- Page 1 Owner’s manual ELECTRIC BICYCLE Assist system ( Gen. 2 ) 25/32 kmh / 20 mph FX+/Dual Sport+ EN-GB...
- Page 2 Welcome WELCOME TO OUR BIKE FAMILY Thank you for purchasing your new bicycle. We believe in bicycles. We make high-quality bicycles that are built to last. That is why each bicycle we make comes with a limited warranty. We wish you many carefree and enjoyable rides with your new bicycle. However, if you experience any problems with your bicycle, do not hesitate to contact your local retailer.
- Page 3 Important to read before the first ride Supplemental Product Information The most important points for you to do 1. Even if you have ridden a bicycle for years, it is important for every person to read the general ‘Bicycle Owner’s Manual’ and the specific ‘E-Bike Owner’s Manual’ carefully before you ride on the new e-bike.
- Page 4 • Store the e-bike in a dry, well-ventilated location. Protect the battery against moisture and water. • The battery can be stored at temperatures between (minimum) -20°C (-4°F) and (maximum) +50°C (122°F). For a long battery life, however, it is best to store the battery at room temperature of approximately 20°C (68°F).
- Page 5 This manual is applicable to the Hyena assist system only Assist system Owner’s Manual Trek FX+/Dual Sport + Diamant 365 ENGLISH Copyright © 2021 HYENA INC. All Rights Reserved. This owner’s manual is primarily intended for the user to operate the e-bike.
-
Page 6: Table Of Contents
Transportation of an e-bike ................ 22 Troubleshooting ..................... 23 9.1. System issues ................... 23 9.2. Battery & charging issues ................23 9.3. Other issues ....................24 Cleaning......................... 25 Disposal ......................... 25 Contact ..........................27 HYENA E-BIKE SYSTEMS EN-GB - 1... -
Page 7: Introduction
Introduction Thank you for choosing your new e-bike with the Hyena riding assist system. We sincerely hope that you will enjoy your ride. This owner’s manual is intended for the user to operate the product and contains details of the assist system. -
Page 8: Riding Safety
• The assist system parts are not intended to be used at ambient temperatures lower than -10°C (14°F) or over temperatures of 45°C (113°F). • Use only genuine Hyena replacement parts. If you use anything other than genuine Hyena replacement parts, you may compromise the safety, performance or warranty of your e-bike. -
Page 9: Assist System Overview
Assist system overview The Hyena assist system includes the following system parts: A. Rear hub motor, MRC-E250F D. Torque & cadence sensor, ST-SQ-1 B. Console, CE-EL19A E. Electronic controller, DP-TR19A C. Battery charger, 2A F. In-tube battery, BP-TR19A HYENA E-BIKE SYSTEMS... -
Page 10: Drive Unit Instructions
⚠ CAUTION Do not dismantle the hub motor. The hub motor should only be serviced by a certified mechanic using genuine replacement parts from Hyena. 3.1. Motor safety instructions • Do not allow the motor to suffer any mechanical or physical impacts or make any internal modifications. -
Page 11: Battery Handling Instructions
⚠ CAUTION The Hyena assist system is powered by a Lithium-Ion (Li-Ion) battery. Always read and adhere to the instruction manual before handling or charging the battery or when using the e-bike. -
Page 12: Assist System Operation
E. Riding assist lever indicator 5.2. Technical data of the console Item Specification Operating temperature -10°C (14°F) to 60°C (140°F) Storage temperature -20°C (-4°F) to 70°C (158°F) Protection rating IPX5 Weight, approx. <0.05 kg (0.11 lbs) HYENA E-BIKE SYSTEMS EN-GB - 7... -
Page 13: Turning On/Off The Assist System
Level 1 (max 140%), Level 2 (max 250%) to Level 3 (max 390%). Level 0 Level 1 Level 2 Level 3 Support Off (0%) (max 140%) (max 250%) (max 390%) Select the desired assist level using the UP (+) and DOWN (-) buttons. HYENA E-BIKE SYSTEMS EN-GB - 8... -
Page 14: Charge Level Indicator
• At 4% charge, the riding support will stop. The remaining charge capacity is reserved to power lights for up to two hours. HYENA E-BIKE SYSTEMS EN-GB - 9... -
Page 15: Walk Assistance
• The Walk-assist function may only be used when pushing the e-bike. Make sure you are ready and standing steady before activating the Walk-assist function. • Do not activate the Walk-assist function when you are riding the e-bike or if the wheels are not in contact with the ground. HYENA E-BIKE SYSTEMS EN-GB - 10... -
Page 16: Turning On/Off The Lights (If Part Of The Equipment)
• At 4% charge, the riding support will stop. The remaining charge is reserved to power lights (if part of the equipment) for up to two hours. Note If your battery is empty, the lighting on your e-bike may not work until the battery is recharged. > 2 secs HYENA E-BIKE SYSTEMS EN-GB - 11... -
Page 17: Range Extender (Optional)
