ASSEMBLY INSTRUCTIONS
BH18-084-099-67
UPC #
050277001866
WARNING:
The maximum weight load capacity is 25
lbs (11.33 kgs). Exceeding capacity may
result in collapse and possible injury.
CHEYENNE PRODUCTS
** THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
DO NOT RETURN THIS ITEM TO THE STORE OR CONTACT THE RETAILER
**
In the unlikely event that you should have a problem with your merchandise, o
parts, Please contact our dedicated customer service team at 1-800-737-5267 or email
customerservice@cheyenneproducts.com to request parts or assistance with your
merchandise. Our offices are open Monday through Friday between 8:00 AM and 5:00 PM -
(Central Standard Time) - excluding major holidays. Our customer service representatives
are committed to resolving your problem as quickly as possible.
** Assemble on soft surface to prevent damage to the product finish.
** Carefully remove all parts from the box and make sure that no parts listed on
the assembly instructions are missing.
** Cheyenne products is committed to helping save the environment for future
generations. We encourage you to reuse or recycle all of the materials used in
the packaging of this product.
LOT NUMBER:
DATE OF PURCHASE:
r you are missing
FT1261-AI-V1
Advertisement
Related Manuals for Cheyenne Products BH18-084-099-67
Summary of Contents for Cheyenne Products BH18-084-099-67
- Page 1 ** Carefully remove all parts from the box and make sure that no parts listed on the assembly instructions are missing. ** Cheyenne products is committed to helping save the environment for future generations. We encourage you to reuse or recycle all of the materials used in the packaging of this product.
-
Page 2: Parts List
HARDWARE: × 1pc × 3pcs × 12pcs allen wrench bolt M5 x 1/2” bolt M5 x 3/4” PARTS LIST: × 1pc × 2p s c × 1pc × 3p s c wood top ring frame bottom ring tube frame ASSEMBLY INSTRUCTIONS NOTE: To make assembly easier, please do not fully tighten the bolts until you finish assembly. - Page 3 ASSEMBLY INSTRUCTIONS × 6 pcs bolt M5 x 3/4” Allen wrench (provided) × 3pcs bolt M5 x 1/2” Please make sure all bolts Allen wrench (provided) and screws are placed in their proper positions and are tightened securely to ensure your safety. Assembly Complete.
-
Page 4: Important Warranty Information
IMPORTANT WARRANTY INFORMATION SAVE THIS INFORMATION FOR FUTURE REFERENCE * Our products are produced under the strict quality control standards and meet or exceed all applicable industry standards and consumer regulations. Your merchandise is warranted for ninety (90) days from the date of purchase against manufacturing defects. - Page 5 INSTRUCCIONES PARA ARMAR BH18-084-099-67 UPC CODIGO DE BARRAS# 050277001866 ADVERTENCIA: La capacidad máxima de carga es de 25 libras (11.33 kgs). Si se excede la capacidad, el producto se puede derrumbar y causar posibles lesiones. CHEYENNE PRODUCTS ** EL FOLLETO DE INSTRUCCIONES CONTIENE IMPORTANTE INFORMACION DE SEGURIDAD.
-
Page 6: Lista De Partes
FERRETERÍA: × 3pcs × 1pc × 12pcs perno de M5 x 1/2” llave allen perno de M5 x 3/4” LISTA DE PARTES: × 1pc × 2p s c × 1pc × 3p s c marco de anillo estante de madera anillo inferior anilo de tubo INSTRUCCIONES PARA ARMAR... - Page 7 INSTRUCCIONES PARA ARMAR × 6 pcs perno de M5 x 3/4” llave Allen (suministrado) × 3pcs perno de M5 x 1/2” Asegúrese de que todos llave Allen (suministrado) los pernos y tornillos se colocan en sus posiciones correctas y estén bien apretados para asegurar su seguridad.
- Page 8 INFORMACIÓN IMPORTANTE DE GARANTÍA * GUARDE ESTA INFORMACIÓN PARA FUTURA REFERENCIA * Nuestros productos son fabricados con los más estrictos controles y normas de calidad y cumplen o exceden todos los requisitos de rigor de la industria, además de cumplir con todas medidas de protección al consumidor. Su mercancía está...
