Summary of Contents for Hear Technologies switch back M8RX

  • Page 2: Fcc Statement

    NOTES ABOUT THE SYSTEM If the Mixer detects a headphone short, it will automatically mute the output in attempt to keep from damaging the headphones. WARNING DO NOT CONNECT M8RX TO A PRO HUB OR OCTO HUB. Damage to either system can occur! PRO Hub OCTO Hub Switch Back...
  • Page 3 19. WARNING: To prevent injury, this apparatus must be securely attached to a rack in accordance with the installation instructions. 20. Detailed installation instruction in user manual. Switch Back M8RX User Guide...
  • Page 4 Switch Back M8RX User Guide...

  • Page 5: Electromagnetic Compatibility

    Directive. Safety: IEC 60065 -01+Amd 1 Nason Tackett EMC: EN 55022:2010 Senior Design Engineer 55024:2010 Hear Technologies FCC Part 15 991 Discovery Drive Huntsville, AL 35806, USA Date: March 1, 2018 Switch Back M8RX User Guide...

  • Page 6: Limited Warranty

    The following are registered trademarks of Hear Technologies: Hear Technologies, Hear Back, Control Your Mix, Talk Back, Extreme Extender, Hearbuds, HearBus, and the “Jack” logo. All names and marks of other companies belong to those respective companies.
  • Page 7 • True 48-volt phantom power remotely/locally OVERVIEW selectable on each microphone input • Burr-Brown 24-bit Delta-Sigma (ΔΣ) A/D The Switch Back M8RX™ is a personal interface to be converters used for live sound or recording, and also a multi-channel • Burr-Brown 24-bit enhanced multilevel delta- headphone monitoring system.

  • Page 8: Detail Diagram

    • Remotely/Locally adjustable microphone gain, in selectable the Dante network as sources increments between 30 and 54 dB • Optional Hear Technologies software for discovering and • Local volume control of up to 8 channels of audio (4 local controlling M8RX interfaces on the network analog inputs and 4 Dante digital inputs) •...

  • Page 9: Mixer Construction

    MIXER CONSTRUCTION CONTROLS The Switch Back M8RX is constructed of UV-stabilized ABS The M8RX has three different types of controls: and has a built-in standard camera tripod stand mount (1/4”-20 INPUT VOLUME KNOB – There are 3 input 5 9 13 thread).

  • Page 10: Connecting The System

    PoE+ network switch. The M8RX receives its inserting network cable to reapply power. power over the Cat6 cable. The Hear Technologies PRO Mixer Once power is reapplied, release BOTH push buttons. Distro (Firmware Version V1.2) is a good choice for a PoE+ network switch.
  • Page 11 LED. BLUE Device List - shows available Switch Back M8RX interfaces Audio Input signal status – these indicators light up currently on the network, as well as their IP address, port,...
  • Page 12 Please visit www.audinate.com for a vast wealth of training videos, example setups, and documentation. Our Switch Back M8RX connects four channels of simultaneous audio input and output with other Dante enabled equipment using a standard Ethernet network connection. Dante will work with standard network switches and routers and is safe to combine with your existing computer network, if necessary.

  • Page 13: Device View

    If the sampling rate needs to change, Below is an example of this window. Here you can see the audio you must change it on all devices individually. signal status. This is also great for troubleshooting. Switch Back M8RX User Guide...

  • Page 14: System Block Diagram

    LEDs. Try rebooting the M8RX. If the problem persists, please contact technical support. If you need further assistance, feel free to contact Hear Technologies technical support by phone at +1-256-922-1200 or visit our web site at http://www.HearTechnologies.com.

  • Page 15: Technical Specifications

    Power PoE+ 36-52 VDC, 15 Watts max** Power Requirements: *Note: 0 dBu = 0.775 Vrms. Specifications and features subject to change without notice. **Provided by Hear Technologies PRONET or equivalent network switch with PoE+ capability. Switch Back M8RX User Guide...
  • Page 16 ©2021 Hear Technologies 01-2021...