Storage temperature 3 months -20°C (-4°F) to 40°C (104°F) 1 year -20°C (-4°F) to 20°C (68°F) Permitted charging temperature range 0°C (32°F) to 45°C (113°F) Protection rating IPX5 Weight, approx. 1.49 kg (3.28 lbs) HYENA E-BIKE SYSTEMS EN-GB - 12... -
Page 18: Mounting The Range Extender Kit
M3 bolt. Be sure that the cable plug is facing away from the range extender battery. STEP 3 The finished connection of the downtube cable with the range extender battery. HYENA E-BIKE SYSTEMS EN-GB - 13... -
Page 19: Installing The Range Extender Battery
IMPORTANT When the range extender battery is attached physically to the e-bike, it must also be attached electrically to the bike. HYENA E-BIKE SYSTEMS EN-GB - 14... -
Page 20: Removing The Range Extender Battery
Move the range extender upwards to insertion to loosen the lower lock tab from unhook it from the mounting plate. the mounting plate. STEP 5 Pick up the range extender towards you to remove it from the mounting plate. HYENA E-BIKE SYSTEMS EN-GB - 15... -
Page 21: Mounting The Bottle Cage Adapter
1. Turn the adapter from the bottom insertion to loosen the lower snap from the mounting plate. 2. Move the adapter upwards to unhook it from the mounting plate. 3. Pick up the adapter towards you to remove it from the mounting plate. HYENA E-BIKE SYSTEMS EN-GB - 16... -
Page 22: Charging Instructions
If the e-bike battery is not fully charged in 24 hours, contact your local authorised retailer for assistance. ► About the charger • Only use a genuine certified Hyena charger to charge your Hyena battery. ⚠ WARNING Use of an uncertified battery charger presents a fire risk, which may result in serious injury or death. - Page 23 • If the LED indicator on the charger still does not illuminate with the charger connected to the socket. • If the red LED on the charger flashes during the charging process to indicate a charging error has occurred. • If you suspect any other malfunction. HYENA E-BIKE SYSTEMS EN-GB - 18...
-
Page 24: Technical Data Of The Charger
If the red LED indicator flashes during the charging process, a charging error has occurred. In that case, immediately remove the charger from the socket. Discontinue the use of the assist system and contact your local authorised bike shop. HYENA E-BIKE SYSTEMS EN-GB - 19... - Page 25 • The battery is equipped with a Battery Management System (BMS). It is designed to protect a fully discharged battery from damage. However, in order to maintain the best possible battery performance and lifespan, Hyena recommends regularly recharging your battery to at least 80% of the full capacity.
- Page 26 After 2 hours After 3 hours After 3.5 hours 100% *From empty • With installed range extender Approximate Charge Time/Charge Percent* After 2 hours After 4 hours After 6 hours 100% After 7 hours *From empty HYENA E-BIKE SYSTEMS EN-GB - 21...
-
Page 27: Storage And Transportation Instructions
Shipping of all types of (separate) batteries, including lithium-ion and lithium metal types, may require the use of specialised packaging, specific hazard labelling and specific documents certifying in compliance with the applicable local regulations. HYENA E-BIKE SYSTEMS EN-GB - 22... -
Page 28: Troubleshooting
- The battery may be near the end of its service life. Contact your local authorised retailer for further service. - The battery capacity may be affected by ambient temperature, especially in cold weather. HYENA E-BIKE SYSTEMS EN-GB - 23... -
Page 29: Other Issues
- If the LED indicator on the charger still does not illuminate, contact your local authorised retailer. 9.3. Other issues If your e-bike does not work properly due to mechanical problems, assist system issues or any other problem that cannot be identified or resolved, contact your local authorised retailer. HYENA E-BIKE SYSTEMS EN-GB - 24... -
Page 30: Cleaning
⚠ WARNING Failure to follow the instructions in this section may result in damage to the components on your e-bike and will void your warranty, but, most importantly, may result in serious injury or death. HYENA E-BIKE SYSTEMS EN-GB - 25... - Page 31 Hyena Inc. Tel +886 4 23598810 Fax +886 4 23598610 www.hyena-ebike.com Address No 25, Jingke N Rd, Nantun Dist, Taichung City 408, Taiwan (ROC) EN-GB - 26...
-
Page 32: Contact
Contact US Head Office European Head Office Trek US Bikeurope B.V./Trek Benelux Trek Bicycle Corporation Ltd. Customer Service Customer Service 9 Sherbourne Drive, Tilbrook 801 W Madison street Ceintuurbaan 2-20C Milton Keynes MK7 8HX Waterloo, Wisconsin 3847 LG Harderwijk United Kingdom 53594 The Netherlands Tel.: 920.478.4678... - Page 33 Limited warranty Your bicycle is covered by a Limited Warranty. Please visit our website for details. For Service and Warranty, please contact your local authorised bike shop. Refer to our website (Support) for the latest revision of this manual. New features, as described in the latest manual, may not be applicable to your e-bike. PN 5284737 - EN-GB Rev 1, May 2022 ©...
- Page 34 PN 5284737 - EN-GB Rev 1 (Gen-2)
