MODEL: HEH00582
SIDE X SIDE DELUXE
17' LADDERSTAND
• Always Wear a Safety Harness with this Product
• Practice Using at Ground Level
• Weight Limit: 300 lbs.
• Tree Size: 9"-18" diameter
Warning
Every year serious injury and even death occurs from hunting related falls. To ensure your safety, please COMPLETELY read and
follow this safety manual and ALL warning labels BEFORE assembling, installing or utilizing this product.
DO NOT USE THIS PRODUCT BEFORE FULLY UNDERSTANDING ALL SAFETY WARNINGS AND INSTRUCTIONS. IF YOU HAVE
QUESTIONS, ARE UNSURE ABOUT ANY INFORMATION OR NEED ADDITIONAL INFORMATION CONCERNING YOUR PRODUCT,
CONTACT OUR CUSTOMER SERVICE DEPARTMENT AT 1-866-972-6168 OR VISIT WWW.PRIMALVANTAGE.COM. KEEP AND
MAINTAIN THIS SAFETY AND INSTRUCTION MANUAL IN A SAFE LOCATION FOR FUTURE REFERENCE.
Distributed by Primal Vantage Company Inc. 685 Route 10 East, Randolph, NJ 07869
Instruction and Safety Manual
SAFETY MUST BE YOUR FIRST PRIORITY WITH THIS PRODUCT
G
O
M
J
H
E
L
X
Q
W
R
Y
V
U
N
E
C
D
F
I
K
P
A
B
©2013 (rev. 11/12)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COMFORT ZONE HEH00582 and is the answer not in the manual?

Questions and answers

Related Manuals for Primal Vantage COMFORT ZONE HEH00582

Summary of Contents for Primal Vantage COMFORT ZONE HEH00582

  • Page 1 CONTACT OUR CUSTOMER SERVICE DEPARTMENT AT 1-866-972-6168 OR VISIT WWW.PRIMALVANTAGE.COM. KEEP AND MAINTAIN THIS SAFETY AND INSTRUCTION MANUAL IN A SAFE LOCATION FOR FUTURE REFERENCE. ©2013 (rev. 11/12) Distributed by Primal Vantage Company Inc. 685 Route 10 East, Randolph, NJ 07869 SAFETY MUST BE YOUR FIRST PRIORITY WITH THIS PRODUCT...
  • Page 2 TREESTAND SAFETY WARNINGS Please read the following instruction manual and warnings labels completely before utilizing this product. Failure to understand and execute the instructions and warnings may result in serious injury or death. In the event of an accident, have a plan for rescue, including the use of devices that may be easily reached while suspended.
  • Page 3 TREESTAND SAFETY WARNINGS NEVER adjust your stand while in use. Practice the attachment of this treestand at ground level before using in a hunting environment. ALWAYS ensure that you and your treestand are safely secured to a healthy tree. Your tree stand MUST be attached tightly to the tree and secured in place. If the stand is not secure, it may shift while in use, resulting in serious injury or death.

  • Page 4: Proper Care And Maintenance

    • We recommend replacing all hardware/cables/nuts/bolts/clips on your tree stand every two (2) years or sooner if inspection finds it necessary. Use only Primal Vantage approved replacement straps and parts. Use of any other straps or parts, will be viewed as a modification to the product. Any modification will void the warranties and relieve Primal Vantage from all liabilities.

