Rane ONE Service Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
This document contains sensitive proprietary information.
All recipients must have a current non-disclosure agreement on file
with Rane.
Do not make illegal copies of this document.
The information in this document contains privileged and confidential information. It is intended only for the use of
those authorized by Rane. If you are not the authorized, intended recipient, you are hereby notified that any review,
dissemination, distribution or duplication of this document is strictly prohibited. If you are not authorized, please
contact Rane and destroy all copies of this document. You may contact Rane at support@rane.com.
© Copyright Rane
Confidential
Rane
ONE
[NK49]
Service Manual
v1.0
ATTENTION!
Rane Service Manual

Advertisement

loading

Related Manuals for Rane ONE

Summary of Contents for Rane ONE

  • Page 1 The information in this document contains privileged and confidential information. It is intended only for the use of those authorized by Rane. If you are not the authorized, intended recipient, you are hereby notified that any review, dissemination, distribution or duplication of this document is strictly prohibited. If you are not authorized, please contact Rane and destroy all copies of this document.
  • Page 2 As the owner of the copyright to the Manual, Rane does not give you the right to copy the Manual, and you agree not to copy the Manual without the written authorization of Rane. Rane has no obligation to provide to you any correction of, or supplement to, the Manual, or any new or superseding version thereof.
  • Page 3 ALL REPAIRS DONE BY ANY ENTITY OTHER THAN AN AUTHORIZED RANE SERVICE CENTER SHALL BE SOLELY THE RESPONSIBILITY OF THAT ENTITY, AND RANE SHALL HAVE NO LIABILITY TO THAT ENTITY OR TO ANY OTHER PARTY FOR ANY REPAIRS BY THAT ENTITY.
  • Page 4 Power Cord Protection. AC power supply cords should be placed such that no one is likely to step on the cords and such that nothing will be placed on or against them.

  • Page 5: Specification

    SERVICE MANUAL MODEL:   SPECIFICATION FUNCTION 1. Line/PC - (3-way toggle switch) [MIDI] Channels: This selects playback audio to mix with. Audio in is always routed over USB directly to the computer from the input When in “PC 1” the audio will be routed from the software to the channel. This is for USB A host. “Line”...
  • Page 6 11. Channel PFL/Cue– (Tact switch w/Red LED) [MIDI] – Activates PFL for selected channel. Radio Style, Press and hold one PFL channel and pressing the other will turn both on. 12. UI Browser – plastic (360-degree Encoder and Push Switch) [MIDI]: A standard detented encoder with push switch is used to navigate through the software.

  • Page 7: Disassembly Procedures

    DISASSEMBLY PROCEDURES 1. REMOVAL OF TOP CABINET. (Fig.1) (A) REMOVE THE 28 CS KONB AND 2PCS ALUMI PLATTER AND 5PCS FADER CAP AND 26 PCS HEXAGON NUT AND 26 PCS WASHER BEFORE REMOVAL OF TOP CABINET. Fig.1 2.REMOVAL OF THE CROSS FADER . (Fig.2) (A) REMOVE THE 4 CS SCREWS BEFORE REMOVAL OF FIXED PLATE.
  • Page 8 3.REMOVAL OF THE FRONT PCB ASSEMBLY(SMT/DIP) AND RIHGT FRONT PCB DIP ASSEMBLY AND BOTTOM CHASSIS. (Fig.3) (A) REMOVE THE 44 CS SCREWS BEFORE REMOVAL OF BOTTOM CHASSIS. REMOVE THE 4 PCS SCREWS AND 2 PCS COPPER AND 3 PCS CONNECTOR BEFORE REMOVAL OF FRONT PCB(SMT/DIP) AND RIHGT FRONT PCB ASSEMBLY.
  • Page 9 5.REMOVAL OF THE DD MOTOR AND START/STOP PCB DIP ASSEMBLY AND TOGGLE SWITCH PCB DIP ASSEMBLY AND RIGHT PCB ASSEMBLY(SMT/DIP) AND LEFT PCB ASSEMBLY(DIP) AND RIHGT FRONT PCB DIP ASSEMBLY AND FSR PCB ASSEMBLY(SMT). (Fig.5) (A) REMOVE THE 8 PCS SCREWS AND 6 PCS WASHER AND 2 PCS WASHER EXTERNAL BEFORE REMOVAL OF DD MOTOR.
  • Page 13 NK49RAN01~04/07/0A BOM DESCRIPTION LEVEL 0.1 BAGL-55A CABLE CLIP 55L 0.1 CA040218004 USB 2.0 1.8M A/B Black CORE 0.1 CB310S129 Separate Wall 0.1 CN0100002505 Flat Cable GND Wire Y/G f4.3 0.1 CN0220001006 Flat Cable GND Wire Black Long 0.1 CN0239600802 Flat Cable Power Wire 2Pin Sin 0.1 CN0239601007 Flat Cable Power Wire 2Pin Sin 0.1 CN0620000802...

