Summary of Contents for Sterilor XP Redox
- Page 1 Installation and user Stérilor XP Redox manual...
-
Page 2: Table Of Contents
4. | Manual sensor calibration ..............1. | Technical characteristics ..............4. | Sensor 1 point calibration ..............1. | Stérilor XP Redox operating principle ..........4. | Set point adjustment ................. 1. | Vessel and module configuration possibilities ........ -
Page 3: Device Discovery
Choose complete treatment straight away or upgrade your solution depending on your wishes and your budget. Stérilor XP modules are stand-alone, complementary and interconnected using Bluetooth. Stérilor XP Sel Stérilor XP Connect Stérilor XP Stérilor XP Stérilor XP Redox Temperature Stérilor XP Redox... -
Page 4: Standards And Regulations
• Bluetooth frequency band from 2402 MHz to 2480 Mhz • Power cable length: 1.80 m • Ambient temperature range: 0 °C < t °C < +55 °C • Redox sensor cable length: 5.00 m • Protection rating: IP66 • Power supply: 230 VAC Stérilor XP Redox... -
Page 5: Stérilor Xp Redox Operating Principle
The Redox sensor is used to detect the disinfectant produced by the chlorinator. The Sterilor XP Redox can only be controlled and configured using the Sterilor XP App. The Stérilor XP Redox communicates with the Stérilor XP chlorinator using Bluetooth (no wiring needed between the control boxes). -
Page 6: Vessel And Module Configuration Possibilities
1 Device discovery Vessel and module configuration possibilities 1. | The Stérilor cell must be installed with the connection head at the bottom Stérilor XP Redox... -
Page 7: Accessories Available As Options
KAQ4044 KAQ4030 KAQ4107 Valve with fittings 2-accessory holder module 5-accessory holder with Ø 50 mm and Ø 63 mm connectors with Ø 50 mm and Ø 63 mm connectors for drainage or water analysis sample-taking KAQ4103 KAQ4104 KAQ4279 Stérilor XP Redox... -
Page 8: Water Quality Recommendations
Potential hydrogen pH between 6.8 and 7.6 Alkalinity T.A.C. between 80 and 150 ppm Hardness TH between 150 and 250 ppm Free chlorine between 0.3 and 1.5 ppm Stabiliser Max 30 mg/l Salt Between 3.5 and 5 g/l Stérilor XP Redox... -
Page 9: Manufacturer Recommendations
• Check all the pool parameters once per month and adjust if necessary. • Couple the Stérilor XP Redox electrical connection to the filtration. • Provide for a connection to the XP chlorinator circuit breaker coupled to the filtration. -
Page 10: The Stabiliser
• If the stabiliser content is higher than 30 mg/l, partially or completely drain the pool. • If the pool needs to be drained, follow your pool manufacturer’s recommendations. • Do not use stabiliser in indoor or sheltered pools. Stérilor XP Redox... -
Page 11: Device Installation
Device installation Pack contents 2. | 3 screws and 3 anchors to install the box Installation and user Stérilor XP Redox manual Redox regulation control 2-accessory holder Installation and user manual Wall support box with the 230 VAC with its connectors (Ø 50 mm and Ø 63 mm) -
Page 12: Equipment Required For The Installation
• A tape measure • A pencil • A saw • Sandpaper to debur (fine grain) • PVC scourer • High performance PVC/ABS adhesive • Cloth • Drill + Ø 5 mm drill bit • Cross-tipped screwdriver • Stripping pliers Stérilor XP Redox... -
Page 13: Possibility 1: Installation Of The 2-Accessory Module
To backflow nozzles Swimming pool backflow Main drain Filtration unit Heat pump Filter 230 VAC Manifold Pump To drains Skimmers TWO CHOICES OF REDOX SENSOR INSTALLATIONS: • Either on the independent module • Or install before the chlorination vessel Stérilor XP Redox... -
Page 14: Possibility 2: Installation Of The 2-Accessory Module
Swimming pool backflow Main drain Filtration unit Heat pump Filter Bypass 230 VAC Manifold Pump To drains Skimmers TWO CHOICES OF REDOX SENSOR INSTALLATIONS: • Either on the independent module • Or install before the chlorination vessel Stérilor XP Redox... -
Page 15: Installation Of The Separate 2-Accessory Module
Important: the Redox sensor must be installed: at the bottom or horizontal - either vertically with the sensor head at the bottom, - or horizontally (90°). • Keep the sensor protection bottle, it is used to winterise it Caution: fragile gold tip. Stérilor XP Redox... -
Page 16: Installing The 2-Accessory Module Connected To The Chlorination Vessel
• Keep the sensor protection bottle, it is used to winterise it Important: the Redox sensor must be installed: - either vertically with the sensor head at the bottom, - or horizontally (90°). Caution: fragile gold tip. Stérilor XP Redox... -
Page 17: Installing The Box
See the filtra�on unit manual for for the electric connec�on the electric connec�on EARTH EARTH Redox control box power supply 230 Vac Redox control box power supply 230 Vac PHASE ELECTRIC NEUTRAL PHASE HAZARD ELECTRIC NEUTRAL HAZARD Filtra�on pump Filtra�on pump Stérilor XP Redox... -
Page 18: Redox Sensor Connection
