PCB Piezotronics IMI SENSORS D643A01 Installation And Operating Manual page 16

Model Number
643A01
Performance
Measurement Range
Output
Frequency Range(± 10 %)
Broadband Resolution
Non-Linearity
Environmental
Temperature Range
Electrical
Excitation Voltage
Settling Time(within 2% of value)
Electrical Isolation(Case)
Physical
Size (Hex x Height)
Weight
Mounting Thread
Mounting Torque(Stud)
Mounting Torque(hex nut)
Sensing Element
Sensing Geometry
Housing Material
Sealing
Electrical Connector
Electrical Connection Position
Electrical Connections(Pin A)
Electrical Connections(Pin B)
[7]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Group, Inc.
4-20 MA OUTPUT VELOCITY SENSOR
ENGLISH SI
0.0 to 1.0 in/sec rms 0.0 to 25.4 mm/s rms
4-20 mA 4-20 mA
600 to 60,000 cpm 10 to 1 kHz
0.005 in/sec rms 0.13 mm/s rms
± 1 % ± 1 %
-40 to 185 °F -40 to 85 °C
12 to 30 VDC 12 to 30 VDC
<15 sec <15 sec
8 8
>10 Ohm >10 Ohm
7/8 in x 1.41 in 22.2 mm x 35.8 mm
3.8 oz 108 gm
1/4-28 UNF 1/4-28 UNF
3 to 4 ft-lb 4.1 to 5.4 Nm
2 to 3 ft-lb 2.7 to 4.1 Nm
Ceramic Ceramic
Shear Shear
Stainless Steel Stainless Steel
Welded Hermetic Welded Hermetic
2-Pin MIL-C-5015 2-Pin MIL-C-5015
Side Side
4-20 mA Pos (+) 4-20 mA Pos (+)
4-20 mA Neg (-) 4-20 mA Neg (-)
OPTIONAL VERSIONS
[1]
Optional versions have identical specifications and accessories as listed for the standard model
except where noted below. More than one option may be used.
[2][3]
[4]
EX
- Hazardous Area Approval- contact factory for specific approvals
Hazardous Area Approval DIV II, CL I, GRPS A-D, ExnL,
Hazardous Area Approval EEx ia IIC T4, -40°C≤Ta≤80°C,
Hazardous Area Approval EEx nL IIC T4, -40°C≤Ta≤80°C,
Hazardous Area Approval DIV I, CL I, II, III, GRPS A-G,
M
- Metric Mount
Supplied Accessory : Model M080A163A (1) replaces Model 080A162
[5][6]
RV
- Buffered Analog Signal Output - 100 mV/g (±20%)
Electrical Connector
Electrical Connections(Pin A)
Electrical Connections(Pin B) 4-20 mA Neg/Signal Output
Electrical Connections(Pin C)
NOTES:
[1]Conversion Factor 1 in/sec = 0.0254 m/sec.
[2]1Hz = 60 cpm (cycles per minute).
[3]Current will fluctuate at frequencies below 5 Hz.
[4]Typical value.
[5]1/8" hex Allen key required for English version, 3mm hex Allen key required for metric version.
[6]Stud torque must exceed sensor hex nut torque to ensure proper dismantling.
[7]See PCB Declaration of Conformance PS039 or PS053 for details.
SUPPLIED ACCESSORIES:
Model 080A162 Mounting Stud (1)
Model ICS-4 NIST-traceable single-axis amplitude response calibration from 0 cpm (0 Hz) to
upper 10% frequency for 4 - 20 mA output vibration sensor (1)
Entered: AP Engineer: DK
Date: 10/10/2014 Date: 10/10/2014
3425 Walden Avenue, Depew, NY 14043
Revision: C
ECN #: 43341
DIV II, CL I, GRPS A-D, ExnL,
AExnA, IIC T4 AExnA, IIC T4
EEx ia IIC T4, -40°C≤Ta≤80°C,
II 1 G II 1 G
EEx nL IIC T4, -40°C≤Ta≤80°C,
II 3 G II 3 G
DIV I, CL I, II, III, GRPS A-G,
Exia, AExia, IIC T4 Exia, AExia, IIC T4
3-Pin MIL-C-5015 3-Pin MIL-C-5015
4-20 mA Pos (+) 4-20 mA Pos (+)
4-20 mA Neg/Signal Output
Neg Neg
Signal Output Pos Signal Output Pos
