Ethereal HDM-CAT5A Setup Manual

Thank you for purchasing the Ethereal HDM-CAT5A (HDMI
The HDM-CAT5A converts a typical HDMI
affordable and reliable method of transmitting HDMI
HDTV Display in distant locations to any HDMI
interconnect cables. By way of digital equalization, the HDM-CAT5A can extend an HDMI
up to 100 feet using Category 5 cable and 150 feet using Category 6 cable.
Due to the problematic nature of the digital system having capacitive loading and Category 5/6 cable having similar issues,
a must feature added to the HDM-CAT5A is an HDCP RECOVERY SYSTEM. This unique serial data restorer is designed
to clean up and restore HDCP and EDID signals.
The HDM-CAT5A consists of one Cat5 balanced line transmitter with unique features of bandwidth and impedance
matching for long hauls and a separate balanced line receiver used on the opposite end of the system to restore the video
back to standard.
Going the distance for LESS no longer means you have to sacrifice reliability and affordability. The HDM-CAT5A will
deliver.
System Contents:
(1) HD Transmitter
Input – (1) HDMI ® Connector
Output – (2) RJ45 Connectors
(1) HD Receiver
Input – (2) RJ45 Connectors
Output – (1) HDMI ® Connector
(1) 1000 Ma 5V Power Supply
Features
▲
Designed for easy set-up & operation
▲
DVI Compatible
▲
Direct Coupled from input to output offering maximum video bandwidth
▲
Full Balanced line Differential Signaling
▲
Automatically Corrects HDCP and EDID data integrity
▲
®
Designed for HDMI , HDTV 480p, 720p, 1080i, 1080P
▲
Compatible with Computer Resolutions VGA, SVGA, XGA, SXGA, UXGA
▲
Available in wall plate - HDM-CAT5D
Must use included 5v 1000mA Power Supply included or warranty is voided. Please be aware that this is an electrical device.
Improperusage can cause fire, shock, and death. Consult a qualified installer orelectrician if you are unfamiliar
with electrical circuits. Be sure to turnOFF all power to these circuits during installation.
HDM-CAT5A
® to Cat 5/6 Converter
HDMI
SET UP GUIDE INFORMATIO N
®
to Cat5/6 Converter).
® cable system over to a double Category 5 or 6 cable system offering an
®
. This system offers installers and end users the ability to link a
® source without the labor associated with bulky and expensive HDMI
Illustration 1
Green - HP
CAUTION:
® 1080p signal over distances
A
B
Green - 5V Yellow - Clock Blue - Data
®
