Position of Keys and Plug-ins

Front and side panel

25F9K
Menu
TV/AV
Volume
switch
up/ down
25F3A
Menu
TV/AV
Volume
switch
up/ down
Please do not use the side and back AV terminals simultaneously .

Back panel

Video Cb input terminal
Video Y input terminal
Video input terminal
Video output terminal
S-VIDEO input terminal
Channel
position up/down
Infrared sensor window
Channel
position up/down
Signal receiver
Power indicator
Power switch
Power
Power indicator
switch
Video Cr input terminal
Antenna input socket
Audio right channel input terminal
Audio left channel input terminal
Audio right channel output terminal
Audio left channel output terminal
Video
Left audio
Right audio
Video
R/L
audio
