AV Link 122.416UK User Manual

A simple USB powered unit that converts analogue video signals from older devices with a Scart interface to high-
definition HDMI outputs. Simple to install and operate, this handy little device is ideal for use with VCR's, DVD players,
Games consoles, Freeview boxes etc when connecting to newer HDTV's or displays.

Technical Specifications and Features

Input
Output
Max. cable length
Max, working current
Operating temperature range
Power: input
Dimensions
Weight

Connection Instructions

• Using a Scart lead of the required length, connect one end to the input port of the converter and the other to the
output port on your source device (max length 8m).
•
Then Using a HDMI lead of the required length, connect one end to the output port of the converter and the
other to the input port on your HD display device (max length 7m).
www.avsl.com
Scart (PAL, NTSC3/4, 43 SECAM, PAL/M, PAL/N)
HDMI (720p, 1080p)
Scart input <=8m; HDMI output <=7m
350mA
-10° to 55°C
DC/5V 1A
88.5 x 57.5 x 25mm
60g
Scart to HDMI Converter
Item ref: 122.416UK
User Manual
