VOSS IKC670RF User Manual

Microwave combi-oven
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IKC670RF
USER
MANUAL
EN
User Manual
Microwave combi-oven

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IKC670RF and is the answer not in the manual?

Questions and answers

Related Manuals for VOSS IKC670RF

Summary of Contents for VOSS IKC670RF

  • Page 1 IKC670RF User Manual Microwave combi-oven USER MANUAL...

  • Page 2: Table Of Contents

    13. ENERGY EFFICIENCY..................35 DEAR CUSTOMER Thank you for choosing this Voss-Electrolux product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.
  • Page 4 Disconnect the appliance from the power supply • before carrying out any maintenance. If the mains power supply cable is damaged, it must • be replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons to avoid an electrical hazard.

  • Page 5: Safety Instructions

    ENGLISH warming pads, slippers, sponges, damp cloth and similar may lead to risk of injury, ignition or fire. If smoke is emitted, switch off or unplug the appliance • and keep the door closed in order to stifle any flames. Microwave heating of beverages can result in delayed •...
  • Page 6 • Before mounting the appliance, check • All electrical connections should be if the oven door opens without made by a qualified electrician. restraint. • The appliance must be earthed. • The appliance is equipped with an • Make sure that the parameters on the electric cooling system.
  • Page 7 ENGLISH • Do not change the specification of this • Always cook with the oven door appliance. closed. • Make sure that the ventilation • If the appliance is installed behind a openings are not blocked. furniture panel (e.g. a door) make •...
  • Page 8 • Concerning the lamp(s) inside this scratching: product and spare part lamps sold separately: These lamps are intended • Do not spill cold water or other liquids to withstand extreme physical on the glassware because a sudden...

  • Page 9: Product Description

    ENGLISH 3. PRODUCT DESCRIPTION 3.1 General overview Control panel Knob for the heating functions Display Control knob Heating element Microwave generator Lamp Rating plate Shelf support, removable Shelf positions 3.2 Accessories For cakes and biscuits. Microwave bottom glass plate Wire shelf To prepare food in microwave mode.

  • Page 10: Before First Use

    4.2 Sensor fields / Buttons To set the microwave function. Hold it for more than 3 sec‐ onds to turn on or turn off the oven lamp. You can turn on the light also when the oven is turned off.
  • Page 11 ENGLISH 6.3 How to set: Microwave Combi Step 1 Turn the knob for the heating functions to select a heating You can combine the microwave function function. with any of the heating functions. Step 2 Turn the control knob to select The oven can make noises when using the temperature / the micro‐...

  • Page 12: Clock Functions

    6.5 Heating functions Heating func‐ Application tion Heating func‐ Application tion To bake cakes with crispy bottom and to pre‐ The oven is off. serve food. Bottom Heat Off position To defrost food (vegeta‐ bles and fruit). The de‐...
  • Page 13 ENGLISH Clock function Application Combination of functions: Duration, End Time. Time Delay To set a countdown time. This function has no effect on the operation of the oven. Minute Minder Minute Minder - can be set at any time, also if the oven is off.
  • Page 14 7.4 How to set function: End Time Step 1 Set a heating function. Step 2 - press repeatedly. - starts to flash. Step 3 Turn the knob for the temperature to set the hour. - press to confirm. Step 4 Turn the knob for the temperature to set the minutes.

  • Page 15: Using The Accessories

    ENGLISH 7.6 How to set function: Minute Minder Minute minder can be both set when the oven is turned on and off. Step 1 - press repeatedly. , 00 - flash. Step 2 Turn the control knob for the temperature to set the seconds and than the mi‐ nutes.

  • Page 16: Additional Functions

    Baking tray: Push the tray between the guide bars of the shelf support. Wire shelf, Baking tray: Push the tray between the guide bars of the shelf support and the wire shelf on the guide bars above. Microwave bottom glass plate: Use the microwave bottom glass plate only with microwave function.

