DITEC PASM24W1 User Manual

1 General information
Terminal block
Sensitivity potentiometer
2 Adjustments
1 1
Dip-Switch settings
PASM241
OFF
▼
ON
▲
PASM24W1
OFF
▼
ON
▲
2 2
The sensitivity settings determine the size of the sensing field
3 3
The lateral angle of the planar antenna determines the position of the sensing field
4 4
The vertical angle of the planar antenna determines the depht of the sensing field
UNIVERSAL MOTION SENSORS FOR AUTOMATIC DOORS
DIP SWITCH 1
Detection mode
Bidirectional mode
---
DIP SWITCH 1
Detection mode
Bidirectional mode
Unidirectional mode
MIDDLE
MAX
MIN
45°
30°
15°
0°
15° 30° 45°
PASM241-PASM24W1
DIP SWITCH 2
Relay configuration
Active output
Passive output
DIP SWITCH 2
Relay configuration
Active output
Unidirectional without MTF
Passive output
vertical angle: 30°, mounting height: 2.2m
2 1 0 1 2
1
15
30
2
45
3
USER'S GUIDE
LED
- flashes after power-on
- lights up during detection
Dip switch
Planar antenna
for wide detection field
DIP SWITCH 3
MTF-mode
---
---
DIP SWITCH 3
MTF-mode
Unidirectional with MTF
1
2
sensitivity : maximum
3
DIP SWITCH 4
Immunity
Normal immunity
Increased immunity
DIP SWITCH 4
Immunity
Normal immunity
Increased immunity
1/2
