SPECIFICATIONS
Product
Model
Cellular Module Model
Antenna Model
Bands
Localization
CAN
Digital Input
Digital Output
External Dimensions (W×H×D)
Weight
Case
Power Supply
Current Consumption
Storage Temperature Range
Operating Temperature Range
Operating Humidity Range
Vibration Resistance
Test Standard
Controller Mobile Communicator
u-blox AG
Taoglas Limited MA.110.C.AB.006.fh (Cable Length : 3m)
FCC-GSM 850/1900、CE-GSM 900/1800
FCC-UMTS 850/1700/1900、CE-UMTS 900/2100
GPS, SBAS, QZSS
150mm×32mm×127.8mm
DC12V (DC10～16V)
90m/s
・CE
This device complies with the R&TTE Directive (1999/5/EC)
issued by the Commission of the European Community.
EN301 908-1, EN301 511, EN300 440-2
EN301 489-1,EN301 489-3,EN301 489-7,EN301 489-24
EN60950-1
EN62209-2
・FCC
FCC Part22, FCC Part24
FCC Part15b
OET Bulletin 65 Supplement C
-1-
YSAR02-3G
LISA-U200
2-channel
6-channel
2-channel
0.32kg
PV resin
MAX 1A
-40℃～85℃
-30℃～65℃
95%(55℃)
2
(8.9G)10～500Hz
Advertisement
Table of Contents
Related Manuals for Yanmar YSAR02-3G
Summary of Contents for Yanmar YSAR02-3G
- Page 1 SPECIFICATIONS Product Controller Mobile Communicator Model YSAR02-3G Cellular Module Model u-blox AG LISA-U200 Antenna Model Taoglas Limited MA.110.C.AB.006.fh (Cable Length : 3m) FCC-GSM 850/1900、CE-GSM 900/1800 Bands FCC-UMTS 850/1700/1900、CE-UMTS 900/2100 Localization GPS, SBAS, QZSS 2-channel Digital Input 6-channel Digital Output 2-channel External Dimensions (W×H×D)
-
Page 2: Fcc Declaration Of Conformity
FCC DECLARATION OF CONFORMITY Product Controller Mobile Communicator Model YSAR02-3G Responsible Party YANMAR CO., LTD. Address 1600-4,Umegahara,Maibara,Shiga,Japan Telephone +81-749-52-8408 FCC STATEMENTS 1. Statement according to Part 15.105 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 3 3. Statement according to Part 15.21 Changes or modifications made to this equipment not expressly approved by YANMAR CO., LTD. may void the user's authorization to operate this equipment. 4. Statement according to RF Exposure Radiofrequency radiation exposure Information: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
-
Page 4: System Block Diagram
COMPONENTS SYSTEM BLOCK DIAGRAM GSM/UMTS and GNSS antenna (Multi Function antenna) GNSS GSM/UMTS antenna antenna connector connector COM board GNSS module Cellular module NEO-7N LISA-U200 MAIN board Power circuit , CPU, etc Interface connector Power supply , CAN , DI・DO... -
Page 5: External Dimensions
EXTERNAL DIMENSIONS 150mm 120mm 110mm *(127.8)mm 32mm * reference size. 1) GSM/UMTS antenna connecter 2) GNSS antenna connecter 3) Interface connecter (Power Supply , CAN , DI・DO) - Page 6 FIGURE OF THE INSTALLATION Antenna Equipment *1 Minimum distance of 2cm between the antenna and your body. *2 Minimum distance of 20cm between the antenna and your head. Installation of the antenna and this equipment will be different depending on each machine. NOTICE TO INSTALL Do not install this equipment to a place where it will receive strong vibrations, impacts , direct sunshine and rain.
- Page 7 FUNCTION OVERWIEW ABOUT INSTALL This equipment is installed to Products made by YANMAR. Ex) Agriculture, Construction, and Marine Machine, or Engine, etc. FUNCTION GNSS Satellite Mobile Communication Remote Center Machine Network (YANMAR) This equipment has some following functions. This equipment can collect the state of the operation machine.
