HCT HTV021TB Owner's Manual

21" full multi tv
Hide thumbs
Table of Contents

Advertisement

Quick Links

HTV-021TB
21" FULL MULTI TV
OWNER'S MANUAL
Please read this manual carefully
before using this TV set and keep it
for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HTV021TB and is the answer not in the manual?

Questions and answers

Related Manuals for HCT HTV021TB

Summary of Contents for HCT HTV021TB

  • Page 1 HTV-021TB 21" FULL MULTI TV OWNER'S MANUAL Please read this manual carefully before using this TV set and keep it for future reference.

  • Page 3: Table Of Contents

    Please read this manual carefully before using this TV set and keep it for future reference. CONTENTS Before Operation Warning and cautions...2 Important safety instructions...3 Installation...5 Aerial connection...5 Preparation of the remote control...5 Function buttons and external sockets...6 Front panel of the TV set...6 Rear panel of the TV set...6...

  • Page 4: Warning And Cautions

    Warning and cautions CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. DANGEROUS VOLTAGE Uninsulated Dangerous Voltage, that may be of sufficient magnitude to constitute a risk of electric shock, is present within the cabinet of this unit.

  • Page 5: Important Safety Instructions

    Important safety instructions READ INSTRUCTIONS All the safety and operating instructions should be read before the unit is operated. RETAIN INSTRUCTIONS The safety and operating instructions should be retained for future reference. HEED WARNINGS All warnings on the unit and in the operating instructions should be adhered to. FOLLOW INSTRUCTIONS All operating and use instructions should be followed.
  • Page 6 Important safety instructions (continued) 12. LIGHTNING To protect your unit from a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the unit due to lightning and power line surges.

  • Page 7: Installation

    Installation Aerial connection To connect the aerial, plug the aerial lead into the aerial socket on the rear of the unit. You can use an outdoor aerial. However, if you use an indoor aerial the quality of the reception may be reduced and adjustment of the aerial may be required when changing programmes.

  • Page 8: Function Buttons And External Sockets

    Function Buttons and External Sockets Front and side panel of the TV set MENU Volume up/ down AV TV (input selector Channel selector Note: Please do not use the S-Video input terminal and the video input terminal together. Back panel...

  • Page 9: Using The Remote Control

    11.TV/AV Button 12.Volume Button 13.TV Menu Button 14.(No including) 15.Channel Button TV Sound 17.Blue Button TV Picture Menu TV Sleep Time Menu 20.Teletext Mode/Swap Button 21.Time / Subcode 22.Index 23.Hold 24.Cancel 25.(No including) 26.Reveal 27.Enlarge 28.Teletext On / Off 29.Mix...

  • Page 10: Switching On/Off The Tv Set

    POWER MENU STANDBY Switching on/ off the TV set 1 To turn on the TV/AV, press the Power button on the front panel. 2 If the indicator is lighting in red, press the P+/P- button on the panel or control, the power indicator will become green.

  • Page 11: Searching Channels

    The unit can tune all the channels automatically. Auto Search MENU MENU MENU Automatic search 1 Press the TV MENU, until the TUNE menu display. 2 Press the P+/- buttons to select AUTO SEARCH. 3 Press V+ button to start auto search. The TV will begin memorizing all the channels available in your area.

  • Page 12: Search

    Searching Channels (continued) Search MENU MENU MENU MENU Search 1 Press the TV MENU, until the TUNE menu display. 2 Press the P+/- buttons to select PROGRAM, then press the V-/+ buttons to select the program number you want to store.

  • Page 13: Manual Fine Tune

    1Press the P+/- buttons or PROGRAM NUMBER 0-9 button to choose desired channels. 2 Press the TV MENU until the TUNE menu appears. 3 Press the P+/- buttons to select " FINE TUNE". 4 Press V-/+ buttons to adjust for the best possible picture and sound results.

  • Page 14: Program Exchange

    (continued) Exchange After auto search there may be some Program numbers duplicated and some blank. To re-order the channels: 1 Press the TV MENU until the PROG.EXCHANGE menu appears. 2 Press P+/- buttons to select PROG.I, then press the V+/- buttons to set desired program.

  • Page 15: Program Skip

    1 Press the P+/- buttons to select the desired program to be skipped. 2 Press the TV MENU until the TUNE menu appears. 3 Press the P+/- buttons to select "SKIP". 4 Press the V-/+ buttons to turn the SKIP function "ON".

  • Page 16: Watching Tv

    Watching TV You can watch TV program in a preset channel. Watching TV program MENU MENU MUTE SLEEP Select the desired program 1 Using "Program number" buttons Directly enter the program number with the numeric keypad on the remote control.

  • Page 17: Program Swap

    Watching TV (continued) Program Swap TXT MODE/SWAP Program swap Swap function enables quick swap to the last watched program. 1 Suppose the channel number you used just now is 8 and the channel number you are using is 18 (as shown in the figure).

  • Page 18: Convenient Picture Functions

    Convenient picture control functions Multiple picture modes 1 Press the TV MENU until the PICTURE menu MENU 2 Press the P+/- buttons to select MENU How to select picture modes You can quickly select the desired picture mode from three factory preset modes and one customized mode.

  • Page 19: Tv Set Up

    3. Press V-/+ buttons to toggle through on and off. Game 1. Press TV MENU until SETUP menu appears. 2. Press P+/- buttons to select GAME, then press V-/+ buttons to enter game. 3. Use MENU to rotate clockwise, P+ button to rotate anti-clockwise.

  • Page 20: Calendar

    Set up function TV Set Up MENU (continued) Calendar function Press TV MENU until SETUP menu appears. 2. Press P+/- buttons to select calendar. 3 Press the P+/- buttons to turn the YEAR/MONTH/DAY , press the V-/+ buttons to set or adjust the YEAR/MONTH/DAY .

  • Page 21: Teletext

    PRESS THE INDEX BUTTON TO GO TO THE INDEX PAGE OF TELETEXT. CANCEL PRESS ' ' BUTTON ALLOW YOU TO GO BACK TO THE TV MODE TEMPORARY. PRESS THE BUTTON TO RETURN TO THE TELETEXT. HOLD PRESS ' ' BUTTON TO HOLD THE CURRENT PAGE.

  • Page 22: Connection To The External Audio And Video Equipment

    Connecting the TV set to the other video and audio equipment Connecting to the other video and audio equipment You can connect a stereo to the AUDIO output terminals on the TV set to enjoy higher quality sound. VIDEO and AUDIO output terminals output the video and audio signals being monitored by the TV set.

  • Page 23: Troubleshooting Guide

    2.The TV set must only be repaired by a qualified registered service person. Never attempt to remove the back cover as the TV set has dangerous voltages inside that may cause a fatality or fire. 3. The cabinet may produce the occasional "snapping sound" This is normal and caused by the materials in the cabinet expanding with room temperature changes.

  • Page 24: Specifications

    Specifications M o d e l PAL, NTSC, SECAM Colour system Sound system BG, DK, I ,M Picture tube 21"colour picture tube(the viewable dimesion is 51cm) Sound output power 2W not distortional Power requirements 100-240V 50/60Hz Power consumption Dimension 603 Width x475 Depth x430 Height Remote Control Owner's Manual Accessories...

  • Page 25: Warranty

    Warranty HTV-021TB...
  • Page 28 90506287...
