LIGHT MY BRICKS LEGO GALAXY EXPLORER 10497 LIGHT KIT Installation Manual
  1. Manuals
  2. Brands
  3. LIGHT MY BRICKS Manuals
  4. Toy
  5. LEGO GALAXY EXPLORER 10497 LIGHT KIT
  6. Installation manual

LIGHT MY BRICKS LEGO GALAXY EXPLORER 10497 LIGHT KIT Installation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
LEGO
GALAXY EXPLORER #10497
®
LIGHT KIT
INSTALLATION GUIDE