• Connect the sensor BNC connector to the control box BNC connector. • Position the Sensor BNC opposite the Control box BNC. • Tighten the nut manually. • Do not use tightening tools. Redox sensor BNC Tightening nut Control box BNC Stérilor XP Redox... -
Page 19: Setting Up The Stérilor Xp App
3 3 Setting up the Stérilor XP app The Sterilor XP App N.B. : controlling XP devices 3. | using the STERILOR XP mobile app MUST have a smartphone connected to the internet. SIMPLE FUNCTIONAL USER-FRIENDLY Stérilor XP ERGONOMIC Connect Stérilor XP Temperature Stérilor XP... -
Page 20: Stérilor Xp Application Download
The Stérilor XP app is available from Google Play and App Store. You can download it… Stérilor XP AVAILABLE FROM AS Pool From Android 7.0 or later DOWNLOAD FROM App Store QR code to download the Stérilor XP app From iOS 10.0 or later Stérilor XP Redox... -
Page 21: Operation Without Stérilor Xp Connect
Setting up the Stérilor XP app Operation without Stérilor XP Connect 3. | Local control of the devices using the Bluetooth on a phone connected to the internet. Pool plant 2.4 or 5 Ghz Home Adsl, Vdsl, Fibre Stérilor XP Redox... -
Page 22: Operation Using Stérilor Xp Connect
Remote control of the devices using the Router Wifi using a phone connected to the internet. Home Pool plant Adsl, Vdsl, Fibre 2.4 Ghz Bluetooth 2.4 or 5 Ghz Only required for the 1st installation and device update Stérilor XP Redox... -
Page 23: Installer Or User Account Creation
Enter a password compliant If you are a professional, Read and validate the Create an account information with the instructions check the box and then Stérilor terms and enter the Company name conditions. and Siret number Create my account Stérilor XP Redox... -
Page 24: Create A Pool Account
Creating a pool makes it possible to identify your pool and define its characteristics. You can authorise people to use the Stérilor XP app for your pool. Follow the steps: Create a pool Enter your pool name Access to the Home page Press Press User manual Information Validate the creation Stérilor XP Redox... -
Page 25: My Pool Address
Press the symbol The weather information Click Address Enter the pool location The address is identified is indicated address on the app Access to the day’s Select the address. weather forecast The address is used to locate the pool. Stérilor XP Redox... -
Page 26: My Pool/My Equipment
The My pool technical information is used to get a correct Stérilor XP equipment configuration for the pool configuration. Press the symbol Select My equipment Select My pool Enter the requested information Enter the requested information (pool information) (filtration and slatted cover information) Save Save Stérilor XP Redox... -
Page 27: Device / Stérilor Xp App Installation
Add a new appliance device to pair (4 digits) indicated on top of the box and Continue Back to the Home page The control box is now paired. You are on the Stérilor XP app Home page. Stérilor XP Redox... -
Page 28: Pairing Another Control Box With The App
Add a new appliance (4 digits) indicated on top of the control box and Continue Select the device to pair Back to the Home page The control box is now paired. You are on the Stérilor XP app Home page. Stérilor XP Redox... -
Page 29: Installed Sensor Identification
Flashing the QR code control box, you do not need to identifies the Redox sensor flash the QR code. relative to its control box. When the sensor QR code has been flashed, the sensor requires calibration. Stérilor XP Redox... -
Page 30: Configuration
Calibrate the sensor or higher than this setting, the app will No = no communication Then Save Press Settings send you an alarm Then Save This alarm is self-resetting when the Redox returns to the authorised range Then Save Stérilor XP Redox... -
Page 31: Redox Sensor Calibration
The Redox sensor needs to be calibrated: • Each time the pool is recommissioned N.B. : the Sterilor XP Redox sensor is calibrated with its • When a drift in the pool chlorine value is detected and your water balance is correct control box in the factory. -
Page 32: Manual Sensor Calibration
Indicate whether the sensor was Press Next replaced or not (if the REDOX sensor is replaced: flash the QR code on the new sensor. In that case, calibration is mandatory). Wait 60 seconds for the REDOX value validation Stérilor XP Redox... -
Page 33: Sensor 1 Point Calibration
• Repeat the calibration or condition replace the Redox sensor Indicate whether the sensor was replaced or not (if the REDOX Press Measure Validate sensor is replaced: flash the QR code on the new sensor. In that case, calibration is mandatory) Stérilor XP Redox... -
Page 34: Set Point Adjustment
Move the yellow dot on the semi-circle. Validate the setting by taken into account on the Set the required set point. keeping the V key pressed device for 5 seconds Programmed set Redox sensor point reading Set point validated Stérilor XP Redox... -
Page 35: My Stérilor Xp Account
You can remove a device from your app (to remove: Owner or Guest with “Advanced User” rights). Press the symbol Select Click on the device in Click The device is automatically My appliance management question Remove removed from the app Stérilor XP Redox... -
