14.
Exploded View
No
Material code
1
0090203204
2
0090300099
3
0094000018
4
0090100132
5
0090300095
6
0090600023
7
0090100128
8
0090300076
9
0094003080
10
0090800171
11
0090600069
12
0094500383
13
009400.4206
14
0090201561
15
0090600028
16
0090203195
17
0090600023
18
0090202504
19
0090600028
25T7A-S EXPLOSION BOM
Parts name
Front Frame
Speaker crash pad
Speaker
Rivet
Washer Rubber
Screw
Washer
Rubber Washer
CRT
Degaussing coil clip
Combined Nut
Degaussing coil
Main Board
Bracket
Screw
Back Cover
Screw
Block
Screw
30
Type
MTAA2025AC--Q
613 Speaker
YDT613-4W-16Ω
MTBS0004BB--Q
Inner Diameter 4.8
SJ2824-87 ST4*16F
MTBH2004BA--Q
1 mm
64SX505Y22-DC01
BJZ0001-----Q
M6(98025)
HXC-64
BXQ5118---S-Q
MTAC2026AC--Q
SJ2825-87 ST3*10F
MTAA2113AC--Q
SJ2824-87 ST4*16F
MTAH2037AA--Q
SJ2825-87 ST3*10F
Exploded View
Q'ty
Remark
1
2
2
8
16
8
4
4
1
4
4
1
1
1
5
1
8
1
5
