Minolta MD 35mm f1.8 Disassembly Tutorial
Easy disassembly method for lens cleaning (mold removal)
Difficulty ★★☆☆☆
Things to prepare
• JIS cross-point precision screwdriver
• Rubber name-ring removal tool
• Kitchen rubber gloves
• Blower or compressed air
• Lens cleaning paper
• Lens cleaning liquid (lens cleaner)
The lens, with its dedicated lens hood.

Advertisement

loading
Need help?

Need help?

Do you have a question about the MD 35mm f1.8 and is the answer not in the manual?

Questions and answers

Summary of Contents for Minolta MD 35mm f1.8

  • Page 1 Minolta MD 35mm f1.8 Disassembly Tutorial Easy disassembly method for lens cleaning (mold removal) Difficulty ★★☆☆☆ Things to prepare • JIS cross-point precision screwdriver • Rubber name-ring removal tool • Kitchen rubber gloves • Blower or compressed air • Lens cleaning paper •...
  • Page 2 Step 1: Using the name-ring removal tool, loosen the ring with the Minolta inscription. Because the ring is wide, you may be able to remove with your fingers while wearing rubber gloves.
  • Page 3 With the name ring removed.
  • Page 4 Step 2: Remove the filter holder frame fixed with three screws from the inside.
  • Page 5 Step 3: Grab the front lens unit with rubber gloves and remove it by turning counterclockwise.
  • Page 6 Step 4: Turn the lens over and remove the rear cap.
  • Page 7 Step 5: If you remove the four screws on the lens mount, the lens mount will come off as a unit. Note! When the aperture ring is lifted, it will come off, but at this time the spring of the click stop will bounce and the tiny bearing will tend to go missing.
  • Page 8 Step 6: Grab the rear lens unit with rubber gloves and remove it by turning counterclockwise.
  • Page 9 Step 7: Clean with lens cleaner and paper. First, don't forget to blow off the dust with a blower!. The front and rear lens groups sandwiching the aperture are in a "unit structure" housed in a metal tube. The lenses facing the outsides of this unit are hard coated, so it is okay to clean them, but if you disassemble it, the lenses on the inside are soft and scratch easily.
  • Page 10 Optical diagram of the MD 35mm f1.8 lens.