  • Page 5: Parts List

    Knob (2) Shooting Rail Adjuster (2) Ratchet Buckle Strap (2) Installation M10 Quickclip (4) Strap (1) Cross Strap (2) ©2013 (rev. 11/12) Distributed by Primal Vantage Company Inc. 685 Route 10 East, Randolph, NJ 07869 CUSTOMER SERVICE DEPARTMENT 1-866-972-6168 WWW.PRIMALVANTAGE.COM...
  • Page 6 Bolt on each side. NOTE: Handle Rails are interchangeable. The welded brace on each Handle Rail can be on either side. ©2013 (rev. 11/12) Distributed by Primal Vantage Company Inc. 685 Route 10 East, Randolph, NJ 07869 CUSTOMER SERVICE DEPARTMENT 1-866-972-6168 WWW.PRIMALVANTAGE.COM...
  • Page 7 INSIDE of Rear Brace using 1-M12x60mm Bolt. NOTE: The front of each Seat Support has a rubber pad on top of it. ©2013 (rev. 11/12) Distributed by Primal Vantage Company Inc. 685 Route 10 East, Randolph, NJ 07869 CUSTOMER SERVICE DEPARTMENT 1-866-972-6168 WWW.PRIMALVANTAGE.COM...
  • Page 8 Place a washer on bolt, insert the bolt through the bracket and through the bushing. Insert the last washer on the bolt and tighten the nut. ©2013 (rev. 11/12) Distributed by Primal Vantage Company Inc. 685 Route 10 East, Randolph, NJ 07869 CUSTOMER SERVICE DEPARTMENT 1-866-972-6168 WWW.PRIMALVANTAGE.COM...
  • Page 9 Handle Rails just in front of the Tree Brace using 1-M12x60mm Bolt on each side. ©2013 (rev. 11/12) Distributed by Primal Vantage Company Inc. 685 Route 10 East, Randolph, NJ 07869 CUSTOMER SERVICE DEPARTMENT 1-866-972-6168 WWW.PRIMALVANTAGE.COM...
  • Page 10 Continue through the Shooting Rail. Add the (See Left Side Closeup for Installation Order) last washer and tighten the nut. ©2013 (rev. 11/12) Distributed by Primal Vantage Company Inc. 685 Route 10 East, Randolph, NJ 07869 CUSTOMER SERVICE DEPARTMENT 1-866-972-6168 WWW.PRIMALVANTAGE.COM...
  • Page 11 1-M12x60mm Bolt. 15. Insert Top Ladder Section into each Yoke . Make sure that Step is behind the Yokes. ©2013 (rev. 11/12) Distributed by Primal Vantage Company Inc. 685 Route 10 East, Randolph, NJ 07869 CUSTOMER SERVICE DEPARTMENT 1-866-972-6168 WWW.PRIMALVANTAGE.COM...
  • Page 12 Rear Foot Platform using 1-M12x60mm Bolt. Attach opposite end of Platform Brace to the OUTSIDE of Top Ladder Section using 1-M12x60mm Bolt. ©2013 (rev. 11/12) Distributed by Primal Vantage Company Inc. 685 Route 10 East, Randolph, NJ 07869 CUSTOMER SERVICE DEPARTMENT 1-866-972-6168 WWW.PRIMALVANTAGE.COM...

  • Page 13: Rear View

    23. Follow Steps 20-22 above to attach the bottom section to the middle section. ©2013 (rev. 11/12) Distributed by Primal Vantage Company Inc. 685 Route 10 East, Randolph, NJ 07869 CUSTOMER SERVICE DEPARTMENT 1-866-972-6168 WWW.PRIMALVANTAGE.COM...

  • Page 14: Installation Instructions

    Stabilizer bar at the proper adjustment point to the tree. NOTE: Drawings are for illustration purposes only and may not depict actual product ©2013 (rev. 11/12) Distributed by Primal Vantage Company Inc. 685 Route 10 East, Randolph, NJ 07869 WWW.PRIMALVANTAGE.COM CUSTOMER SERVICE DEPARTMENT 1-866-972-6168...

  • Page 15: Strap Installation

    Pull slack to tighten. Press down on latch and insert strap underneath teeth as shown. Pull strap to desired length. ©2013 (rev. 11/12) Distributed by Primal Vantage Company Inc. 685 Route 10 Randolph, NJ 07869 CUSTOMER SERVICE DEPARTMENT 1-866-972-6168 WWW.PRIMALVANTAGE.COM...
  • Page 16 Failure to comply may result in stabilizer bar is not installed. serious injury or death. ©2013 (rev. 11/12) Distributed by Primal Vantage Company Inc. 685 Route 10 Randolph, NJ 07869 CUSTOMER SERVICE DEPARTMENT 1-866-972-6168 WWW.PRIMALVANTAGE.COM...
  • Page 17 Slot 2 with the teeth. WARNING DO NOT sit on seat platform until the ratchet and installation straps have been secured. ©2013 (rev. 01/13) Distributed by Primal Vantage Company Inc. 685 Route 10 Randolph, NJ 07869 CUSTOMER SERVICE DEPARTMENT 1-866-972-6168 WWW.PRIMALVANTAGE.COM...
