BH47-021-099-28
UPC # 050277000197
The maximum weight load capacity is
10lbs (4.5 kgs) each shelf. Exceeding
capacity may result in collapse and
possible injury
.
CHEYENNE PRODUCTS
** THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
DO NOT RETURN THIS ITEM TO THE STORE OR CONTACT THE RETAILER
**
In the unlikely event that you should have a problem with your merchandise, o
parts, Please contact our dedicated customer service team at 1-800-737-5267 or email
customerservice@cheyenneproducts.com to request parts or assistance with your
merchandise. Our offices are open Monday through Friday between 8:00 AM and 5:00 PM -
(Central Standard Time) - excluding major holidays. Our customer service representatives
are committed to resolving your problem as quickly as possible.
** Assemble on soft surface to prevent damage to the product finish.
** Carefully remove all parts from the box and make sure that no parts listed on
the assembly instructions are missing.
** Cheyenne products is committed to helping save the environment for future
generations. We encourage you to reuse or recycle all of the materials used in
the packaging of this product.
LOT NUMBER:
DATE OF PURCHASE:
r you are missing
1
Advertisement
Related Manuals for Cheyenne Products BH47-021-099-28
Summary of Contents for Cheyenne Products BH47-021-099-28
- Page 1 ** Carefully remove all parts from the box and make sure that no parts listed on the assembly instructions are missing. ** Cheyenne products is committed to helping save the environment for future generations. We encourage you to reuse or recycle all of the materials used in the packaging of this product.
- Page 2 BOLT (14PCS) SCREW (2PCS) BOLT (12PCS) 1/4″ x 1-1/8″ 1/4″ x 1-1/2″ 1/4″ x 1/2″ LEFT WHEEL (2PCS) RIGHT WHEEL (2PCS) (WITH LOCK) (WITHOUT LOCK) OPEN WRENCH (1PC) ALLEN WRENCH (1PC) LEFT FRAME METAL SHELF LEFT METAL MIDDLE FRAME (1PC) (1PC) TUBE (2PCS) (1PC)
- Page 3 STEP 1 ATTACH METAL SHELF (B) AND LEFT METAL TUBE (C) TO THE LEFT FRAME (A), USING 4 BOLTS (1). 2. USING 2 SCREWS (2) FASTEN TO METAL SHELF (B) FASTEN SECURELY BOLT (4PCS) SCREW (2PCS) 1/4″ x 1-1/8″ 1/4″ x 1-1/2″ ALLEN WRENCH (1PC) STEP 2 ATTACH MIDDLE FRAME (D) TO THE ASSEMBLED...
- Page 4 STEP 3 ATTACH RIGHT METAL TUBE (E x 2), TO THE MIDDLE FRAME (D), USING 2 BOLTS (1). 5. ATTACH RIGHT METAL TUBE (E) X2, TIGHTEN TO THE HARDWARE SCREW (2). FASTEN SECURELY. BOLT (2PCS) 1/4″ x 1-1/8″ ALLEN WRENCH (1PC) STEP 4 ATTACH RIGHT FRAME (F), TO THE METAL TUBE (E), USING 4 BOLTS (1).
- Page 5 STEP 5 ATTACH LEFT WOOD SHELF (G) AND RIGHT TOP WOOD SHELF (H) AND RIGHT BOTTOM WOOD SHELF (I), TO THE LEFT FRAME (A) AND MIDDLE FRAME (D) AND RIGHT FRAME (F), USING 12 BOLTS (3) AND 2 BOLTS (1). AS SHOWN. FASTEN SECURELY.
-
Page 6: Important Warranty Information
IMPORTANT WARRANTY INFORMATION SAVE THIS INFORMATION FOR FUTURE REFERENCE * Our products are produced under the strict quality control standards and meet or exceed all applicable industry standards and consumer regulations. Your merchandise is warranted for ninety (90) days from the date of purchase against manufacturing defects. - Page 7 INSTRUCCIONES PARA ARMAR BH47-021-099-28 UPC CODIGO DE BARRAS# 050277000197 ADVERTENCIA: La capacidad máxima de carga es de 10 libras (4.5 kgs). Si se excede la capacidad, el producto se puede derrumbar y causar posibles lesiones. CHEYENNE PRODUCTS ** EL FOLLETO DE INSTRUCCIONES CONTIENE IMPORTANTE INFORMACION DE SEGURIDAD.
-
Page 8: Lista De Partes
FERRETERÍA: PERNO DE (14PCS) TORNILLO (2PCS) PERNO DE (12PCS) 1/4″ x 1-1/8″ 1/4″ x 1-1/2″ 1/4″ x 1/2″ BLOQUEO DE RUEDAS (2PCS) RUEDAS (2PCS) (CON TRABA) (SIN TRABA) LLAVE ABIERTA (1PC) LLAVE ALLEN (1PC) LISTA DE PARTES: MARCO IZQUIERDO ESTANTE METÁLICO TUBO METÁLICO MARCO CENTRAL (1PC) - Page 9 PASO. 1 ACOPLE EL ESTANTE METÁLICO (B) Y EL TUBO METÁLICO IZQUIERDO (C) AL MARCO IZQUIERDO (A), USANDO 4 PERNOS (1). 2. USANDO 2 TORNILLOS (2), AJUSTE FIRMEMENTE AL ESTANTE METÁLICO (B). PERNO DE (4PCS) TORNILLO (2PCS) 1/4″ x 1-1/8″ 1/4″...
- Page 10 PASO. 3 ACOPLE EL TUBO METÁLICO DERECHO (E x 2) AL MARCO CENTRAL (D), USANDO 2 PERNOS (1). 5. ACOPLE EL TUBO METÁLICO DERECHO (E) X2 Y AJÚSTELO AL TORNILLO (2). AJÚSTELOS FIRMEMENTE. PERNO DE (2PCS) 1/4″ x 1-1/8″ LLAVE ALLEN (1PC) PASO.
- Page 11 PASO. 5 ACOPLE EL ESTANTE DE MADERA IZQUIERDO (G), EL ESTANTE DE MADERA SUPERIOR DERECHO (H) Y EL ESTANTE DE MADERA INFERIOR DERECHO (I), AL MARCO IZQUIERDO (A), AL MARCO CENTRAL (D) Y AL MARCO DERECHO (F), USANDO 12 PERNOS (3) Y 2 PERNOS (1).
- Page 12 INFORMACIÓN IMPORTANTE DE GARANTÍA * GUARDE ESTA INFORMACIÓN PARA FUTURA REFERENCIA * Nuestros productos son fabricados con los más estrictos controles y normas de calidad y cumplen o exceden todos los requisitos de rigor de la industria, además de cumplir con todas medidas de protección al consumidor. Su mercancía está...
