Summary of Contents for Lanzar Vector VCT2020
- Page 1 36Watts 2 Channel High Power MOSFET Amplifier with Protection LED Indicator...
-
Page 2: Table Of Contents
You have purchased a quality product designed and engineered to give you many years of uncompromised musical service. Lanzar Vector ampli ers are designed with the lates technology available, which provides headroom for even the most demanding peaks and dynamic ranges found on modern CD's and recordings. -
Page 3: Features And Speci Cations
High Level Input: If your car stereo jacks are not RCA type output, use the high-low level input adaptor to connect the speaker output leads of car stereo and the RCA input jacks of amp. AUX Line Outputs: This amp features RCA jacks for AUX line outputs. Use these for unlimited system expansion to the next ampli er. www.Lanzar.com... - Page 4 MOSFET Power Supply Frequency Response: 15 Hz-30K Hz • Signal to Noise Ratio: >95dB • THD:0.1 % What's in the Box: • 2x20 Amp Maxi Type Fuse • 2-Channel High Power Ampli er • Dimensions: 10.63''W x 1.78''H x 7.48'' www.Lanzar.com...
- Page 5 Controls Power/protection LED Low level inputs Crossover frequency control AUX line inputs Crossover mode selector Input level control Bass boost selector Speaker connections Power Terminals Power fuse www.Lanzar.com...
-
Page 6: Electrical Connections
Electrical Connections 12V battery Head unit To remote turn-ON +12V Stereo/Mono Input Connections Using LOW Level Inputs L/R Audio Head unit Outputs www.Lanzar.com... - Page 7 Using HIGH Level Inputs Head unit High Level Another Input Adaptor Ampli er From speaker terminals Mono Input Connections Using LOW Level Inputs Head unit to a second ampli er Y Adaptors www.Lanzar.com...
-
Page 8: System Wiring Speaker Connections
Using HIGH Level Inputs Head unit High Level High Level Another Input Adaptor Input Adaptor Ampli er From speaker terminals System Wiring Speaker Connections Stereo Output Mode LEFT Speaker RIGHT Speaker 2-4 OHMS 2-4 OHMS www.Lanzar.com... -
Page 9: Mounting And Installation
Speaker Mounting and Installation Your new Lanzar Vector Ampli er comes complete with all required mounting hardware. When determining a suitable location in your vehicle for the amp, please remember that it is a high-power electronic device capable of generating high heat. - Page 10 About Power Fuses: Lanzar Vector ampli ers feature built-in fuse systems. These fuses protect both the ampli er and electrical system in your vehicle from fault conditions. If you ever need to replace the fuse in your ampli er, use a fuse of exactly the same type and rating.
-
Page 11: Protection Circuitry And Troubleshooting
Troubleshooting PROTECTION CIRCUITRY The built-in protection circuitry in the Lanzar Vector Series ampli ers will disable the ampli er if it senses an input overload, a speaker short circuit, or extreme temperature conditions. When the protection circuit is activated by any of these conditions the Protection LED will be illuminated. -
Page 12: Precautions
If you need to replace the power fuse, do so only with a fuse identital to that supplied with the ampli er. Using a fuse of a di erent type or rating may result in damage that isn’t covered in the manufacturer’s warranty. www.Lanzar.com... - Page 13 4-ohm load to each channel of the ampli er. two-channel ampli er will present a 2-ohm mono Most two-channel ampli ers will work well in this load to the ampli er. MOST TWO-CHANNEL AMPLIFIERS DO NOT SUPPORT con guration. 2-OHM MONO OPERATION! AMPLIFIER DAMAGE COULD RESULT! www.Lanzar.com...
- Page 14 Questions? Issues? We are here to help! Phone: (1) 718-535-1800 Email: support@lanzar.com...
