ICT N7 Series Installation Manual

Bill validator

Advertisement

Quick Links

2003 International Currency Technologies Corporation
Vol. 1.0
Part Number
H46540-R
N7 Series
Installation Guide
4 - Way Acceptance
Low Maintenance
Easy Installation
Re - Programmable
Flash ROM
Auto Self -Adjusting
Sensor System
International Currency Technologies
43010 Osgood Rd. Fremont, CA 94539
T el
(510) 353-0289
Fax
(510) 353-0399
E-mail
sales@ict-america.com
Website
www.ict-america.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N7 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ICT N7 Series

  • Page 1 N7 Series Installation Guide 4 - Way Acceptance Low Maintenance Easy Installation Re - Programmable Flash ROM Auto Self -Adjusting Sensor System International Currency Technologies 43010 Osgood Rd. Fremont, CA 94539 T el (510) 353-0289 (510) 353-0399 E-mail sales@ict-america.com Website www.ict-america.com...
  • Page 2 Contents Contents (1) N7 Bill Validator Specifications ......... 2 (2) Bill Validator Dimensions ........... 2 (3) LED Display ............... 4 (4) LED Status ..............4 (5) Download and upgrade ..........4 (6) N7 Pin-out Assignments (N.I.S.R for 117V AC) ..5 N.I.S.R CONNECTOR ..........
  • Page 3 (1) N7 Bill Validator Specifications Acceptance Rate Weight Approx. 2kg (shipping) 96% or greater Vertical Vertical Bill insertion Power Sources (Sliding Block) 4-way Acceptance 117V AC 0.2Amp (60HZ) Acceptance Speed Power Consumption Approx. 3 seconds Max 50 watts (including bill stacking) Environment Range Interfaces Operating Temperature 0 C~55 C...
  • Page 4 (3) LED Display The two LED lights located at the front of the unit will show the operational status of the bill validator. The LED lights will flash ON and OFF (in 500ms intervals) when the unit is ready to accept bills. The LED lights will be OFF if the unit is disabled or out of service, in which case the unit will not accept any bills.
  • Page 5 N.I.S.R CONNECTOR INTERFACE CONNECTOR : 18-pin mating connector pin-out assignments: Pin 10 /OUT-OF-SERVICE Pin 1 Reserved Pin 11 /DEBUG DATA Pin 2 INTERRUPT Reserved Pin 12 /ACCEPT ENABLE Pin 3 Pin 4 GROUND Reserved Pin 5 /DATA Pin 14 /SEND Pin 6 Reserved Pin 15...
