- Page 1 Voltage-controlled power starvation Eurorack Module kit...
- Page 2 Contents (1) Front Panel (1) PCB (1) Resistor Card (1) Semiconductor Card (1) Capacitor Card (1) Hardware bag (8) 0.25" QC PCB tabs (2) 2x8 box header (2) M3x0.5 eurorack mounting screw (2) M3 nylon washer (2) 3mm (T1) LED, red (1) Wire bag (8) 13”...
- Page 3 Kit Notes Tools • Soldering iron with fine tip • Solder • Fine-tip tweezers • Nut drivers/sockets/wrenches: • 7mm (toggle switch) • 8mm (jack nuts) • 10mm (potentiometer nuts) • Wire strippers • Insulated connector crimper Skills This kit assumes that you have a basic understanding of electronics, electronic components, and soldering and assembling electronics.
- Page 4 Kit Notes (cont.) your soldering iron tip to the pre-soldered pad to reflow the solder. Then you can solder the other side normally. • Flux is your friend. Use flux. Water-soluble flux is best for a clean finish, but you have to make sure to get it all off when done, as it can corrode the joint and some fluxes may also be capacitive.
- Page 5 PCB Assembled Front View FAM1500-K v1.0 manual Jun. 2022 — p.4/15 www.flightofharmony.com...
- Page 6 PCB Assembled Rear View FAM1500-K v1.0 manual Jun. 2022 — p.5/15 www.flightofharmony.com...
- Page 7 SMD Reference FAM1500-K v1.0 manual Jun. 2022 — p.6/15 www.flightofharmony.com...
-
Page 8: Exploded View
Exploded View Numbers indicate easiest (in regard to soldering) order of assembly; see instruction list on p.3. FAM1500-K v1.0 manual Jun. 2022 — p.7/15 www.flightofharmony.com... -
Page 9: Led Installation
LED Installation Finger-tight Finger-tight Do not solder Solder rst Set lens to desired height then solder FAM1500-K v1.0 manual Jun. 2022 — p.8/15 www.flightofharmony.com... -
Page 10: Regulator Installation
Regulator Installation Bend line 90° FAM1500-K v1.0 manual Jun. 2022 — p.9/15 www.flightofharmony.com... -
Page 11: Power Cable Assembly
Power Cable Assembly Quick & Easy option 1. Strip about 0.25"/6.5mm from each end of wire. 2. Place quick-connect terminal over end of wire and crimp securely. 3. Use nylon cable ties to keep wires together & orderly. FAM1500-K v1.0 manual Jun. 2022 — p.10/15 www.flightofharmony.com... - Page 12 1) Make sure to dry it before use if you use boiling water. Don't use Famine wet. FAM1500-K v1.0 manual Jun. 2022 — p.11/15...
- Page 13 FAM1500-K v1.0 manual Jun. 2022 — p.12/15 www.flightofharmony.com...
- Page 14 Miscellaneous IC Orientation Line/Slope Pin 1 Line/Slope Diode Orientation (OR) LINE LED and capacitor Orientation FAM1500-K v1.0 manual Jun. 2022 — p.13/15 www.flightofharmony.com...
- Page 15 Miscellaneous (cont.) Tightening toggle switch jam nuts. Toggle switches are slightly shorter than the jacks and potentiometers, so the jam nut (rear nut) must be run flush with the panel before tightening the outer nut to prevent deforming the panel. Spin ush with panel, do not tighten.
- Page 16 FAM1500-K v1.0 manual Jun. 2022 — p.15/15 www.flightofharmony.com...
