Unpacking Guide
LT-40C550
LT-40C551
Instruction Book
& Quick Start Guide
Accessories Pack
TV
TV Stand Support (L) x 1
TV Stand Base
TV Stand Support (R) x 1
Installing the Base Stand
1. Ensure the TV is switched off and not connected to the mains power supply.
2. Keep the protective bag on your TV, it will help to protect the TV. Lay the TV
down on a flat surface with the back side facing up, and ideally at the edge of
a table so that the base of the TV slightly overhangs on it. Please make sure
a soft cushioned material (such as a pillow or thick piece of foam) is placed
beneath the screen.
If you don't have a table big enough, you can use the TV box. Lie the box
flat, make sure you place the polystyrene back in the box first to give the
box some rigidity and strength.
3. Fit the stand support onto the stand base. Ensure the stand support marking
position is in right position (L = left, R = right). Align with the screw holes
then screw the support by using 4 screws A supplied.
Screw A x 2
TV Stand Support
TV Stand Support
(Left) (included)
(Right) (included)
TV Stand Base Front
(included)
2 people are required when unpacking your TV.
4. Rotate the stand assembly so the metal bar face to the front of the TV. Insert
the stand support under the bottom of the TV. The stand assembly will
fit snugly into the TV. Then screw the stand to the TV by using 4 screws B
supplied.
Table
Cushioned
Material
Protective
Bag
Screw A x 2
Screw B x 4
Don't lift the TV from the top
When you remove the TV from its box lie it flat.
Don't balance it on the sensor at the front of the TV.
Remove the Protective Bag
• Keep the protective bag on your TV until you have attached the stand and
positioned the TV.
• The LCD display is very fragile, and must be protected at all times when installing
and removing the base stand. Be sure that no hard or sharp object, or anything
that could scratch or damage the LCD display, comes into contact with it. DO NOT
exert pressure on the front of the TV at any time because the screen could crack.
MENU VOL - VOL + CH-
CH+