  • Page 14: Power Button

    0.1 NP212RAN89 Name Plate(right) 0.1 NP212RAN90 Name Plate(FX) 0.1 NP212RAN91 Front Name Plate 0.1 NP212RAN92 rear Name plate 0.1 NUT01030IID 0.1 NUT01090IIN Hexagon Nut 0.1 NUT0404IIZ FLANGE SCREW NUT 0.1 NUT05030ICU 0.1 OTD04144880G-00 DC FAN 40*40*20mm 24V 0.1 OTFSR5K Force Sensing Resistor 0.1 PNK49RAN01 Pack Assembly (01)(02)(03)(04)(07)(0A) ..2 BA-F100L-L2C...
  • Page 15 0.1 RU0730609 Rubber Foot 0.1 RU1210605 Rubber Button(PAD) 0.1 SC0306RIBI Screw M3X6 PPB 0.1 SC0306RINI Screw M3X6 PPN 0.1 SC0308FBBI Screw M3X8 PFB Tapping 0.1 SC0308FIBI Screw M3X8 PFB 0.1 SC0308PBBI Screw M3X8 PBB Tapping 0.1 SC0308PBNI Screw 0.1 SC0308WBNI Screw M3X8X 8 PPWN W/Washer T 0.1 SC0310FBBI Screw M3X10 PFB TAPPING...
  • Page 16 ..2 TWPC19C02701 Fader PCB Assembly ...3 TWPC19C02701M Fader PCB DIP Assembly ..4 TE591271001 Pin Header 180° Pitch:1.27mm (J1) ...3 TWPC19C02701T Fader PCB SMT/AI Assembly ..4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 14 C2,3,4,5,6,7,8,9,10,11,14,15,17,18 ..4 CS106K1003X5R CCAP SMD 10uF 10% 10V 0603 X5R C1,12,13,16 ..4 ICA1324LLHLX-T IC SENSOR HALL EFFECT...
  • Page 17 ..4 CS104K5005X7R CCAP SMD 0.1uF/50V 10% 0805 X7R C102,104 ..4 DISMBJ9.0CA DIODE P6SMB11CAT3 BRKDWN TVSC D100,101 ..4 FCN2T1000801 FCN Dual-Contact Vertical SMD J100 ..4 OTM21CC222R1H3 NETWORK EMI Suppression Filters 2200pF FIL100,101 ..4 RS010K10F03 RESISTOR 10K 1% SMD 0603 R102 ...3 TWPC19C014D01T Start/Stop PCB SMT/AI Assembly ..4 AL2-54-0138 Mos et BSS138 N-CH...
  • Page 18 ...3 SWVS6P001 Switch Slide 2P2T ...3 TE102251 Block(2P) (J15,17) ...3 TE612000202 Terminal 2P 2.0 180° (J18,33) ...3 TE613960201 Connector 2P 180 (J29,30) ...3 TE613960601 Connector 6P 180 (J32) ..2 TWPC19C01701T MAIN PCB Assembly(SMT) ...3 AL2-54-0138 Mos et BSS138 N-CH Q29,30,31 ...3 CS068C5002NPO CCAP SMD 6.8PF/50V ±0.25PF 0402 NPO C247,248...
  • Page 19 D3,4,8,9,15,16,20,21,23,24,25,27,51,52,53, ...3 DISMBJ9.0CA DIODE P6SMB11CAT3 BRKDWN TVSC ...3 ECS10616BLE ECAP 10UF/16V 4*5.7mm SMD Low C79,93,100,115,283,286,291,296 ...3 ECS10716DLE ECAP Low ESR 100uF/16V 6.3*5.5 C157 ...3 ECS10806FLE ECAP 1000UF/6.3V SMD Low ESR C87,92,108,113 ...3 ECS22735GLE ECAP LOW ESR 220UF/35V 10x10.3mm SMD 1 C273 ...3 ECS33716FLE ECAP 330uF/16V 8*10.2mm SMD LOW ESR 1...
  • Page 20 ...3 RS1K2410F03 RESISTOR 1.24K 1% SMD 0603 R103,135 R7,8,20,21,29,30,47,48,55,56,68,69,79,80,8 ...3 RS22R108F05 RESISTOR 22.1 1% SMD 0805 1,82 ...3 RS22R116F02 RESISTOR 22.1 1% SMD 0402 R258,259,260,261,265,266,318 ...3 RS23K710F03 RESISTOR 23.7K 1% SMD 0603 R289,294 ...3 RS2K2110F03 RESISTOR 2.21K 1% SMD 0603 R119,121,151,153,291,297 ...3 RS2K2116F02 RESISTOR 2.21K 1% SMD 0402...