  • Page 17: Hints And Tips

    ENGLISH Loc appears on the display when you turn the control knob or press any button when the Function lock is on. When you (°C) turn the knob for the oven functions, the oven stops. 30 - 115 12.5 When you turn off the oven while the 120 - 195 Function Lock is on, the Function Lock switches automatically to the Child Lock.
  • Page 18 Put the spoon to the bottle or glass when After you turn off the oven, take the food heating drinks to ensure better heat out and let it stand for a few minutes to distribution. allow the heat distribute evenly.
  • Page 19 ENGLISH Cookware / Material Microwave function Microwave Combi function Defrost‐ Heating, Cooking Clingfilm Roasting film with microwave safe closure Roasting dishes made of metal, e.g. enamel, cast iron Baking tins, black lacquer or silicon- coated Baking tray Wire shelf Microwave glass bottom plate Cookware for microwave use, e.g.
  • Page 20 Baking results Possible cause Remedy The cake bakes un‐ The oven temperature is too Next time set a longer baking time evenly. high and the baking time is and lower oven temperature. too short. The cake batter is not even‐...
  • Page 21 ENGLISH CAKES / PASTRIES (°C) (min) Cake with crumble topping 150 - 160 20 - 40 Fruit flans (made of yeast dough / sponge cake mix‐ 150 - 160 35 - 55 ture), use a deep pan Fruit flans made of short pastry 160 - 170 40 - 80 Preheat the empty oven unless specified otherwise.
  • Page 22 BISCUITS (°C) (min) Biscuits made of yeast dough 150 - 160 20 - 40 Macaroons 100 - 120 30 - 50 Pastries made of egg white / Meringues 80 - 100 120 - 150 Preheat the empty oven. Use the second shelf position.
  • Page 23 ENGLISH 10.9 Roasting Turn the roast after 1/2 - 2/3 of the cooking time. Use the first shelf position. Roast meat and fish in large pieces (1 kg or more). Baste meat joints with their own juice several times during roasting. Use the function: Conventional Cooking.
  • Page 24 POUL‐ (kg) (°C) (min) Poultry, por‐ 0.2 - 0.25 each 200 200 - 220 20 - 35 tions Chicken, half 0.4 - 0.5 each 190 - 210 25 - 40 Chicken, pou‐ 1 - 1.5 190 - 210 60 - 80...
  • Page 25 ENGLISH PIZZA PIZZA (°C) (min) (°C) (min) Quiche lor‐ 170 - 190 45 - 55 Unleavened 10 - 20 raine / Swiss bread flan Puff pastry flan 160 - 180 45 - 55 Cheesecake 140 - 160 60 - 90 Flammkuchen 12 - 20 Apple pie, cov‐...
  • Page 26 FAST GRILL (min) (min) 1st side 2nd side Toast with topping 6 - 8 10.12 Bread Baking Preheating is not recommended. DEFROST‐ Use the second shelf position. (°C) (min) French fries, thin, 210 - 230 20 - 30 turn 2 or 3 times...
  • Page 27 ENGLISH Use the first shelf position. (kg) (min) (min) Defrosting time Further defrost‐ ing time Chicken 100 - 140 20 - 30 Turn halfway through. Meat 100 - 140 20 - 30 Turn halfway through. Trout 0.15 25 - 35 10 - 15 Strawberries 30 - 40...
  • Page 28 VEGETA‐ (min) (min) (°C) BLES Cooking Continue to Peppers 60 - 70 5 - 6 time until cook at simmering 100 °C Vegetables 60 - 70 5 - 6 for soup Carrots 50 - 60 5 - 10 Mushrooms...
  • Page 29 ENGLISH MEAT / FISH Set power for 100 W unless specified (kg) (min) Standing otherwise. time (min) Minced meat, set 200 W 7 - 8 5 - 10 Chicken 30 - 35 10 - 20 Chicken breast 0.15 5 - 9 10 - 15 Chicken legs 0.15...
  • Page 30 REHEATING (min) Standing time (min) Baby food in jars 0.2 kg 1 - 2 Baby milk, put a spoon into the bottle 180 ml 0:20 - 0:40 Milk 200 ml 1000 1 - 1:30 Water 200 ml 1000 1:30 - 2...
  • Page 31 ENGLISH Microwave Combi function Set the function: Grill + MW. (kg) (°C) (min) Standing time (min) Chicken, half, use 0.55 x Round glass the second shelf dish, Ø 26 cm position pieces Au gratin pota‐ Round glass toes, use the sec‐ dish ond shelf position Roast pork neck,...
  • Page 32 100 - 200 W Defrosting fruit and Defrosting cheese, Defrosting bread Defrosting meat, fish cakes cream, butter 10.19 Information for test institutes Tests according to IEC 60705. Use wire shelf unless otherwise specified. MICROWAVE FUNCTION (kg) (min) Sponge cake 0.475...

  • Page 33: Care And Cleaning

    ENGLISH Use the wire shelf. MICRO‐ WAVE COMBI (°C) (min) FUNC‐ TION Chicken, Grill + MW 45 - 55 Put the meat in 1.1 kg round glass con‐ tainer and turn it upside down after 20 minutes of the cooking time. 11.

  • Page 34: Troubleshooting

    Step 1 Turn off the oven and wait until it is cold. Step 2 Carefully pull the shelf sup‐ ports up and out of the front catch. Step 3 Pull the front end of the shelf support away from the side wall.

  • Page 35: Energy Efficiency

    ENGLISH The oven does not turn on or Error codes does not heat up The display Check if... The oven does not The automatic shows... heat up. switch-off is deacti‐ 12:00 There was a power vated. cut. Set the time of The oven does not The fuse is blown.
  • Page 36 Use the residual heat to warm up other earlier in some oven functions. dishes. The fan and lamp continue to operate. Keep food warm When you turn off the oven, the display Choose the lowest possible temperature shows the residual heat.
  • Page 40 www.voss.dk...
