Summary of Contents for Clarke CHT876
- Page 1 SINGLE HAND RIVETER MODEL NO: CHT876 PART NO: 1801876 USER INSTRUCTIONS ORIGINAL INSTRUCTIONS GC05/22...
- Page 2 This guarantee does not effect your statutory rights. FITTING AND STORING THE NOZZLES The CHT876 rivet gun is equipped with a choice of 4 different size nozzles to suit different rivets. Choose the rivet to be used for the job.
- Page 3 OPERATION 1. When items are to be riveted together, the hole diameter must be nominally larger than the outer diameter of the rivet. Ensure that the hole is perpendicular with the surface of the workpiece components. 2. Insert the rivet into the hole of the workpiece components.
- Page 4 ADJUSTMENT If the internal claws of the rivet gun fail to grip the stem of the rivet, the mechanism will need adjusting. 1. Loosen the locking sleeve and rotate the nozzle clockwise to tighten (anti-clockwise to loosen). 2. Part the handles to extend the riveter and to tighten the internal claws.
