- Page 1 BS709E 1/10 2WD EP BAJA 2 Wheel Drive Ball Differential Box 2 in 1 ESC & receiver Version Completely waterproof ,driving all weather Baja,Buggy ,Truggy,SC truck four different bodies Instruction Manual...
- Page 4 2.4GHz TRANSMITTER St Rev Switch ST REV SWITCH: Used to change steering orientation Steering Trim Knob: Turn to make truck drive straight when steering wheel is centered. Power Light: Indicates the transmitter is turned on. Power Switch: Turns transmitter on and off. Steering Wheel: Turn left to steer the vehicle Ieft.Turn right to steer the vehicle right.
- Page 5 BS709-082 BS701-075 BS709-052...
-
Page 6: Common Parts
COMMON PARTS BS709-022N Transverse drive shaft BS709-070 Gear box unit BS709-023 Gear box unit BS709-068 2pcs BS701-075 BS709-053 2.4G Transmitter... - Page 7 COMMON PARTS BS709-023 spur gear BS711-009 Fr.Brace BS709-056 USB charger BS709-082 Servo horn BS709-052 20T motor gear...
- Page 9 Federal Communications Commission (FCC) Statement. This device complies with part 15 of the FCC Rules. Operation is subject to the following twoconditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
- Page 10 BSD Racing http://www.bsdracing.com PRINTED IN CHINA NOT RESPONSIBLE FOR TYPOGRAPHICAL ERRORS...