  • Page 21 ..4 AL2-73-4051 IC74HC4051 Single 8-Chan Mux 1 U10,11,13 C12,13,14,15,16,17,18,27,28,29,30,31,32,4 ..4 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 3,44,45,46,47,48,49,50,67,72 ..4 CS102J5003NPO CCAP SMD 1nF/50V 5% 0603 NPO C1,2,3,4,5,6,7,8,9,11,19,20,21,22,23,24,25, 26,33,34,35,36,37,38,39,40,41,42,51,52,53, ..4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 54,55,56,57,58,59,60,61,62,63,64,65,66,68, 70,71,87,88,89,90 ..4 CS220J5003NPO CCAP SMD 22pF/50V 5% 0603 NPO 11 C76,77,78,79,80,81,82,83,84,85,86 ..4 CS226M3505X5R...
  • Page 22 ...3 TWPC19C018E01T Start/Stop PCB SMT/AI Assembly ..4 AL2-54-0138 Mos et BSS138 N-CH Q100,101,102 ..4 LD6703ARQHGRBYW Liquid-emitting Diode Red/Green/Blue SMD LED36,46 ..4 RS010K10F03 RESISTOR 10K 1% SMD 0603 R197,198,199 ..4 RS015010F03 RESISTOR 150 1% SMD 0603 R102,103,195,196 ..4 RS030110F03 RESISTOR 301 1% 1/10W 0603 R101,194 ..4 TE6A2000602 Pin Header 180°...
  • Page 23 ..2 RN042001 CS RING 0.1 TWMT321005801 Douser Process ..2 MT3210058 FIXED BASE ..2 MT3210069 DOUSER HOLDER ..2 NP632YAH105 DOUSER(900RPM) ..2 RN042501 FIXED RING (25MM) 0.1 WS109506205M Washer 0.1 WS663309IC Spring Washer 3# 0.1 TWPC18P00303 Motor PCB Assembly ..2 TWPC18P00303T MOTOR PCB SMD Assembly ...3 PC18P003 Motor PCB ...3 TWPC18P003A03T...
  • Page 24 ...3 TE612000402 Connector 4Pin P=2.0mm ...3 TE612000403 Connector(4P Socket) 180° ...3 TE613960201 Connector 2P 180 TE2,3 ...3 TE962541401 Connector14P ..2 TWPC18P003B01 Optical Encoder PCB Assembly ...3 CN0420000506 Flat Cable 4Pin Pitch 2.0mm Single Row ...3 DIHEDS-9700F50 Optical Encoder SEN1 ..2 TWPC18P003C01 Optical Encoder PCB Assembly ...3 CN0420001013 Flat Cable 4Pin Pitch 2.0mm Single Row...
  • Page 25 TO LEFT FRONT TO LEFT FRONT VDDA_1 VDDA_1 TP100 R100A R101A J100 CUE-MIX CUE-MIX CUE-GAIN CUE-GAIN 10KB 10KB C103 C105 VDDA_1 CUE-MIX 100pF 100pF CUE-GAIN TP105 VSSA_1 VSSA_1 VSSA_1 GND_1 SPLIT-Q-1 +3V3SW_1 TP101 NON-ZIF 1.0mm +3V3SW_1 TP106 R100B R101B 10KB 10KB 10KB 10KB...
  • Page 26 +3V3SW +3V3SW +3V3SW +3V3SW +3V3SW 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 74HC595 74HC595 74HC595 74HC595 74HC595 +3V3SW R-PAD-1 B-PAD-3 G-PAD-6 MODE-1R MODE-3B G-PAD-1 R-PAD-4 B-PAD-6 MODE-1G MODE-4R +3V3SW SCLR +3V3SW SCLR +3V3SW SCLR +3V3SW SCLR +3V3SW SCLR B-PAD-1 G-PAD-4 R-PAD-7 MODE-1B MODE-4G nLEDS-OE R-PAD-2...
