76*50mm "ROHS"
GTIN14 LABEL 90*42mm "ROHS"
SAFETY MANUAL FOR MK42 "ROHS"
USER MANUAL FOR MK43 "ROHS"
OVERLAY PRINT 250G REV.A "ROHS"(ARTWORK REV.A)
LL9 CARD REV.A FOR LQV7 "ROHS"
SOFTWARE DOWNLOAD CARD FOR MK42 "ROHS"
COMPLIANCE STICKER 硝银珑 FOR MK43 "ROHS"
GIFT BOX FOR MK43 "ROHS"(ARTWORK REV.F)
OUTER CARTON FOR MK43 "ROHS"
PE BAG FOR INSTRUCTION 240 x 150mm "ROHS"
PE BAG 1000*360*0.04mm "ROHS"
LEFT EPE FOR LQV2 "ROHS"
RIGHT EPE FOR LQV2 "ROHS"
MIDDLE EPE FOR LQV4 "ROHS"
CABLE USB BLACK L=1500mm "HONGYUN" USB AM-USB BM "ROHS"
SUB FINAL ASSY FOR MK43 "ROHS"
3M DOUBLE TAPE 64.7*64.7*0.15mm "ROHS"
FOOT RUBBER Φ40*4mm FOR AD25 "ROHS"
FOOT RUBBER Φ40*3.5mm "ROHS"
POWER BUTTON ABS REV.A FOR AD03 "ROHS"
PUSH BUTTON_SMALLER ABS CLEAR FOR AD25 "ROHS"
16KEY HIGH-RESISTANCE CARBON FILM PET REV:1.2 FOR LQV6
"ROHS"
BOTTOM COVER FOR LQV4 "ROHS"
KNOB ABS FOR MK42 "ROHS"
20KEY RUBBER REV:0.3 FOR MK42 "ROHS" (ARTWORK REV.H)
1KEY LEFT BUTTON FOR MK42 "ROHS"
1KEY RIGHT BUTTON FOR MK42 "ROHS"
1KEY BLACK BUTTON FOR MK42 "ROHS"
LENS PMMA 85.7*26.9*1.2mm REV:0.5 "ROHS"
SLIDE BUTTON BLACK ABS FOR MK42 "ROHS"
XY PAD REV:0.4 FOR MK42 "ROHS"
TOP COVER FOR MK43 "ROHS"(ARTWORK REV.H)
16KEY PAD RUBBER REV:0.3 FOR MK42 "ROHS"
XY PAD BRACKET FOR MK42 "ROHS"
EVA BLACK 132*15*2.0mm FOR LQV6 "ROHS"
EVA A 20*14*0.5mm BLACK REV:0.1 FOR MK42 "ROHS"
EVA B 20*18*0.5mm BLACK REV:0.1 FOR MK42 "ROHS"
MUTE FOAM 687*8*8 REV:1.0 FOR MK43 "ROHS"
NON-WOVEN FABRICS 687*9*2mm 3M FOR LQV4 "ROHS"
CABLE UL1007 26AWG 6PIN P=2mm L=230mm W/1 CONNECTOR
"ZHUOZHI" ZZ-LJ-000247 "ROHS"
CABLE UL2468 24AWG 4PIN (DEL PIN NO.2,3) P=2.5mm L=324mm ONE
CONNECTOR "JIA FU" "ROHS"
CABLE FPC 10PIN L=150mm "SHENGPIN" 1.0*10P*150mm*A(4/4/8/8)
(0.035*0.65) "ROHS"
MOD WHEEL ASSY FOR AD25 "ROHS"
BASE PLASTIC BLACK ABS FOR AD25 "ROHS"
METAL BRACKET REV.B FOR AD25 "ROHS"
POT B MONO B5K L=20mm "FAVORSHINE" F16K-1044A "ROHS"
POT B MONO B5K L=20mm "SOUNDWELL" RD1610NOA0X-WA2-014
"ROHS"
Desc Qty Unit
0.80 M
1.00 EA
2.00 EA
1.00 EA
0.80 EA
0.40 EA
1.00 EA
1.00 EA
1.00 EA
1.00 EA
1.00 EA
1.00 EA
1.00 EA
0.20 EA
1.00 EA
1.00 EA
1.00 EA
1.00 EA
1.00 EA
1.00 EA
1.00 EA
1.00 EA
4.00 EA
4.00 EA
1.00 EA
14.00 EA
1.00 EA
1.00 EA
8.00 EA
1.00 EA
1.00 EA
1.00 EA
2.00 EA
1.00 EA
9.00 EA
1.00 EA
1.00 EA
1.00 EA
1.00 EA
4.00 EA
2.00 EA
1.00 EA
1.00 EA
1.00 EA
1.00 EA
1.00 EA
1.00 EA
1.00 EA
2.00 EA
2.00 EA
1.00 EA
0.00
