Yongnuo YN360S User Manual

Thank you for using the YN360S
LED video light. Please read the
manual carefully and keep this
user manual properly for
reference.
1.The YN360S adopts 148 LED lamp beads,
large viewing angle,combined with super
long lamp board lighting angle, which is
more natural,wider and suitable for stereo
and wide-angle lighting.
2.The YN360S adopts high display index
LED lamp beads,the RA is higher than 95,
which is close to natural light,makes the
color restore truly and naturally.
3.Supports the mobile APP remote control
the video light,which is more convenient to
remote adjust the brightness of the video
light.
4.The YN360S adopts YONGNUO exclusive
LED constant current drive technology,
definitely not appear the corrugated,
stroboscopic and other negative phenomena
when shooting.
5.The YN360S adopts dual LED digital
display screen, the power output will be
more intuition.
6.Double power supply modes,support NP-F
series lithium batteries and 12V2A DC
power supply.
7.Brand new key dimming mode,Coarse/Fine
adjustment integrated, which is easier for
operation..
1.Please use the video light in the ventilated
environment.
2.Do not disassemble the product,
maintenance or repair of this product
should be carried through by technical
maintenance personnel of our company or
technical maintenance personnel authorized.
3.Do not use this product in flammable and
explosive place, or where it can be exposed
to moisture.
4.Please keep this product away from the
children.
148 LED lamp beads
3200K-5500K
1406LM
320G
12V 2A DC power supply
465*64*35mm
1.Battery slot
2.Battery lock
3.3200k brightness
increase button
4.3200k brightness
decrease button
5.LED digital
display screen
6.power switch
7.5500K brightness
increase button
8.5500K brightness
decrease button
9.DC power jack
1.Battery Installation
a. When the lithium battery is mounted , the battery
is mounted to a card groove according to the arrow
direction.
NOTE: It's recommended to use YONGNUO
NP-F750 battery to get a more lasting shooting
experience. The battery capacity of YONGNUO
NP-F750 reaches up to 5200mAh. When YN360S is
set to the maximum luminous intensity, it will keep
working about 150 minutes. Please take the batteries
out when this video light is not used.
b. When removing the lithium batteries, please
press the battery lock and then taake out the
lithium batteries.
2.External power supply
It is recommended to use YONGNUO power
adapter with YN360S to obtain lasting service time.
When using external power supply, the video light
will stop the battery power supply automatically and
will not get the battery charged. The
external power supply inter face outside is
positive and the interface inside is negative.
The input voltage is 12V and the electric
current is 2A.Note:If YN360S defective
when it is used with power adapter of other
brands, YN360S will no longer be
guaranteed for repair.
1.Startup &Shutdown and Brightness Adjustment
First install the battery or insert DC power, then
switch the power switch, the LED video light is lit,
press the 5500K and 3200K brightness adjustment
button, adjust the brightness of the video light.
2.Electric Quantity Test
Hold the left or right 5500k brightness increase
and decrease button for electric quantity test,
the LED screen will display the value of electric
quantity.The value of electric quantity will be
shown as P0-P9,which means 0%-90% of the
electric quantity,the electric quantity as the
picture shown is 30%.
(Note: The battery remaining capacity tested
when the luminous intensity is low will be
different from the battery remaining capacity
tested when the luminous intensity is high. The
battery capacity tested is how long the service
time of YN600 Air will last under the current
luminous intensity.)
8.Mobile APP Remote Control
The product supports mobile remote control ,
the APP can be downloaded from the
YONGNUO official website or download
through scanning the two-dimension code on
the gift box, Moible phone APP will be updated
continuously. Please pay attention to
YONGNUO official website for latest version
of APP to get better remote control experience.
(The YN360S is just support the mobile remote
control single video light,but not supports
YONGNUO LED wireless control system).
The remote
control distance
is within15 meters
