- Page 1 DMS2(Data Management Server2) MIM-D00A Air Conditioner installation manual imagine the possibilities Thank you for purchasing this Samsung product. DB98-32138A(3)
-
Page 2: Safety Precautions
Safety Precautions This installation manual describes how to install the DMS2. For installation of other optional accessories, refer to the appropriate installation manual. R ead carefully this installation manual before WARNING installation and check if the DMS2 is installed correctly after installation. -
Page 3: Table Of Contents
Contents AFETY RECAUTIONS ..............DMS2 EFORE NSTALLING THE ........... CCESSORIES .................. IEWING THE ARTS ................ RODUCT IMENSIONS .............. YSTEM RCHITECTURE .............. OMPATIBLE EVICES ..............DMS2 ..............NSTALLING THE ETTING THE OMPUTER NVIRONMENT ........ -
Page 4: Before Installing The Dms2
A public IP is needed to access the DMS2 over the internet. (One public IP is needed for each DMS2) A private IP may be used if the DMS2 need not be accessed over the internet. DMS2 supports DHCP. -
Page 5: Accessories
Quantity Shape Installation User’s manual Cable tie manual The DMS2 must be installed by a trained installer. Ensure the main power is turned off before installing the DMS2. Be sure to use adapter and power cable we provide. -
Page 6: Viewing The Parts
LED Indicator Check 15 LED status such as Power, CPU-Alive, Ethernet-Linked/Active, COM1~5-TX/RX and Check DMS2 Bottom cover Unfasten 2 screws on the bottom and separate the bottom cover from DMS2. Then check cable connection part. LED Indicator Item Name Status... - Page 7 Reset DMS2 Power Terminal Connect DMS2 adapter Serial Terminal Service agent checks DMS2 error status using this terminal SD card socket Sub memory (for program update and set information saving) socket RS485 Connect for RS485 communication with devices such as centralized...
-
Page 8: Product Dimensions
Viewing the Parts (Continued) Main Parts DMS2 Interior Display Board 20-pin Cable DI contact control option switch Main Board 40-pin Cable Sub Board Note If you need external circuit configuration, consult with the manufacturer. R efer to page 20 for DI contact input operation. -
Page 9: System Architecture
Interface module Connecting centralized controller and DMS2 ( type) - You can control up to 16 centralized controllers and 256 indoor units using DMS2. Connecting interface module and DMS2( type) - You can control up to 80 interface modules and 256 indoor units using DMS2. -
Page 10: Compatible Devices
Watt-hour power meters) Meter Connected with PIM Pulse type Pulse Width: 20~400(ms) Pulse: 1~10000(Wh/Pulse) Products with ‘* ’ are not Samsung products and must be purchased separately. (Only selected power meters may be used for protocol compatibility issues.) - Page 11 Centralized Must not exceed 16 units Controller 16 units per 1 channel, total 80 units are connectable Interface when connecting interface module to DMS2 directly module (256 units are connectable when using centralized controller) SIM/PIM Maximum 8 SIM/PIM units can be connected.
- Page 12 Installing the DMS2 Separate the installation plate on the rear side of DMS2. Fix the installation plate on the wall using 4 screws. Hang the DMS2 on the groove which is on the top of the installation plate. Installation plate...
- Page 13 ( Screws for assistant hole are not provided by our company.) Assistant hole If you install DMS2 inside of the wall or wiring from the rear side is needed, use wiring groove on the bottom of DMS2. wiring groove To prevent breakdown and damage of DMS2, and for safe...
-
Page 14: Installing The Dms2
Installing the DMS2 (Continued) Connecting Centralized Controller Unfasten the 2 screws on the bottom of the DMS2 front cover. Hold the bottom 2 sides of the DMS2 and push downwards to slide open the cover. Connect the adapter to the power terminal. - Page 15 Connecting Interface Module Unfasten the 2 screws on the bottom of the DMS2 front cover. Hold the bottom 2 sides of the DMS2 and push downwards to slide open the cover. Connect the adapter to the power terminal. Arrange the adapter as the right figure.
- Page 16 Installing the DMS2 (Continued) Connecting SIM Unfasten the 2 screws on the bottom of the DMS2 front cover. Hold the bottom 2 sides of the DMS2 and push downwards to slide open the cover. Connect the adapter to the power terminal.
- Page 17 Using the DI External Contact Control (Optional) Setting the External Contact Control Pattern You can set the system settings through contact control pattern. Select [System Settings] menu and click [System environment setting]. Click [Edit] from ‘Select the contact control pattern’ . Select the pattern you want to check.
- Page 18 Note Pattern 1 is set as factory setting. DMS2 has total 10 DI ports. However, actually used DI ports are Ch1 and Ch2, and the rest of the ports (Ch3~Ch10) are for additional functions.
- Page 19 1. If the contact control signal is changed to ON, emergency stop status and all the indoor units are given ‘Stop’ command, and controlling using remote controller is impossible. 2. During the emergency stop, the DMS2 will ignore any request from the upper controllers. Pattern2 3.
- Page 20 Installing the DMS2 (Continued) DI(Digital Input) Circuitry according to Control Switch Pattern P attern 2 (May be used for connection with a fire sensor) DMS2 Emergency Stop/Resume Operation No Connection P attern 3 (External contact signal control) ...