  • Page 27 +3V3SW. J200 PLAY. R-PLAY. G-PLAY. B-PLAY. GND. +3V3SW. TO RIGHT-PLATTER PCB J4 LED200 R203 R204 Q200 R-PLAY. R205 BSS138 R200 10.0K GND. SW200 PLAY. G-PLAY. Q201 BSS138 START/STOP R201 10.0K LED201 R206 GND. R207 GND. R208 Q202 B-PLAY. BSS138 R202 10.0K GND.
  • Page 32 TO RIGHT FRONT TO RIGHT FRONT VDDA VDDA VDDA VDDA VDDA VDDA VDDA VDDA R11A M1-LEVEL M1-LEVEL M1_HI M1_HI M1_LO M1_LO M2-LEVEL M2-LEVEL M2_HI M2_HI M2_LO M2_LO CROSSFADER CROSSFADER DECK DECK 10KB 10KB 10KB 10KB 10KB 10KB 10KB 10KB 100pF 100pF 100pF 100pF...
  • Page 37 SW10 PAD-1 PAD-1 PAD-5 PAD-5 MODE-1 MODE-1 TACT CARBON TACT TACT CARBON SW11 MODE-1 PAD-2 PAD-2 PAD-6 PAD-6 MODE-2 MODE-2 PAD-1 TACT CARBON TACT CARBON MODE-2 TACT PAD-5 MODE-3 PAD-2 MODE-4 PAD-3 PAD-3 PAD-7 PAD-7 PAD-6 SW12 MODE-5 TACT CARBON TACT CARBON MODE-3 MODE-3...
  • Page 42 BAT54S MAX Line Input 4Vrms BAT54S AUX LEFT AUX RIGHT 2,200pF +8V0 -8V0 2,200pF +8V0 -8V0 P6SMB11CAT3G P6SMB11CAT3G 5.11K NJM4580M 5.11K NJM4580M U10A AUX_LEFT U10B AUX_RIGHT 220pF BOTTOM 220pF 5.11K 5.11K 220pF 220pF 5.11K 5.11K ESD GND must connect to earth GND via chassis bottom 5.11K 5.11K +8V0...
  • Page 43 2.00K 2.00K 330pF 330pF 4.02K BAT54S 4.02K BAT54S SLOT-1 AUX-L 90.9 22.1 ADC_1P 90.9 22.1 ADC_2P SLOT-2 AUX-R 4.02K 4.02K AUX_LEFT AUX_RIGHT MC33078 MC33078 SLOT-3 PH/LN-1L SLOT-4 PH/LN-1R 330pF 2.00K ADC1M 330pF 2.00K ADC2M SLOT-5 PH/LN-2L SLOT-6 PH/LN-2R ADC1P ADC2P 2,700pF 2,700pF +3V3...
  • Page 44 +3V3 U36 LP3990 2.5V +2V5 R207 2.49K +3V3 VOUT +3V3 AOUTA1_P R208 2.49K R209 C160 680pF C158 1uF, 16V 22uF C163 C197 0.22uF, 6.3V 3,300pF 6.6 VP-P 0.1uF DO NOT STUFF U22A MAIN LEFT AOUTA1_N R211 2.49K R212 0.1uF OSC_MCLK +8V0 C166 MC33078...
  • Page 45 +8V0 +8V0 C127 47pF 47pF C128 0.1uF 0.1uF R159 2.49K R160 2.49K MAIN BAL LEFT 2.49K 2.49K BOOTH BAL LEFT U15C U16C C129 R161 0.1uF NJM4580C R164 0.1uF NJM4580C U15A U16A R166 1.00K 820pF 1.00K 820pF C132 47pF 47pF -8V0 NJM4580C C131 11CAT3G...
  • Page 46 Output driver impedances can be adjusted One Cap per Pin +3V3 U33D MIMXRT1061DVL6B between 23 ohms and 157 ohms. +3V3 U33A MIMXRT1061DVL6B MCU_DCDC NVCC_SD0 SPI1_SCK GPIO_SD_B0_00 MOTOR_SCK DCDC_IN_1 DCDC_LP SPI1_CS0 GPIO_SD_B0_01 MOTOR1_CS# +3V3 U33B MIMXRT1061DVL6B 4.7uH DCDC_LP SPI1_SDO GPIO_SD_B0_02 MOTOR_MOSI...
  • Page 47 To Left Platter Motor To Right Platter Motor TP33 VNL0_ENC_R R296 VNL0_ENC_L R367 VNL1_ENC_R R368 TP10 VNL1_ENC_L R372 MOTOR2_CLK R259 22.1 TP12 MOTOR1_CLK R258 22.1 TP11 MOTOR2_SEL# R261 22.1 TP14 MOTOR1_SEL# R260 22.1 TP13 MOTOR2_MOSI R266 22.1 TP16 MOTOR1_MOSI R265 22.1 TP15 MOTOR2_MISO...

