Summary of Contents for Salora 28HSW5012
- Page 1 GEBRUIKSAANWIJZING BEDIENUNGSANLEITUNG OPERATING INSTRUCTIONS MODE D'EMPLOI 28HSW5012 KLEURENTELEVISIE MET AFSTANDSBEDIENING FARBFERNSEHGERÄT MIT FERNBEDIENUNG COLOUR TELEVISION WITH REMOTE CONTROL TELEVISEUR COULEUR A TELECOMMANDE...
- Page 2 50405193...
-
Page 3: Table Of Contents
Contents Safety Information ..........63 Markings on the Product........63 Environmental Information........64 Features ...............65 Accessories Included..........65 Standby Notifications ..........65 TV Control Switch & Operation......66 Inserting the Batteries into the Remote ....66 Connect Power ............66 Antenna Connection ..........66 Notification ............66 Remote Control ............69 Connections............70 Switching On/Off ...........71 First Time Installation..........71... -
Page 4: Safety Information
• Do not place any heat sources such as electric Safety Information heaters, radiators, etc. near the TV set. • Do not place the TV on the floor and inclined CAUTION surfaces. • To avoid danger of suffocation, keep plastic bags RISK OF ELECTRIC SHOCK DO NOT OPEN out of the reach of the babies, children and domestic... -
Page 5: Environmental Information
WARNING WALL MOUNTING WARNINGS Do not ingest the battery, Chemical Burn Hazard This product or the accessories supplied with the • Read the instructions before mounting your TV product may contain a coin/button cell battery. If the on the wall. coin/button cell battery is swallowed, it can cause •... -
Page 6: Features
If the TV is on and it isn’t being operated for a while Note: Screen Off option is not available if the Mode is set to Game. it will go into standby. When you next switch-on, the following message will be displayed. “TV switched to When the TV is not in use, please switch off or stand-by mode automatically because no operation... -
Page 7: Tv Control Switch & Operation
Changing Channels and Volume TV Control Switch & Operation You can change the channel and adjust the volume by using the Volume +/- and Programme +/- buttons on the remote. Inserting the Batteries into the Remote Lift the cover on the back of the remote gently. Insert two AAA batteries. - Page 8 uses PlayReady technology to access PlayReady- Specification protected content and/or WMDRM-protected content. If the device fails to properly enforce restrictions on PAL BG/DK/II’ TV Broadcasting content usage, content owners may require Microsoft SECAM BG/DK to revoke the device’s ability to consume PlayReady- VHF (BAND I/III) - UHF protected content.
- Page 9 Wireless LAN Transmitter Specifications Max Output Frequency Ranges Power 2400 - 2483,5 MHz (CH1-CH13) < 100 mW 5150 - 5250 MHz (CH36 - CH48) < 200 mW 5250 - 5350 MHz (CH52 - CH64) < 200 mW 5470 - 5725 MHz (CH100 - CH140) <...
-
Page 10: Remote Control
Remote Control Source: Shows all available broadcast and content sources Netflix: Launches the Netflix application. YouTube: Launches the YouTube application. Play: Starts to play selected media No function Rapid reverse: Moves frames backwards in media such as movies Language: Switches between sound modes (analogue TV), displays and changes audio/subtitle language (digital TV, where available) Red button... -
Page 11: Connections
Connections NOTE: When connecting a device via the YPbPr or Side Connector Type Cables Device AV input, you must use the Scart connection cables to enable Connection connection. See the illustrations (back) on the left side. | You can use YPbPr to VGA cable to enable YPbPr signal via VGA input. -
Page 12: Switching On/Off
channels of it will be listed on the top of the Channel Switching On/Off List. When finished, press OK to continue. To Switch the TV On You can activate Store Mode option at this point. Connect the power cord to a power source such as a This option will configure your TV’s settings for store wall socket (220-240V AC, 50 Hz). -
Page 13: Media Browser Menu
You can use USB hubs with your TV’s USB inputs. To terminate this operation and control the TV via External power supplied USB hubs are recommended the remote again, press Quick Menu button on the in such a case. remote, highlight the CEC RC Passthrough and set as Off by pressing Left or Right button. - Page 14 TV Menu Contents System - Picture Menu Contents You can change the picture mode to suit your preference or requirements. Picture mode can Mode be set to one of these options: Cinema, Game(optional), Sports, Dynamic and Natural. Contrast Adjusts the light and dark values on the screen. Brightness Adjusts the brightness values on the screen.
- Page 15 System - Sound Menu Contents Volume Adjusts the volume level. Equalizer Selects the equalizer mode. Custom settings can be made only when in User mode. Balance Adjusts whether the sound comes from the left or right speaker. Sets headphone volume. Headphone Please ensure before using headphones that the headphone volume is set to a low level, to prevent damage to your hearing.
