PREPARING FOR OPERATIONS

Figure A
Antenna cable
with a plug
Figure C
Coaxial cable(75 ) twin-lead cable(300
Antenna
Figure B
75-300
¦¸
Antenna adapter
Antenna feeder
Figure D
)
Antenna connection
Connect an antenna to the antenna socket on
the TV set, we recommend using a Cable TV
system for better picture and audio quality.
1.If you use a coaxial cable(75 ),insert the
antenna plug (see figure C) into 75 socket
(see figure A).
2.If you use a twin-lead cable(300 ),please
shape the cable as figure D, and connect the
leads to antenna adapter and then insert the
antenna adapter into the 75 socket (see
figure B).
Power source wire connection
Insert the power plug into AC outlet.
Install and replace batteries of the
remote control unit:
1.Place the remote control unit with the face
down, then open the battery cover of the
unit.
2.Place the two"AA"size batteries, matching
the + and - signs on each battery to the +
and -signs of the battery compartment.
3.Close the cover of the battery compartment.
NOTE:
(1)Don't drop or wet or dismantle the unit.
(2)If you don't intend to use the unit for a
long period or the electricity of the
batteries is used up, remove the batteries
to prevent batteries acid from leaking
into the battery compartment.
(3)Replace the two old batteries at the
same time.
(4)Don't use charge battery (Ni-cd )and
don't mix battery type.
(5)Don't throw your batteries into a fire.
Dispose of your batteries in a required
place.