Page 36: Invite A User
• Advanced user level = access to all functions Create an invitation Press the symbol Press Select Create an invitation User management Invitation codes Choose the authorised Forward the 6 character rights (Role) code to your guest (case sensitive) Validate Stérilor XP Redox... -
Page 37: Join A Pool
Access to the Home page Enter the code Validate by pressing Join My pools (6 characters) sent for the pool in question by the owner (case sensitive) Join a pool How to obtain the code Join a pool (see page 36) Stérilor XP Redox... -
Page 38: Change A Guest's Access Rights
That user will have 3 access levels: • User level = modification of 1 level parameters • Advanced user level = access to all functions Press the symbol Select the new rights Press Select the user name in User management question Validate Stérilor XP Redox... -
Page 39: Transferring Management To A New Owner
Only a guest who is already a pool user can access the Owner status. For the professional or current owner: Press the symbol Press Select Select the new owner User management Transfer ownership Validate. The previous owner becomes an “Advanced user” Stérilor XP Redox... - Page 40 Only a guest who is already a pool user can access the Owner status. For the new owner: close and relaunch the Stérilor app. Press the symbol Check the owner name You have the access to administer new users Press User management Stérilor XP Redox...
-
Page 41: Select Another Pool
Select another pool 5. | You can manage several pools using the same account. Private individual: max 3 pools / Professional: unlimited. Press the symbol Press Select the pool The selected pool My pools in question is displayed Save Stérilor XP Redox... -
Page 42: Modify Or Logout My Account
My Stérilor XP account Modify or Logout my account 5. | To Logout your account, follow steps If changes to account information are needed, follow steps then Press the symbol Press Modify information Press Validate the disconnection Manage Logout Save Stérilor XP Redox... -
Page 43: My Installation Information
Legal notices. T&Cs. General terms and conditions of use. Used to access and read all the legal information. User manual Access to all the Stérilor XP range user manuals. Regular updates to be informed of product changes. Stérilor XP Redox... -
Page 44: Demonstration Mode
The Home Page is in Validate access to the demo demonstration mode. You can view the different After the demo, you will Open your menus. need to access your personal access again Select Exit Demo Stérilor XP account again. Stérilor XP Redox... -
Page 45: Stérilor Xp Equipment Software Updates (Except Connect)
Connect. Press Update Press Close Select Select the device to update Information progress Appliance update The control box concerned by the update downloads the new software. The control box LED flashes for a few seconds. Stérilor XP Redox... -
Page 46: Professional Support
Stérilor technician’s computer. Press Generate a code Possibility of taking control of the app remotely. Possibility of viewing the Send the code to the Stop the session installation remotely. Stérilor technician Stérilor XP Redox... -
Page 47: Statuses And Anomalies
• If equipped with a Stérilor XP Connect, the history is continuous, possibility of going back to previous dates all the way back to the original installation. • If not equipped with a Stérilor XP Connect, the history goes back 3 days. Stérilor XP Redox... -
Page 48: Control Box Colour Code: Operating Status
Steady You have launched a sensor calibration. The Redox regulation has reached The Redox notifies the chlorinator Power on the XP Redox control box. Detail Follow the instructions given by the app. the programmed Redox set point. to produced to reach the set point. -
Page 49: Control Box Colour Code: Operating Diagnosis
Check the sensor Check the correct REDOX reading. Check the correct REDOX reading. Ventilate the space if necessary. condition. If necessary, replace the sensor. Check your REDOX min and max alarm settings. Calibrate if necessary. Self reset Stérilor XP Redox... -
Page 50: Maintenance And Guarantee
• Check the Redox sensor, the BNC, the cable and the sensor head condition. WINTERING: • Cut the 6A circuit breaker provided for the Stérilor XP Redox connection to the filtration control box. • Clean and rinse the sensor in clean water. Wipe carefully. -
Page 51: Device Guarantee
For all After-sales services, customers must contact their professional dealer using the applicable procedure. All product returns for expertise must be carriage paid. Your dealer must indicate your Stérilor XP Redox serial number on your invoice. Keep your purchase invoice to be able to use your guarantee. -
Page 52: Contact Us
ZAC de la Rouvelière - 72700 SPAY - FRANCE Serial N° S.A.S. WITH AN EQUITY CAPITAL OF 300,000 € - SIRET 400 916 979 000034 - APE CODE 2223Z - FR 314 0091 6979 © NextPool - All rights reserved - 2021 SR-12-284-1/09-2021 Stérilor XP Redox...