  • Page 48: Change Log

    R236 3.16K LM3704 R288 RESET 100K 5.1V C316 Vth=1.25V USB1_VBUS USB-A 0.0nH C317 R292 TYPE-B-2.0 0.1uF USB1_D_N 5.76K USB1_D_N USB1_D_P USB1_D2_N VBUS Delays +3.3V Buck turn-on 200ms USB1_D_P USB1_D1_N Allows +3.3V to fully discharge before restart USB1_D1_P USB1_D2_P Enables buck at 2.5V 90ohms@100MHz SHLD 90 ohms differential impedance between...
  • Page 55 +3V3SW +3V3SW +3V3SW +3V3SW +3V3SW +3V3SW 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 74HC595 74HC595 74HC595 74HC595 74HC595 74HC595 METER_OL_D1 METER_OL_D2 METER_OL_D3 METER_OL_D4 PFL_CUE_D1 FX PHASER METER_+6_D1 METER_+6_D2 METER_+6_D3 METER_+6_D4 PFL_CUE_D2 PADDLE_1_LED +3V3SW SCLR +3V3SW SCLR +3V3SW SCLR +3V3SW SCLR +3V3SW SCLR +3V3SW SCLR...
  • Page 56 74LVC125A U14A +3V3SW TO MAIN HOST SPI-CLK VDDA VDDA VDDA VDDA VDDA VDDA VDDA SPI-CLK-C 10KB 10KB DET 10KB DET 10KB DET 10KB DET 10KB 10KB 100uF LEVEL-1 HIGH-1 MID-1 LOW-1 FILTER-1 BOOTH FX-DEPTH 22pF U14B XF_SPI_MISO R200 74LVC125A XF_SPI_MOSI SPI-MOSI SPI-MOSI-C +3V3SW...
  • Page 57 +3V3SW +3V3SW +3V3SW +3V3SW +3V3SW 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 74HC595 74HC595 74HC595 74HC595 74HC595 R-PAD-1 B-PAD-3 G-PAD-6 MODE-1R MODE-3B +3V3SW G-PAD-1 R-PAD-4 B-PAD-6 MODE-1G MODE-4R +3V3SW SCLR +3V3SW SCLR +3V3SW SCLR +3V3SW SCLR +3V3SW SCLR B-PAD-1 G-PAD-4 R-PAD-7 MODE-1B MODE-4G nLEDS-OE R-PAD-2...
  • Page 58 +3V3SW. PLAY1 R-PLAY1 G-PLAY1 B-PLAY1 GND. +3V3SW. LED36 R101 R102 R-PLAY1 R103 Q100 BSS138 R197 10.0K GND. SW10 PLAY1 G-PLAY1 start/stop Q101 BSS138 R198 10.0K LED46 R194 GND. R195 GND. R196 B-PLAY1 Q102 BSS138 R199 10.0K GND. Title: Size Number Revision REV3 REV3_DATE...
  • Page 63 +3.3 SWD_IO SWD_CLK +5.0 +3.3 ON BACK SIDE LP3990 3.3V +5.0 VOUT +5.0 +3.3 0.1uF 0.1uF 10uF SPI0_SCK SPI0_MOSI +4.8 100k SPI0_MISO SPI0_SSEL *MOSI MOVED /RESET SIL SHROUDED 2.0mm +4.8F SPI0_SCK PIO0_0/ACMP_I1/TDO SPI0_MOSI 10uF 0.1uF PIO0_1/ACMP_I2/CLKIN/TDI SWDIO/PIO0_2/TMS HALL_A +5.0 +4.8 SWCLK/PIO0_3/TCK HALL_A 2.21k...
  • Page 68 0.1uF TPS54140 For MD991/MD992 /MD994 MOTOR +28V PC18P003B 101M ICAPL1117-33V +3.3V BOOT SEN1 For MD998 Control PCB Vout +5V-1 +3.3V COMP Vout TO TE1 TO CN1 FCN1 BA47CAT3 From Switchpower VSENSE AL2-51-0140 TO FUN PCB DC IN +28V PWRGD 74AHC245A 0.1uF 3.3uH 53.6K...
