AV Link 122.417UK User Manual

A simple USB powered unit that converts high-definition HDMI video signals for use with older TV's and displays with an
analogue Scart interface. Simple to install and operate, this handy little device is ideal for use with Blu-Ray players,
games consoles, Sky HD boxes, laptops and more.

Technical Specifications and Features

Input
Output
Max. band width
Max. baud rate
Max. cable length
Max, working current
Operating temperature range
Power: input
Dimensions
Weight

Connection Instructions

• Using a HDMI lead of the required length, connect one end to the input port of the converter and the other to
the output port on your source device (max length 7m).
• Then Using a Scart lead of the required length, connect one end to the output port of the converter and the
other to the input port of your display device (max length 8m).
www.avsl.com
HDMI (up to v1.3 @ 60fps)
Scart (PAL/NTSC)
300MHz
10.2Gbps
HDMI Input <= 7m; Scart output <=8m
600mA
-10° to 55°C
DC/5V 1A
88.5 x 57.5 x 25mm
60g
HDMI to Scart Converter
Item ref: 122.417UK
User Manual
122.417UK User Manual
