- Page 1 U S E R M A N U A L SPDIF/TosLink/Coaxial Digital Audio Converter Model No: ADCN0002M1(Toslink To Coaxial) ADCN0003M1(Coaxial To Toslink)
- Page 2 INTRODUCTION Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Our series of converters, switchers, extenders, matrixes and splitters are designed to make your A/V device use more convenient, more comfortable, more productive and more cost- efficient.
- Page 3 Physical Connection Showing Picture： Toslink To Coaxial 1. Toslink input port 2. Coaxial output port 3. Power indication 4. DC Power Adaptor Interface(DC 5V~12V) Coaxial to Toslink 1. Toslink output port 2. Coaxial input port 3. Power indication 4. DC Power Adaptor Interface(DC 5V~12V)
- Page 4 Operating and Connecting： 1. To use the optical fiber cable or coaxial cable to connect the optical fiber signal source or coaxial signal source (such as blue-ray player, the computer and so on) with the converter input. 2. The converter output port through the optical fiber cable or coaxial cable connected to the optical fiber signal receiver or coaxial signal receiver (such as AV amplifier and so on).
- Page 5 Notes: Pls use the machine as the instruction listed to keep the long use lifetime of the machine. 1. The machine should be placed at the spot far from the Damp, High-Temperature, Dusty, Erosive, and oxidative environment. 2. All parts will be free from the strong shake, hit, fall. 3.