- Page 16 System - Settings Menu Contents Conditional Access Controls conditional access modules when available. Language You may set a different language depending on the broadcaster and the country. Enter correct password to change parental settings. You can easily adjust Menu Lock, Maturity Lock, Child Lock or Guidance in this menu. You can also set a new PIN or change the Default CICAM PIN using the related options.
- Page 17 This setting configures the power up mode preference. Last State and Standby Power Up Mode options are available. Virtual Remote Enable or disable the virtual remote feature. With this setting you can enable and disable CEC functionality completely. Press Left or Right button to enable or disable the feature.
-
Page 18: General Tv Operation
Child Lock: If this option is set to ON, the TV can only General TV Operation be controlled by the remote control. In this case the Using the Channel List control buttons on the TV will not work. The TV sorts all stored stations in the Channel List. Internet Lock: If this option is set to ON, the open You can edit this channel list, set favourites or set browser application in the portal will be disabled. -
Page 19: Teletext Services
Options (OK button): Displays event options. TV by pressing the OK to continue with the reboot operation. Now/Next Schedule 3 AM search and upgrade mode Navigate (Directional buttons): Press the Directional buttons to navigate through the channels Your TV will search for new upgrades at 3:00 o’clock if and events. -
Page 20: Pc Input Typical Display Modes
PC Input Typical Display Modes AV and HDMI Signal Compatibility The following table is an illustration of some of the Source Supported Signals Available typical video display modes. Your TV may not support all resolutions. SECAM Index Resolution Frequency NTSC4.43 640x350 85Hz (SCART) -
Page 21: Supported Video File Formats For Usb Mode
Supported Video File Formats for USB Mode Extension Video Codec SPEC (Resolution) & Bit Rate .dat, vob MPEG1/2 1080P@30fps - 40 Mbps MPEG1/2, .mpg, .mpeg MPEG4 MPEG1/2, H.264, H.264: 1080Px2@30fps - 62.5 Mbps, 1080P@60fps - 62.5 Mbps MVC: .ts, .trp, .tp AVS, MVC 1080P@30fps - 62.5 Mbps Other: 1080P@30fps - 40Mbps .mp4, .mov,... -
Page 22: Supported Audio File Formats For Usb Mode
Supported Audio File Formats for USB Mode Extension Audio Codec Bit Rate Sample rate MPEG1/2 Layer1 32Kbps ~ 448Kbps .mp3, MPEG1/2 Layer2 8Kbps ~ 384Kbps 16KHz ~ 48KHz MPEG1/2 Layer3 8Kbps ~ 320Kbps MPEG1/2 Layer1 32Kbps ~ 448Kbps MPEG1/2 Layer2 8Kbps ~ 384Kbps 16KHz ~ 48KHz MPEG1/2 Layer3... -
Page 23: Supported Subtitle File Formats For Usb Mode
Extension Audio Codec Bit Rate Sample rate MPEG1/2 Layer1 32Kbps ~ 448Kbps MPEG1/2 Layer2 8Kbps ~ 384Kbps 16KHz ~ 48KHz MPEG1/2 Layer3 8Kbps ~ 320Kbps .wav LPCM 64Kbps ~ 1.5Mbps 8KHz ~ 48KHz IMA-ADPCM, 384Kbps 8KHz ~ 48KHz MS-ADPCM G711 A/mu-law 64Kbps ~ 128Kbps 8KHz MPEG1/2 Layer3... -
Page 24: Supported Dvi Resolutions
Supported DVI Resolutions When connecting devices to your TV’s connectors by using DVI converter cable(DVI to HDMI cable - not supplied), you can refer to the following resolution information. 56Hz 60Hz 66Hz 70Hz 72Hz 75Hz 640x400 þ 640x480 þ þ þ... - Page 25 and display the result when complete. Connectivity Advanced Settings Highlight Advanced Settings and press the OK Wired Connectivity button. On the next screen you can change the IP To Connect to a Wired Network and DNS settings of the TV. Highlight the desired one •...
- Page 26 • The location where the transmission is most effective • If the connection is established correctly, you will be differs depending on the usage environment. able to access the shared files from your mobile device via the Media Browser of your TV. •...
- Page 27 It is also possible that the connection may not be selection again. Or press the Blue button to switch to available due to a firewall problem. If you think next media type quickly without changing the network. this causes your problem, contact your internet Refer to the Media Browser menu section for further service provider.
- Page 28 8. Click the Install button. The installation begins Internet Portal and finishes automatically. A progress bar will HINT: A broadband internet connection is required indicate the state of the installation process. for high quality viewing. You must set the country 9.
- Page 29 Internet Browser All sites on the internet might not be supportted. According to the site; content problems may occur. To use the internet browser, enter the portal first. Then In some circumstances video contents might not be launch the Internet application on the portal. able to be played.
